Installation using external input terminals
For any of the con gurations utilising the external alarm circuit input, the reed switch of the device
should be linked out. See section "C. Jumper headers
(https://www.support.pyronix.com/uk/product/mc1z1-we/documentation/mc1z2-shock-we-
installation-guide#C.+Jumper+header+overview)".
Please note: The colours for the circuits below are indicative and not the colours required to make the
circuit work.
