PlaneMatch = Single Axis Slope
©2025 Spectra Precision | All Rights Reserved
PlaneMatch requires RC1402 and HL760 or CR700 receiver that is paired with the laser.
Press M button on the remote control. Using the up and down arrow buttons scroll to
>>PlaneMatch<<. Press E button to enter the sub menu. Press E button to confirm the
PlaneMatch for the Y axis. When PlaneMatch has been completed, the HL760/CR700 goes
back to the standard elevation display. The laser shows it status by simultaneously
flashing rad and green LEDs once a second.
Note: The Y axis is in manual mode and the X axis is in automatic mode.
Exiting PlaneMatch can be done by pressing the Manual button twice where the unit
always goes back to automatic mode.
Red and green LED is flashing to indicate Single Axis Slope
Mode Manual button
