Oasis® User Manual
P A R T N U M B E R : 2 1 - 3 5 3 9 8
Please Note
Your specific model number is located on the
serial label (usually at the case rear). However,
label locations may vary depending on the
model – see page 20 for more details.
Models shown on this cover sheet do not
represent all models covered by this manual.
Support:
structuralconcepts.com/support
Tech Service/Warranty:
1 (800) 433-9490, EXT. 1
Hours:
Monday – Friday, 8am to 8pm EST (Closed holidays)
21-35398 OASIS REFRIGERATED SELF-SERVICE FS-EN
Models
FSC460R
FSC660R
FSE460R
FSE660R
FSI660R
FSI860R
Before contacting, you must have the following:
Serial no., model no., store no., store address, details (photos, leak locations,
damage, store's ambient conditions, etc.)
FSI860R
REV B DATE: 10/18/24
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Structural Concepts Oasis FSC460R
Summary of Contents for Structural Concepts Oasis FSC460R
- Page 1 Oasis® User Manual P A R T N U M B E R : 2 1 - 3 5 3 9 8 FSI860R Please Note Models Your specific model number is located on the FSC460R serial label (usually at the case rear). However, FSC660R label locations may vary depending on the FSE460R...
-
Page 2: Table Of Contents
Table of Contents Overview / Type / Compliance / Warnings / Precautions / Wiring / Plugs ................Installation: Case Removal From Skid .. -
Page 3: Overview / Type / Compliance / Warnings / Precautions / Wiring / Plugs
Precautions / Wiring / Plugs Overview NSF/ANSI Type I vs. II Environmental Conditions These Structural Concepts cases are designed to merchandise packaged products at 41 °F (5 °C) or less This case is designed to display products in ambient product temperatures. -
Page 4: Wiring Diagram
California Code of Regulations, title 17, section 95374. This disclosure statement has been reviewed and approved by Structural Concepts and Structural Concepts attests, under penalty of perjury, that these statements are true and accurate. - Page 5 Refrigerant Warnings Following are important information regarding refrigerants. Read carefully! DANGER Refrigeration unit contains gas under high pressure. Do not tamper with or puncture the system. Contact qualified service personnel before disposal. Risk of fire or explosion. Flammable refrigerant is used in this case. Minimum room area (operating or storage): 77.25 ft (7.1 m Consult repair manual/owner’s guide before servicing this product.
-
Page 6: Installation: Case Removal From Skid
Installation: Case Removal From Skid Remove Lower Panels From Case: • To prevent damage to the case, remove the lower front and panel from the case before removing it from the pallet. • Panels are secured by a set of hooks and magnets. •... - Page 7 Installation: Case Removal From Skid Levelers: • There are levelers on each corner of the case. • Raise levelers to their highest position to engage the Levelers casters. Carefully Remove Case From Pallet: • Carefully lower to the floor (using a ramp if available). •...
-
Page 8: Installation: Start Up
Installation: Start Up Plug Case In/Turn On Main Power Switch: • Do not use an extension cord with this case. • Do not operate this equipment with a damaged cord, plug, or outlet. • Ensure that the main power switch is off. •... -
Page 9: Placement Of Case
Placement of Case Consider where the display case will be positioned relative to walls, ceilings, HVAC vents, windows, and other equipment discharging warm air. The 5’ - 10’ - 15’ Rule Stay 5’ away from an exterior window With service display cases that have a glass front, air blowing on the front glass causes condensation to Direct sunlight increases the heat load on the front of develop. -
Page 10: Product Placement
Product Placement Product Placement Product can be placed on decking. Proper airflow is critical to maintaining proper product temperature. Product should not be placed on air grills inside of the case and have at least 1 inch of clearance between product and discharge. See merchandising illustration below. - Page 11 Product Placement Product Placement Product can be placed on decking. Proper airflow is critical to maintaining proper product temperature. Product should not be placed on air grills inside of the case and have at least 1 inch of clearance between product and discharge. See merchandising illustration below.
- Page 12 Product Placement Product Placement Product can be placed on decking. Proper airflow is critical to maintaining proper product temperature. Product should not be placed on air grills inside of the case and have at least 1 inch of clearance between product and discharge. See merchandising illustration below.
-
Page 13: Shelf And Deck Load Limits
Shelf and Deck Load Limits The chart below lists the load limits for the shelves and decks. All weights below are for a uniformly distributed load. All values are in pounds. M AX UP P ER MAX U PP E R MA X L OWE R M AX L OW E R M A X SI N GL E... -
Page 14: Lower Front Panel Removal
Lower Panel Removal Servicing of refrigeration components is to be done by a licensed refrigeration contractor. • Remove lower front panel to access the compressor package. • Carefully slide condenser package pan out from under case to access various components. •... -
Page 15: Side Panel Removal
Side Panel Removal Servicing of refrigeration components is to be done by a licensed refrigeration contractor. • Remove lower rear panel to access the compressor package. • Carefully slide condenser package pan out from under case to access various components. •... -
Page 16: Cleaning Schedule (To Be Performed By Store Personnel)
Cleaning Schedule (To Be Performed by Store Personnel) F REQU ENC Y IN ST R U CT I ON S Glass Surfaces: Clean glass surfaces and shelves with household or commercial glass cleaner. Daily Exterior Panels: Wipe off all surfaces with warm water and mild soap solution and non-abrasive Daily cloth. -
Page 17: Preventative Maintenance
Preventive Maintenance Maintenance and Service Notes WARNING! TURN OFF CASE BEFORE PERFORMING PREVENTATIVE MAINTENANCE • All maintenance staff and others working in the local area shall be instructed on the nature of work being carried out. Work in confined spaces shall be avoided. •... - Page 18 Preventive Maintenance Maintenance and Service Notes WARNING! TURN OFF CASE BEFORE PERFORMING PREVENTATIVE MAINTENANCE Repairs to sealed components • During repairs to sealed components, all electrical supplies shall be disconnected from the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanent opening form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation.
- Page 19 Preventive Maintenance Maintenance and Service Notes WARNING! TURN OFF CASE BEFORE PERFORMING PREVENTATIVE MAINTENANCE Removal and evacuation • When breaking into the refrigerant circuit to make repairs-or for any other purpose-conventional procedures shall be used. However, for flammable refrigerants it is important that the best practice be followed, since flammability is a consideration.
- Page 20 Preventive Maintenance Maintenance and Service Notes WARNING! TURN OFF CASE BEFORE PERFORMING PREVENTATIVE MAINTENANCE Decommissioning • Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of recovered refrigerant.
- Page 21 Preventive Maintenance Maintenance and Service Notes WARNING! TURN OFF CASE BEFORE PERFORMING PREVENTATIVE MAINTENANCE Recovery • When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all refrigerants are removed safely. • When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for holding the total system charge is available.
-
Page 22: Serial Label Information & Location
TECHNICAL SERVICE page in this manual for instructions panels/toe-kicks, on electrical boxes, etc.). on contacting Structural Concepts’ Technical Service Department. Serial labels contain electrical, temperature and refrigeration information, and regulatory standards to This disclosure statement has been reviewed and which the case conforms. -
Page 23: Programmable Controller Information
Programmable Controller (Select, Click On or Scan Qr Code for Information) Determine which programmable controller is on your case (Controllers that Structural Concepts commonly use are shown below). Your particular programmable controller may differ. Carel® PJEZ Platform Carel® ir33 Platform Carel®... -
Page 24: Technical Service Contact Information / Warranty Information
Structural Concepts Technical Service Contact Information & Limited Warranty Contact Information Web: structuralconcepts.com/support Hours Available: Monday – Friday, 8am to 8pm EST (Closed holidays) Tech Service/Warranty: 1 (800) 433-9490, EXT. 1 Before contacting, you must have the following: serial number / model number / store number / store address / details (photos, leak locations, damage, store’s...
