POWERING A SMARTER WORLD
FacePass 7 Pro
FacePass 7 Pro
Smart Face Recognition and Inf rared
Thermal Temperature Detection Terminal
Quick Guide
Anviz brand and product are trademarked and protected under law of the United States.
Unauthorized use is prohibited.
For more information visit www.anviz.com, or email marketing@anviz.com for further help.
©2021 Anviz Global Inc. All Rights Reserved.
V1.0
IRT
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Anviz FacePass 7 Pro
Summary of Contents for Anviz FacePass 7 Pro
- Page 1 Thermal Temperature Detection Terminal Quick Guide V1.0 Anviz brand and product are trademarked and protected under law of the United States. Unauthorized use is prohibited. For more information visit www.anviz.com, or email marketing@anviz.com for further help. ©2021 Anviz Global Inc. All Rights Reserved.
- Page 2 Temperature and face recognition: 1. Keep the face in the purple frame. The red frame implies device has identified face. 3. The yellow frame represents temperature recognition process. 4. The green frame means face enrollment is successful. (Only the FacePass 7 Pro IRT has this function) 8010 8010...
-
Page 3: Recommended Installation Environment
The recommended face recognition distance is 30-80cm(11.81-31.50"). The best ① adaptive angles are ±20° both horizontally and vertically. The recommended installation height is 1.1m(43.31"), where the FacePass 7 Pro ② can recognize enrolled faces from 1.3m(51.18")to 2.2m(86.61"). Please specify the... -
Page 4: Installation
4. Installation The Sunlight and Hard Light may lead to big differences between site image and registered image; backlight, side-light and strong light will influence the recognition experience. (Analysis: from the view of human eyes, the color changes on face skin may result in wrong recognition of identity;... -
Page 5: Installation Diagram
Installation Diagram: 2.2m (86’61”) 1.3m 1.1m (51’18”) 1.1m (43.31”) ( 43.31”) Floor 100cm Fig.(1) Installation Position (39.37”) ( Recommended Distance for Face Recognition) Step 2：Installation Steps Place the backplate at the ③ appropriate position and fix screws into the wall according to the mounting holes. -
Page 6: User Enroll
User Enroll Quick Face Registration 8010 Face in the circle Face enroll successfully. ID:8010 Enrolled Already exist 8010 - Sasha 8010 - Sasha 8010 - Sasha Lease center your face in the fram Lease center your face in the fram NEXT ②... - Page 7 To Import and Export the Lots of Face Photos of Users to be Enrolled with USB Disk To setup a new folder in the root directory of your usb stick, rename it ,eg. “Face” Select the Face photos to be imported and rename as the actual ID number, to save these photo files into the Folder of “Face “, eg.
-
Page 8: Communication Setting
Communication Setting PING FacePass 7 Pro Click“Network”option Click“Network\Comm Set Ethernet or WiFi IP address on a to enter network Mode”to select server parameters based on management setting page, then or client mode. your network computer to make select Ethernet or environment. - Page 9 Mask Recognition and Body Temperature Detection Setting Enter Mask Setting Page Enter the main page and click ‘Advanced’-> ‘Temperature’ to enter the Mask/Temperature setting page. Main Advanced Temperature Temp.Settings Mask Settings Enroll Face User T&A Application Data Network Verify Mode Settings Advanced Auto FN...
- Page 10 Please set the value to 10 times the normal temperature to avoid complex calculation with decimal points. For instance, if the actual alarm value is 37.3 ℃, the device setup value should be 373. (Also apply to Fahrenheit) (Only the FacePass 7 Pro IRT with this function) Temperature Temperature Work Mode...
-
Page 11: Switching Power Supply
Door Sensor Bell Power on to unlock 7. Wiring Type Access Controller SC011 and the FacePass 7 Pro device are authorized by Anviz wiegand to form a distributed access control system. Please contact sales@anviz.com for more information. Power off to unlock... - Page 12 Dropbox Google Anviz Before using all Anviz products, please read all applicable terms, rules, policies and usage provisions found at https://www.anviz.com/privacypolicy and https://www.anviz.com/anviz-biometric-data-retention-policy. By using your Anviz, you agree to be bound by the Anviz Privacy Policy. Anviz brand and product are trademarked and protected under law of the United States.
