1-5. Maintenance, Service and Faults 2. Operation 2.1 Unpacking and inspection 2.2 UPS front and rear panel views 2.3 Installation Procedure 2.4 Forza Tracker monitoring software 3. Advanced operation 3.1 Description of buttons and functions 3.2 LCD Panel 3.3 Audible alarm 3.4 Abreviations on the LCD display... -
Page 3: Introduction
1. Introduction Thank you for purchasing the Forza Atlas 3000 Online UPS. To enjoy all the features and benefits of this unit, please read and follow all installation and operation instructions thoroughly before unpacking, installing or operating this device. After you have read this manual, keep it in a safe place for future reference. -
Page 4: Maintenance, Service And Faults
1-5. Maintenance, service and faults • The voltage used by this UPS may be hazardous. The unit contains no user serviceable parts; do not attempt to disassemble the unit. Only qualified service technicians can perform maintenance on the unit. Failure to adhere to this could cause personal injury or equipment malfunction and void the warranty. -
Page 5: Installation Procedure
Rear panel view Programmable outlets: connect to non-critical loads. Output receptacles: connect to high critical loads. AC input Input circuit breaker Network/Fax/Modem surge protection Emergency power off (EPO) connector USB communication port RS-232 communication port SNMP intelligent slot Output terminal Output circuit breaker Input terminal 2.3. -
Page 6: Forzatracker Monitoring Software
Step 3: Communication connection Communication port: USB port RS-232 port Intelligent slot To allow for unattended UPS shutdown/start-up and status monitoring, connect one end of the communication cable to the USB/RS-232 port, and the other end to the communication port of your PC. With the monitoring software installed, you can schedule UPS shutdown/start-up and monitor UPS status through PC. -
Page 7: Advanced Operation
Installation procedure for Windows users: 1. Use the supplied CD or go to the website: http://www.forzaups.com. 2. After clicking the software icon, choose the required operation system. 3. Follow the on-screen instructions to install the software. 4. When you finished downloading all required files, enter the serial No (installation password): 5242-87f6-64re-di8d-986u to install the software (include the hyphens). -
Page 8: Lcd Panel
3-2. LCD panel... - Page 9 Display Function Backup time information Indicates the remaining backup time in pie chart. Indicates the remaining backup time in numbers. H: hour, M: minute, S: second Fault information Indicates that the warning and fault occurs Warning and fault code indicators. The meaning of the codes is listed in the section below.
-
Page 10: Audible Alarm
3-3. Audible alarm Battery mode Beeps once every 4 seconds Low battery Beeps once every second Overload Beeps twice every second Fault Beeps continuously Bypass mode Beeps every 10 seconds 3-4. Abbreviations on the LCD display Abbreviation Display content Meaning Enable Disable Escape... - Page 11 01: Output voltage settings Interface Setting Parameter 3: Output voltage For 200/208/220/230/240 VAC, you may choose any of the following output voltages in parameter 3: 200: The output voltage is 200VAC 208: The output voltage is 208VAC 220: The output voltage is 220VAC 230: The output voltage is 230VAC 240: The output voltage is 240VAC For 100/110/150/120/127 VAC, you may choose any of the...
- Page 12 05: ECO voltage range settings Interface Setting Parameter 2 & 3: Press the UP or Down key to choose the acceptable high and low voltage values for the ECO mode. HLS: High line transfer in ECO mode as set in parameter 2. For 200/208/220/230/240 VAC, the setting in parameter 3 ranges between +7V and +24V of the nominal voltage.
- Page 13 08: Enable/Disable programmable outlets Interface Setting Parameter 3: Activates or cancels the programmable outlet feature. ENA: Programmable outlets enabled DIS: Programmable outlets disabled 09: Backup time setting for programmable outlets Interface Setting Parameter 3: Sets the backup time limits for the programmable outlets.
-
Page 14: Operating Mode Description
3-6. Operation mode description Operating mode Description LCD display When the input voltage is within acceptable range, the UPS Online mode will supply pure and stable AC power to connected loads. The UPS will also charge the battery in online mode. Energy saving mode: ECO mode When the input voltage is within the voltage regulation range,... -
Page 15: Warning Indicators
3-8. Warning indicators Warning Icon (flashing) Alarm Low battery Beeps once every second Overload Beeps twice every second Battery not connected Beeps once every second Overcharge Beeps once every second Beeps once every second Site wiring fault EPO enable Beeps once every second Over temperature Beeps once every second Charger failure... - Page 16 4. Troubleshooting guide If the UPS system does not operate correctly, use the table below to troubleshoot the problem. Symptom Possible cause Remedy The AC input cable is not Check to make sure the power cord is Even though the mains supply properly connected.
-
Page 17: Storage And Maintenance
Symptom Possible cause Remedy Fault code 14 becomes illuminated The UPS shuts down Check the output wiring and along with the icon on the automatically upon if connected devices are LCD display, and the alarm starts detecting the overload short-circuited. beeping continuously. - Page 18 6. Specifications Model FDC-003K 3000 VA / 2400 W CAPACITY* INPUT 160VAC / 140VAC / 120VAC / 110VAC ± 5 % or 80VAC / 70VAC / 60VAC / 50VAC ± 5 % Low line transfer (based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
