- Page 2 ⚠ SAFETY INFORMATION ⚠ Please note the following information to ensure your safety and get better use out of your GIO Titan Premium (Titan PR for short) Long Range Mobility Scooter Please read the manual prior to first use and do not permit anyone who hasn’t, operate the vehicle.
- Page 3 Table of Contents Riding Safety Overview Scooter Assembly Scooter & Control Diagrams Operating & Adjusting Your Scooter Maintenance & Care Specifications & Troubleshooting Warranty Information Riding Safety ALWAYS wear an approved helmet when riding your scooter ALWAYS steer with both hands ALWAYS drive with caution at appropriate speeds ALWAYS use your scooters turn signals and horn ALWAYS obey local traffic laws...
- Page 4 Overview Thank you for your purchase of the GIO Electric Titan PR Long Range Mobility Scooter. It is an easy to operate mobility scooter designed for indoor and outdoor use. This stylish recreational mobility scooter doesn’t require any licensing, registration or insurance. (unless required locally)
- Page 5 Riding Poncho Security Lock Windshield Kit (Optional Installation) Step 2 - Installing the Basket First attach the top to the basket body with the provided hardware. Once attached, locate the premade holes located in the back side of the seat and mount the basket as a whole.
- Page 6 Step 3 - Installing the mirrors Insert the mirrors into the mounting points above the controls and tighten into place. (If adding the optional windshield, install in step 6 instead) Step 4 - Turning on the breaker Your scooter ships with the breaker in the off position. Open the underseat compartment to find the breaker inset in the compartment liner next to the latch.
- Page 7 Step 5 - Charging Charge your battery for the first time - Your scooter does not arrive fully charged and will need charging before it is ready to drive. See instructions for charging on page #. Step 6 - (Optional Installation) Windshield The Titan PR includes the previously separate windshield kit at no extra cost.
- Page 8 You can now begin mounting it to the scooter. Locate the 2 metal mounting clips. Remove each mirror, place the mounting clip over top of the hole the mirror slots into, extending the clip towards the driver. Reinsert each mirror through the mounting clip into its mounting hole and loosely tighten for now.
- Page 9 Next slide one of those threaded supports into the receiving channel on the metal mounting clips you just installed. Carefully flex the windshield to allow the other threaded support to be guided into the metal mounting clip on the opposite side. With the windshield now in place add the 2 remaining nuts to the ends of the threaded part of the support.
- Page 10 Scooter Diagram Mirrors Armrests (flip up) Headlight Seat adjustment levers Front turn signal lights Basket Front wheel & fender Underseat compartment Front fork & brakes Battery & Controller (internal) Handlebar, controls, display Rear turn signal lights Ignition Rear brakes & wheels Covered charging port Motor (internal) Seat &...
- Page 11 Control Diagrams Rear brake lever Bag hook Parking brake pin Front brake lever Headlight level switch Twist grip throttle Turn signal switch 3 speed switch Horn button Caution/brake light switch USB power port Light control master switch Coin/cup holder Reverse/neutral/drive switch LCD display (see below) Ignition Left turn indicator...
- Page 12 Operating & Adjusting your Scooter Turning your Scooter ON/OFF To turn the scooter on, insert the key and turn clockwise. To turn your scooter off, turn the key counterclockwise from the on position. The LCD display should activate and “Ready” light illuminate indicating the scooter is on and ready to ride.
- Page 13 Your scooter features control switches next to the throttle grip that adjust driving features. The lower switch labeled RND sets the scooter into reverse, neutral or forward drive. The red switch labeled 1-3 sets the current speed setting of the forward drive when in use. Bring your scooter to a complete stop before switching between forward, neutral and reverse.
- Page 14 Remote fob and alarm system The GIO Titan PR features an alarm system that is controlled with the included fob. This fob can also be used to turn the scooter on and off remotely. To turn on the scooter, press the center power button ( ) on the ⚡...
- Page 15 Charger may become warm or emit a noise while active. If charging does not complete after 12 hours please contact GIO Technical Support. ⚠ Your scooter will only charge and operate with the breaker in the ON position! Do not touch the charger or connections with wet hands! ⚠...
- Page 16 Storage on your Scooter Your scooter comes complete with several storage options. The largest being the basket on the seat located on the back of the seat. There is a bag hook located just below the LCD screen, perfect for shopping bags or a purse.
- Page 17 ⚠ To ensure the safety and reliability of your scooter, do not modify your scooter, and always use parts, i.e. charger, specifically designed for the GIO Tron. Alway make sure your scooter is turned off before performing any maintenance! ⚠...
- Page 18 0° to 40°C (32° to 104°F) Avoid dropping your charger. Always disconnect by gripping plugs directly, do not tug on wires. Do not disassemble or attempt to repair a damaged battery or charger, contact GIO customer service to order replacement parts.
- Page 19 In the event you see decreased brake performance or your brakes feel spongy when applied please contact GIO Technical Support or seek out a local service provider qualified to maintain hydraulic brakes.
- Page 20 Cleaning To clean your scooter use a damp cloth with a neutral soap to wipe clean surfaces. Avoid high pressure or excess water as this may cause corrosion or shorts in electrical components. Specifications & Troubleshooting Specifications Motor: Rear differential 48v 500w Battery: 48v 20ah lead acid Brakes:...
- Page 21 Troubleshooting Issue Possible Cause Solution Battery gauge Loose connection near the Check connections, doesn’t register power switch or battery tighten loose connections anything when, pack. scooter is ON Battery is completely Charge battery discharged. Check connections near Scooter turns ON Motor wire is loose or the motor, tighten loose and has battery...
- Page 22 Charger overheating and Check or replace charger shutting off prematurely Charger doesn’t Battery or charger issue Discontinue use, contact complete charging, GIO Technical Support light stays red continuously. Charger extremely Damaged charger Discontinue use, replace hot, emits odor, charger sparks etc The tips above are meant as a basic guide.
- Page 23 There are no warranties that extend beyond the description in this limited warranty. GIO Electric guarantees this product, including charger, motor, controller, to be free of manufacturing defects for a period of 12 months. All warranty periods commence from the date of shipment.
