- Page 2 Tamper Mounting Options EOL Resistor Headers: The KX10DP has 2 sets of header pins (as shown). These headers are used to select the End of Line resistance for EOL wiring applications. NOTE: If EOL wiring is not used, leave the headers OFF.
- Page 3 ALARM: ALARM TAMPER ALARM TAMPER TAMPER: ALARM TAMPER ALARM TAMPER 6K8, 5K6, TAMPER 5K6, 4K7, ALARM 4K7, 2K2, 2K2, ALARM TAMPER ALARM TAMPER ALARM TAMPER ALARM TAMPER GENERIC CONTROL PANEL PANEL OUTPUT CENTRALE GENERICA DEOL DEOL USCITA DELLA CENTRALE LED OFF PCX / EURO EURO EOL INPUT 1 COM...
