Wireless Network

1. On first start, "No Network" will show
on the display. Tap on "OK" to dismiss
it to display the Time and Date.
2. Once the system is at the main Time
and Date screen, scan the Master
Badge through the barcode reader
on the right side of the system, then
type in the PIN using the on-screen
keyboard.
3. Make sure that the bar code is facing
to the left when scanning the Master
Badge through the barcode reader.
The Master Badge PIN is listed
on the inside flap of the small
envelope containing the Master
Badge.
If you cannot locate the Master Badge, or if you have any issues logging in with the Master
Badge, please call Technical Support for assistance at 1-888-458-9994.
