  • Page 1 LL1505C USER GUIDE spectraprecision.com contractors-tools.com contractors-tools.com 1-877-866-5721 North America...
  • Page 2 Exit of Laser Beam Austritt Laserstrahl Sortie du faisceau laser Salida del rayo láser Uscita del raggio laser Uitgang van laserstraal Lasersäteen poistuminen Utgång från laserstrålen Exit of Laser Beam Austritt Laserstrahl Sortie du faisceau laser Salida del rayo láser Uscita del raggio laser Uitgang van laserstraal Lasersäteen poistuminen...

  • Page 4: Table Of Contents

    Spectra Precision LL1505C Horizontal Laser User Guide Contents Introduction ....................7 Safety Instructions ..................7 Product ......................9 General Description ..................9 Intented Usage ....................9 Product Components ...................10 RC1402 Remote Control ................11 Batteries ......................11 3.5.1 Installing Batteries ................11 3.5.2 Battery Status Indication ..............12 3.5.3...
  • Page 5 24 Protect the Unit ....................38 25 Cleaning and Maintenance ................38 26 Protecting the Environment................38 Warranty ......................39 28 Technical Specification...................40 28.1 Technical Specification LL1505C Laser ............40 28.2 Technical Specification RC1402 Remote Control ........41 29 Declaration of Conformity ................41 30 UKCA ......................41...

  • Page 6: Introduction

    Introduction Thank you for choosing one of the Spectra Precision Lasers from the family of precision lasers. This user guide is about the LL1505C self-leveling laser, which is an easy-to-use tool that offers accurate horizontal reference up to 2000 ft. (600m) diameter when using a receiver.
  • Page 7 • Before starting your work, always check the accuracy of the product. • Spectra Precision is not responsible for any inaccuracy that is caused by not reading the user guide and by any misuse of the product. • The user of the product is responsible for checking the result for the measurement.

  • Page 8: Product

    Product General description The laser may have been shipped to you with rechargeable NiMH battery pack or with alkaline batteries. In any case alkaline batteries can be used as a backup to power the laser at the job site. When alkaline batteries are used, the plus and minus symbols at the battery door indicate how to put the alkaline batteries into the battery compartment.

  • Page 9: Product Components

    Product Components LL1505C Laser (Refer to pages 2 and 3) Power Button Press for one second to turn on the Laser; press and hold for 2 seconds to turn off the laser Battery LED Shows the amount of battery charge Leveling/Bluetooth®...

  • Page 10: Rc1402 Remote Control

    WILL RESULT IF CHARGING IS ATTEMPTED. Close the battery door. The LL1505C can be used with a rechargeable NiMH battery pack, which is keyed to prevent mis-insertion. The way it is designed allows only the correct installation. Alkaline batteries can be used as a backup.

  • Page 11: Battery Status Indication

    3.5.2 Battery status indication WHY: The customer needs to know the battery status when starting the work at the job site. WHAT: The battery indication shows the remaining battery capacity for the rechargeable battery pack. The battery indication is also shown for alkaline batteries, but the true remaining battery lifetime depends on the battery brand.

  • Page 12: Laser Setup

    Note: The batteries should only be charged when the temperature is between 41°F and 104°F (5°C to 40°C). Charging at another temperature than specified may not start the charging process. Waiting for a temperature change may finally start the charging process when the temperature was too low. Note: The charger has a security timer.

  • Page 13: Menu Navigation Via Rc1402 Only

    10 minutes, the unit shuts down completely. Menu Navigation via RC1402 Only WHY: All features of the LL1505C can be accessed by a menu driven interface using the remote control RC1402. This is an intuitive way to operate the laser that is also easy to remember since it does not require certain two or three finger button presses.

  • Page 14: Bluetooth® Connectivity

    HOW: Option 1: When powering the LL1505C, it is in connectivity mode for the first thirty seconds. During this time start the Laser Remote App. When starting the Laser Remote App for the very first time after installation, accept the EULA.

  • Page 15: Manual Mode Horizontal

    Pic 5 Horizontal automatic mode The display shown in picture 5 is available via the remote control RC1402 only. Manual Mode Horizontal WHY: For some applications the user may require a non-level laser plane. This can be used to align non-level elevations or reference hubs. The laser can be sloped in both axes when in horizontal manual mode.

  • Page 16: Rotation Speed

    The LL1505C can shut off the laser beam in one, two or three sections. These sections are limited to the size of the lighthouse windows in the four axes. The status of the mask mode is shown on the standard display LCD of the remote control;...

  • Page 17: Standby Mode

    Option 2: Press and release the M button (r) at the keypad of the remote control to enter the menu. Select >>Mask Mode<<, (pic 9). Depending on the sector the beam should be shut off, the desired sector can be selected. For selecting the sector, press and release one of the arrow buttons.

  • Page 18: Single Axis Slope Mode (Y Axis)

    HOW: Press and hold the manual button (o) at the laser or RC1402 remote control for three seconds to bring the laser into the standby mode. Press and hold the manual button (o) again for three seconds to deactivate the standby mode and to restore full operation of the laser.

  • Page 19: Planematch (Y-Axis) = Automatic Single Axis Slope

    14 PlaneMatch (Y-Axis) = Automatic Single Axis Slope The PlaneMatch function requires a remote control RC1402 or the laser remote app. WHY: On some jobsites the fall or the rise of the ground or between two existing elevations is not known. It is the goal to match the fall/raise of the ground or between the two existing elevations.
  • Page 20 Note: When the function PlaneMatch is complete, the laser will be in single axis slope mode for the Y axis. This means, the Y axis is in manual mode and the X axis is in automatic self-leveling mode. There might be no warning for changes in the Y axis when there is a drift of the laser plane.

  • Page 21: Settings

    Download the app from the store to your smartphone and install it. HOW: Option 1: When powering the LL1505C it is in connectivity mode for the first thirty seconds. During this time start the Laser Remote App. When starting the Laser Remote App for the very first time after installation, accept the EULA.

  • Page 22: Radio

    This is why the LL1505C provides a delay time for the Shock Warning. The delay time for Shock Warning should allow the user a certain amount of set-up time without any alarm of height changes.

  • Page 23: Backlight (Rc1402 Only)

    HOW: On the remote control press the M button (r) to enter the menu. Scroll to >>Settings<<, press the E button (s), scroll to >>HI-Alert<< (see pic 21), press E button to open the HI-alert submenu. Choose delay time 5 min (default), (see pic 22), 30 seconds or HI-Off, (see pic 23), by scrolling to the option and confirming by pressing the E button on the remote control or in the laser remote app when used.

  • Page 24: Language

    WHY: The company using the LL1505C may have employees from different countries. The laser may be shifted from one person to another, each with a different native language. Each person on a job site using the LL1505C wants to use the laser in their known language.

  • Page 25: Radio Channel

    WHAT: The LL1505C provides six different radio channels. Those are 0 (default), 1, 2, 3, 4 and 5. HOW: The radio channel can be changed only using the remote control! Press M button (r) on the remote control to enter the menu.
  • Page 26 Information about the runtime of the laser is the time the laser has been used since it was produced. The runtime is shown in hours and minutes. It cannot be set to zero. Information about the current radio channel that has been selected for the communication path is available.
  • Page 27 Scroll to >>Temperature>> (see pic 32) and press E button to show the current temperature within the product in °C and °F (see pic 33). Note: This is the internal product temperature, and this can be different to the ambient temperature. Pic 32 Temperature menu Pic 33 Laser temperature °C / °F Scroll to >>PWR-Firmware<<...
  • Page 28 Pic 38 Serial number menu Pic 39 Laser serial number In menu >>Runtime<< (see pic 40), press E button to enter the menu and to see the current runtime of the laser (see pic 41). Pic 40 Runtime menu Pic 41 Laser runtime Scroll to >>Radio<<...

  • Page 29: Determining The Height Of Instrument (Hi)

    Determining the Height of Instrument (HI) WHY: For most applications it is necessary that the height of instrument (HI) is known because it is used as a reference height and control elevation on a regular basis. WHAT: The height of instrument (HI) is the elevation of the laser beam in relation to a benchmark or reference point.

  • Page 30: Vertical Application

    18 Vertical Application WHY: The LL1505C can be set up in vertical position but the laser is now in manual mode only. This allows the usage of the laser when self-leveling is not required to use the laser as a non-level reference. Maybe the application assures that the reading will be done at the same elevation by purpose.

  • Page 31: Pair The Laser With Cr700

    After completing PAIR OK will be displayed on the receiver and a long beep occurs. The LL1505C has been paired with this receiver and turns back to the standard function. On the HL760 press and release the power button twice to exit the menu at the receiver.

  • Page 32: Remote Control Rc1402

    After completing PAIR, OK will be displayed on the receiver and a long beep occurs. The LL1505C has been paired with this receiver and turns back to the standard function. On the CR700 press and release the power button once to exit the menu. A laser symbol and an antenna are lit to confirm the receiver is ready for communication with the laser.

  • Page 33: Pairing The Remote Control Rc1402 With The Laser

    20.3 Pairing The Remote Control RC1402 With The Laser WHY: The communication between remote control RC1402 and the laser LL1505C is based on a radio communication path. This enables a unique communication path that ensures only the paired laser will be controlled by the paired remote control.

  • Page 34: Troubleshooting

    Menu functions for the LL1505C: >>Rotation<< >>PlaneMatch<< >>Single Slope<< >>Mask Mode<< >>Settings<< >>Info<< >>Service<< 21 Troubleshooting Any error message at the remote control RC1402 or the app can be confirmed with a short press on the button E or on the OK (app). The table below shows the related description and possible solutions.
  • Page 35 Laser beam blocked Press E button (s) on the remote control or the OK button in the app to delete the error message. Make sure there are no obstacles between the laser and HL760/CR700 receiver during the operation. The receiver needs to receive the laser beam all the time during this function.

  • Page 36: Check Accuracy

    22 Check Accuracy 22.1 Checking accuracy of the Y- and X Axis 1. Set up the laser 30 m (100 ft.) from a wall and allow it to level. 2. Raise/lower the receiver until you get an on-grade reading for the –Y axis. Using the on-grade marking notch of the receiver as a reference, make a mark on the wall.

  • Page 37: Service

    23 Service 23.1 Technician Menu Access to Technician menu, see pic 47, is only possible for trained service dealer personnel. Pic 47 Technician menu 24 Protect the Unit Do not expose the unit to extreme temperatures or temperature changes (do not leave inside the car).

  • Page 38: Warranty

    27 Warranty Spectra Precision LLC warrants the LL1505C to be free of defects in material and workmanship for a period of five years. Spectra Precision LLC or its authorized service center will repair or replace, at its option, any defective part, or the entire product, for which notice has been given during the warranty period.

  • Page 39: Technical Specification

    28 Technical Specification 28.1 Technical Specifications LL1505C Laser Leveling Accuracy , Horizontal ± 1,5mm / 30m (1/16 in @ 100 ft) 10 arc seconds Rotation Speed 300, 600, 900 rpm Operational Diameter with HL760 Typ. 1200 m (4000 ft) PlaneMatch Distance Typ.

  • Page 40: Declaration Of Conformity

    Applied European directives: 2011/65/EU RoHS Directive, 2014/53/EU Radio Equipment Directive 30 UKCA We declare under our sole responsibility that the products LL1505C and RC1402 are in conformity with the following relevant UK Statutory Instruments: 2012 No. 3032 The Restriction of the Use of Certain Hazardous Sub-stances in Electrical and Electronic Equipment (RoHS) 2017 No.

  • Page 41: Electro-Magnetic Compatibility

    This in particular is applicable for the antenna, which has been delivered with the LL1505C and RC1402. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada.
  • Page 43 Spectra Precision (USA) LLC Spectra Precision 3265 Logistics Lane, Suite 200 North America Distributor Dayton, OH 45377 Contractors-Tools.com U.S.A. 1-877-866-5721 Phone +1 888-527-3771 © 2024, Spectra Precision (USA) LLC. All rights reserved. PN 101979-00 Rev. A (12/24)
