- Page 1 FX-1500LCD/2200LCD FX-1500LCD-U/2200LCD-U Power Protection Home theater / Server & network...
-
Page 2: Important Safety Instructions
• The wall socket shall be located nearby the UPS and must be accessed very easily. System introduction The award-winning Forza FX Series, recognized by CHA as the best of its kind, offers an enhanced level of protection for your high performance office equipment, sensitive electronics and home-theater components. -
Page 3: Front Panel
Features • LCD displays real time status information • Easy to read LCD display with bright blue backlight • Power protection for home and office equipment • Boost & buck AVR to stabilize voltage • 8 outlets - Six (6) with surge protection, battery backup and AVR, plus two (2) surge only outlets •... -
Page 4: Home Theater
3. Charge the UPS This unit is shipped from the factory with its internal battery fully charged; however, some charge may be lost during shipping. Therefore, it is recommended to charge the battery prior to initial use. Simply plug the unit into an appropriate AC outlet, and allow it to recharge to full capacity for at least 8 hours. - Page 5 5. Network/Modem/Phone line connection Connect the incoming internet line into the input surge protected jack on the back of the UPS. Then connect another network cable from the output jack on the UPS to the modem input socket, as shown in the figure below. NETWORK / PHONE LINE CABLE RESET...
-
Page 6: Turn On/Off Ups
Simply press the power switch to turn on the UPS. 10. LCD display The Forza 1500/2200LCD/LCD-U Series comes equipped with an easy to read LCD and a blue backlight that displays the battery status, input voltage, output voltage, and operation mode of the UPS. -
Page 7: Battery Removal
Battery removal* Follow the steps 1 to 3 to replace the batteries. Disconnect all sources of power before replacing the battery. Remove the front panel. Remove the battery cover. After removing battery cover, gently extract the battery by disconnecting the two wires connected to the UPS. -
Page 8: Software Installation
Even when mains supply is normal, the LED still displays battery mode Possible Cause Solution Circuit breaker trips Reset the circuit breaker. Power cord is loose. Reconnect the power cord properly. * For further assistance, please contact us at tech@forzaups.com• When replacing your batteries, we recommend using a Forza FUB-1290. -
Page 9: Technical Specifications
Technical specifications * 2 years on batteries **Calculated with a single PC plus monitor... - Page 10 Forza Power Technologies, LLC Forza® is a registered trademark. All rights reserved. Reproduction of this manual or any part thereof is forbidden without written consent from Forza Power Technologies, LLC. All other trademarks and brand names are registered trademarks of their respective owners. Any mention of such is...
