- Page 1 M-Bio Portable Bluetooth Enabled Fingerprint & RFID Device Quick Guide v1.1 www.anviz.com...
-
Page 2: Package List
Package List M-Bio Portable Bluetooth Enabled Fingerprint & RFID Device Quick Guide v1.1 POWERING A SMARTER WORLD Device USB Cable Quick Guide RFID Card Notification: 1. Please check if the package contains all the items listed above. Contact the distributor if there is any problem. -
Page 3: Incorrect Method
Illustration for Placing Finger Correct Method ( Straighten your finger and then place it on the sensor Ensure the finger is flat and covers the entire sensor) Always place finger in the Try to place your finger center of the sensor. covers the entire sensor. - Page 4 DO NOT just use DO NOT slide your finger your fingertip. during the fingerpint verification process. Appearance Fingerprint Sensor OLED Screen RFID Reader Area...
- Page 5 Power Button Power Over USB Port WIFI AP Mode Date and Time Battery Bluetooth 2021 01 10 14:20:33 192.168.2.234...
- Page 6 Operation Guide IMPORTANT: M-Bio is suitable for USB 5V power supply only. Plug in the power the device will automatic power on. Register User: Add One Fingerprint per User Only: 4. Continue to register another user 1. Swipe 2. Place finger 3.
- Page 7 Blue LED Green LED lights and Sensor Blue LEDs up and display light up light up Save Successed Notice: During the device in the regsiter mode without any operation for 3 sec the M-bio will back to the normal mode.
- Page 8 Red and Blue Blue LED and Green LED lights LEDs Light FingerPrint sensor up and display lights up delete success Notice: During the device in the delete mode without any operation for 3 sec the M-bio will back to the normal mode.
- Page 9 Red and Blue Blue LED and Green LED lights LED Light FingerPrint sensor up and display lights up delete success Notice: When you swipe card on M-Bio, Red LED flashing with long beeps means the card does not exist in the device.
-
Page 10: Login Webserver
Login WebServer Login to M-bio Webserver to manage the device. 2021 01 10 M-bio is default with WIFI AP 14:20:33 192.168.2.1 funciton. Please connect M-Bio WIFI AP WIFI SSID: M-bio Default Password: 123456789 Login Web Server User Name Password Login Reset Please input the default address (192.168.2.234) - Page 11 Admin 0-User User User Name Felix Network Password ************* Base Setup Card Num Please Enter Advanced Identify Mode System default Select FP right_thumb Save Fill the employee's information and click "Fingerprint Enroll" to enroll user's finger on the M-Bio device.
- Page 12 +1-855-ANVIZ4U | +1-855-268-4948 MON-FRI 5AM-5PM Pacific Email support@anviz.com 24 Hours Answer Text +1-408-837-7536 MON-FRI 5AM-5PM Pacific Community Join community.anviz.com if you have any question or suggestion to share Scan and download software CrossChex CrossChex Mobile App Standard Google Drive Anviz Drive...
