EAGLE
E-SCOOTER
OWNERS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EAGLE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for gio EAGLE

Summary of Contents for gio EAGLE

  • Page 1 EAGLE E-SCOOTER OWNERS MANUAL...
  • Page 2 PLEASE INSPECT THIS NEW GIO ELECTRIC EAGLE LSM E-SCOOTER UPON ARRIVAL. REPORT DAMAGES THAT MAY HAVE OCCURRED DURING SHIPPING TO THE DEALER IT WAS PURCHASED FROM OR TO GIO IF PURCHASED DIRECT.

  • Page 3: Table Of Contents

    Modification of the scooter in any way may also void the warranty. Please note illustrations/images in this manual may differ from the final product. If concerns or questions in regards to this e-scooter arise please contact the GIO Dealer from which it was purchased or GIO Electric Customer Service...

  • Page 4: Safe Operation Guide

    SAFE OPERATIONS GUIDE ALWAYS ride in proper accordance with local laws and regulations. Ensure the vehicle is properly registered and the rider properly licensed. Always obey local traffic laws. ALWAYS be aware of surroundings, pedestrians, traffic, etc. Be sure to take extra care when driving in spaces shared with motor vehicles, parking lots, driveways, crosswalks etc ALWAYS take extra care when driving at night and use the headlight.
  • Page 5 NEVER park or store the scooter in hallways, stairways or doorways where it may impede exit in the event of an emergency. ⚠ DO NOT MAKE ANY ALTERATIONS OR MODIFICATIONS TO THIS GIO E-SCOOTER OR ADD ANY PARTS NOT AUTHORIZED BY GIO EXCEPT THOSE DISCUSSED IN THIS MANUAL OR THOSE REQUIRED BY LAW.

  • Page 6: Assembly

    ASSEMBLY The GIO Eagle e-scooter arrives 90% assembled and is ready in 5 simple steps. 1. Unboxing Untie or snip the wires holding the scooter in its protective frame and remove it from its packaging. Ensure to save packing material until the scooter is completely assembled to avoid discarding any small parts.
  • Page 7 3. Battery Connections Each scooter ships with certain battery wires disconnected to prevent the unit from accidentally being turned on during shipping and to reduce excess battery discharge. Begin by opening the under-seat compartment as described on pg 08. Once open remove the plastic tray within to reveal the battery compartment below.
  • Page 8 ASSEMBLY continued… Battery Wires The Eagle’s 72V battery pack is made up of six 12V cells connected in series. The first and last cells in the battery pack need to be connected to the corresponding battery wire from the scooter.

  • Page 9: Component Diagrams

    COMPONENT DIAGRAM a Mirrors Front wheel, fender, brakes b Throttle, right brake lever, g serial number cover plate buttons (power, speed horn) h Footrest right signal light Charge port c LCD Display (center), left brake lever, Seat, battery & controller (internal) buttons (Headlight, signals, horn) k Rear light, rear signal lights Left signal light...

  • Page 10: Scooter Operation

    Do not remove the key while the scooter is in motion, this will result in loss of power and possible loss of control. The Eagle also features a red power button next to the throttle. This button can be used to quickly turn the unit on or off while the ignition is in the on position.

  • Page 11: Steering Lock

    Alarm The Eagle is equipped with an easily operated security alarm. To activate the alarm, squeeze the left brake handle while turning the scooter off. Once activated if the scooter is physically moved the alarm siren will sound.
  • Page 12 SCOOTER OPERATION continued… Kickstands The Eagle includes a pair of kickstands, a main center kickstand and a side kickstand. To use the side kickstand, push the kickstand down with a foot into the extended position and rest the scooter on the kickstand. When not needed, straighten the scooter and push the kickstand back into position.

  • Page 13: Electrical System Operation

    GIO Electric Customer Service. The Eagle comes complete with its own charger, do not use a charger not designed for this specific scooter model. Never recharge the batteries without supervision. Keep away from children while actively charging.
  • Page 14 Over the life of the scooter, clean the different parts with a degreaser to remove any excess dirt that has been collected on them and then relubricate. ⚠ IF THE BRAKES ARE NOT WORKING PROPERLY, DISCONTINUE SCOOTER USE AND CONTACT THE DEALER OR GIO CUSTOMER SERVICE. ⚠...
  • Page 15 Brakes The Eagle is equipped with front and rear hydraulic disc brakes which require little user maintenance. Insufficient brake fluid may allow air to enter the brake system, possibly causing it to become ineffective. If the brake fluid level is low, be sure to check the brake pads for wear and the brake system for leakage.

  • Page 16: Motor & Controller

    MAINTENANCE & CARE continued… Motor & Controller The electric scooter motor is usually a permanent magnet (brushless) motor that features high output torque and efficiency. Maintenance is not normally required and should only be performed by a qualified technician. Check and ensure all motor mounting hardware is secure regularly. If any are found to be loose, tighten them to avoid motor damage when riding.

  • Page 17: Troubleshooting

    Scooter doesn’t stop Hydraulic line issue Seek technical support/repair when applying brakes If difficulties with the scooter arise that are outside of these issues or these solutions are not correcting the problem, contact a technician at the dealership or GIO customer service.

  • Page 18: Wiring Schematic

    WIRING SCHEMATIC SPECIFICATIONS Rated Motor Power 1200w 6X Liquid Cooled Rear Display Hub Motor Top Speed 50 km/h Battery 72V23AH Graphene Battery Range Up to 70 km Controller 72V35A Measurements 177 x 72 x 107cm Brakes Front/Rear Hydraulic Disc Wheelbase 130cm Suspension Hydraulic Front / Rear...

  • Page 19: Warranty

    WARRANTY The following details are applicable to all scooters sold directly to customers by GIO. If this product was purchased via an Authorized Dealer please refer to the warranty coverage provided by the dealer and contact them directly for warranty-related claims or assistance.
  • Page 20 11400 Twigg Place Richmond, BC V6V 3C1 Canada support@gioelectric.zendesk.com 1-855-907-4211 © GIO Electric, 2024. All Rights Reserved...
