Summary of Contents for gio GOLF ENCLOSED

  • Page 2 To ensure the safety and reliability of this scooter, do not modify the scooter, and always use parts, i.e. charger, specifically designed for the GIO Golf Enclosed Mobility Scooter. Details contained in this manual are subject to change. Images are for...

  • Page 3: Table Of Contents

    ⚠ THIS SCOOTER IS ELECTRIC, TAKE PROPER CARE NOT TO MAKE CONTACT WITH ELECTRICAL CONTACT WITH BODY OR TOOLS. ⚠ ⚠ ALWAYS APPLY BRAKES WHILE GOING DOWNHILL TO CONTROL SPEED AND AVOID SHARP TURNS AT HIGHER SPEEDS TO PREVENT TIPPING SIDEWAYS! ⚠ ⚠...

  • Page 4: Riding Safety

    RIDING SAFETY ALWAYS ride in accordance with local regulations for mobility scooters as in most places they are intended for sidewalk use and are not street-legal ALWAYS practice driving the scooter in an open area before driving amongst vehicle/pedestrian traffic ALWAYS accelerate slowly and steer with both hands ALWAYS drive with caution at appropriate speeds ALWAYS use the scooter’s turn signals and horn...

  • Page 5: Overview

    NEVER turn the scooter off while in motion NEVER use replacement parts not approved by GIO Electric NEVER use a charger not included or approved by GIO Electric NEVER touch the motor after use, it is hot NEVER ride the scooter while it is being transported via trailer, car lift etc...

  • Page 6: Assembly

    ASSEMBLY Each GIO Golf Enclosed Mobility Scooter arrives 95% assembled and requires the following to complete it. We strongly recommend 2 people for assembly, as certain components are large and will be more easily attached with support from a second person. Please note scooters ship with the parking brake engaged and will not operate or move until released.
  • Page 7 Step 3 - Bumpers Bumpers attach to mounting plates located on either side of the body at the front and rear. Front mounts are visible just in front of the front wheels through the wheel well, rear mounts are either visible below the body or from above through the access provided before the bench is installed.
  • Page 8 ASSEMBLY continued… Step 4 - Drip Guards The clear plastic drip guards are installed just above the seam where the top of the door meets the body. They are there to minimize water reaching that seam. Clean the surface with warm soapy water for best results. Carefully remove the backing on the adhesive strip and apply the guard to the vehicle ensuring to allow space for the door to open.
  • Page 9 Remove the charging port access panel (the small rectangular panel on the back wall just at the base of the bench) and ensure that the wires on either side of the breaker are snug. Replace the panel. Ensure that the connections on each battery cell are screwed in tight.

  • Page 10: Scooter Operation

    SCOOTER OPERATION Turning the Scooter ON/OFF To turn the scooter on, insert the key into the ignition located on the console below the handlebars and turn clockwise. To turn the scooter off, turn the key counterclockwise from the on position. The scooter can also be turned on remotely with the included fob.
  • Page 11 To slow/stop the scooter, release the throttle and squeeze brake levers. Always apply both brakes, especially when traveling at higher speeds. Please note the motor cut-out function of the scooter will automatically deactivate the motor when brakes are applied to prevent motor wear. ⚠...
  • Page 12 SCOOTER OPERATION continued… The brake handle also features a parking brake option. Once stopped squeeze the brake lever fully and while still holding in place, press up on the small parking brake lever to rotate the catch into place. To release the parking brake simply squeeze the brake handle again to release the spring- mounted catch.
  • Page 13 Right Side Controls: The 3-position horizontal black switch controls the scooter’s lights: ☼ All lights including the headlight ON > < Daytime signal & running lights only DⱭ ○ All lights OFF Left Side Controls: The upper switch adjusts the intensity of the headlight when it is active. Low beam and high beam.
  • Page 14 SCOOTER OPERATION continued… Media Center Located on the left lower portion of the console, the media center panel features all the buttons to operate the scooters sound and video system. Power Button - Toggle Media Center On/Off ⏭ Skip forward, Long Press Seek forward / FM Frequency Up(Radio) ⏮...
  • Page 15 PLEASE NOTE THE SMALL SCREEN ON THE MEDIA CONTROL PANEL ITSELF IS BYPASSED AND INFORMATION IS DISPLAYED VIA THE LCD DISPLAY. SEE #5 BELOW FOR LOCATION LCD Display Battery Level - includes state of charge % and current battery ❶ voltage Trip Odometer (km) - resets when the scooter shuts down ❷...
  • Page 16 SCOOTER OPERATION continued… Charging the Scooter This scooter requires a full charge before its first use. To maintain the batteries, charge the scooter after each use and do not allow the battery to fully empty. Locate the charging port behind the plastic flap on the outside rear body below the window.

  • Page 17: Maintenance & Care

    MAINTENANCE & CARE The GIO Golf requires minimal maintenance which can be performed by most users, a friend or family member, or a scooter technician. Visually inspect regularly for signs of damage, especially after collisions/accidents. ⚠ TO ENSURE SAFETY AND RELIABILITY, DO NOT MODIFY THIS SCOOTER &...
  • Page 18 MAINTENANCE & CARE continued… Battery Care ⚠ ALWAYS CHARGE THE BATTERY WITH THE INCLUDED CHARGER, DO NOT SUBSTITUTE WITH A DIFFERENT CHARGER. FOR BEST PERFORMANCE, CHARGE AFTER USE AND AVOID COMPLETELY DRAINING THE BATTERY BY RECHARGING IT BEFORE THE METER REACHES ZERO.
  • Page 19 If there is a cut or greater damage to the tire(s), replacement parts are available to order, please contact GIO customer service or the dealer it was purchased from. Please refer to tire markings for max recommended PSI.

  • Page 20: Specifications & Troubleshooting

    SPECIFICATIONS & TROUBLESHOOTING Specifications Motor: 1200 Watts Ground Clearance: 13cm (5") Battery: 60v 45ah lead acid Dimensions: 198x98x155cm Brakes: Front Disc/Rear Drum (79” x 39” x 62”) Tires: 10 x 4.00 Tubeless Tires Interior Measurements 93x78x120cm Top Speed: 25km/h (18.5mph) (37”...
  • Page 21 Issue Possible Cause Solution Noise coming from Defective or damaged motor Replace motor motor Scooter powers off Breaker tripped Allow scooter to rest and reset suddenly breaker Voltage too low Recharge battery Scooter doesn’t Throttle is defective Replace throttle decelerate when Controller is defective Replace controller throttle released...
  • Page 22 ATTENTION Please note that this model currently features a yet-to-be-utilized auxiliary connection located near the upper right corner of the windshield. As there is currently no accessory available for this connection no item is missing from the scooter, it should be the connection alone.

  • Page 23: Warranty Information

    The limited warranty as contained herein is exclusive and in lieu of all other warranties expressed or implied. There are no warranties that extend beyond the description in this limited warranty. GIO Electric guarantees this product, including the charger, motor, and controller, to be free of manufacturing defects for a period of 12 months.
