Overview / Type / Compliance / Warnings /
Precautions / Wiring / Plugs
Overview
These Structural Concepts cases are designed to
merchandise packaged products at 41 °F (5 °C) or less
product temperatures.
Refrigerated Display cases are classified by "Test Room
Climate Class." Test Room Climate Class 8 is to be
operated in an environment of 24°C (75.2°F) 55% R.H.
Product must be pre-chilled to 41 °F (5 °C) or less before
being placed in the case.
Component parts shall be replaced with like components.
Cases should be installed and operated according to
this operating manual's instructions to ensure proper
performance. Improper use will void warranty.
Compliance
Performance issues when in violation of applicable
NEC, federal, state and local electrical and plumbing
codes are not covered by warranty.
This equipment MUST be installed in compliance
with all applicable NEC, federal, state, and
local electrical and plumbing codes.
Grocerant® User Manual
NSF/ANSI Type I vs. II Environmental
Conditions
This case is designed to display products in ambient
indoor store conditions where temperature and humidity
are maintained within a specific range.
NSF/ANSI Type I Conditions: Product is displayed in store
conditions with a maximum ambient temperature of 75 °F
(24 °C) and maximum relative humidity of 55%.
NSF/ANSI Type II Conditions: Product is displayed in store
conditions with a maximum ambient temperature of 80 °F
(27 °C) and maximum relative humidity of 55%.
If you are unsure if your unit is classified as NSF/ANSI Type
I or Type II, see the tag next to the serial label on your
case.
Warnings
This page contains important warnings to prevent
injury or death. Please read carefully!
Risk of electric shock. Disconnect power before
servicing the unit. CAUTION! More than one
WARNING
source of electrical supply is employed with
ELECTRICAL
HAZARD units that have separate circuits. Disconnect
ALL ELECTRICAL SOURCES before servicing.
Hazardous moving parts. Do not operate the
WARNING
case with the covers removed. Fan blades
KEEP
may be exposed when deck panel is removed.
HANDS
CLEAR
Disconnect power before removing deck panel.
This product can expose you to chemicals,
including Urethane (Ethyl Carbonate), which are
known to the state of California to cause cancer
and birth defects or other reproductive harm. For
more information, go to P65Warnings.ca.gov.
Condensate pan and overflow condensate
WARNING
pans are HOT! Disconnect and allow to cool
HOT
SURFACE
before cleaning or removing from case.
Do not place any items on the glass top
surface to prevent scratching or marring.
3
