Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and
water damage. For the detailed operation, see FAQ manual.
No. Port Name
1 Ethernet port
2 Power port
1 Cable
Figure 1-1 Cables
Table 1-1 Cable information
Description
Connects to network with network cable.
●
Provides power to the device with PoE.
●
Do not connect both network cable and Wi-Fi at the same time.
Inputs 12 VDC power. Be sure to supply power as instructed in
the manual.
Device abnormity or damage might occur if power is not
supplied correctly.
1
Quick Start Guide
