Insert the Key Panels
The panels should be placed in alphabetical order from front to back in the cabinet
(AB/CD). Insert the top panel mounting pin in to a hole on the top key panel mounting
bracket. Lift the panel up and pivot the bottom mounting pin into the corresponding hole
in the bottom bracket. Do not remove the tags from the hooks.
NOTE: Your warranty will be voided if
a UPS battery backup is not installed.
1. Plug the HandyTrac Primary Touch
power cable into a UPS Battery Backup.
Be sure the HandyTrac Touch System is
connected to a plug that includes both
Battery Backup and Surge Protection.
HandyTrac Touch
User Guide
6
