PRO SMART MAGNETIC ELLIPTICAL
TRAINER WITH 16 INCHES STRIDE
SF-E323038
USER MANUAL
IMPORTANT! Please retain owner's manual for maintenance and adjustment instructions. Your
satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED
US: support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669).
IMPORTANT SAFETY INFORMATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-E323038 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunny Health & Fitness SF-E323038

Summary of Contents for Sunny Health & Fitness SF-E323038

  • Page 1 PRO SMART MAGNETIC ELLIPTICAL TRAINER WITH 16 INCHES STRIDE SF-E323038 USER MANUAL IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US: support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669).

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained, and used properly.

  • Page 3: Pre-Assembly Check List

    PRE-ASSEMBLY CHECK LIST Before you start to assemble, please make sure all parts are included Description Spec. Description Spec. Main Frame Left Decorative Cover Handle Tube Right Decorative Cover Front Stabilizer Computer Middle Handlebar Bottle Holder Left Handlebar PTFE Lubricant Right Handlebar Hardware Package Pedal...

  • Page 4: Hardware Package

    HARDWARE PACKAGE Ordering Replacement Parts (U.S. and Canadian Customers only) Please provide the following information in order for us to accurately identify the part(s) needed:  The model number (found on cover of manual)  The product name (found on cover of manual) ...
  • Page 5 ASSEMBLY INSTRUCTIONS We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 1: Follow the direction of the arrow shown in the picture, Lift the Front Post (No. 2). STEP 2: Attach the Front Post (No.
  • Page 6 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 3: Attach the 2 Adjustable Pads (No. 51) into the Front Stabilizer (No. 4) by hand. Remove 2 Bolts (No.
  • Page 7 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 5: Remove 8 Screws (No. 48) from the ends of Left/Right Foot Tube Connect Patches (No.
  • Page 8 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 7: Attach the Left Handlebar (No. 12) onto the Left Swing Tube (No. 5) with 2 Bolts (No.
  • Page 9 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 9: Remove 4 Bolts (No. 74) from the back of the Computer (No. 73) with the Spanner (No.
  • Page 10 ADJUSTMENTS GUIDE MOVING THE ELLIPTICAL Hold the Handle Tube (No. 3) and pull upward to lift the rear of the elliptical off the floor until the Transportation Wheels (No. 57) on the Front Stabilizer (No. 4) touch the ground. Now you can move the elliptical with ease.

  • Page 11: Battery Installation And Replacement

    BATTERY INSTALLATION & REPLACEMENT BATTERY INSTALLATION 1. Take out 2 AA batteries from computer box. 2. Press the buckle of battery cover on the Computer (No. 73), then remove battery cover. 3. Install 2 AA batteries into the battery case on the back of the Computer (No. 73). Pay attention to the battery + and –...

  • Page 12: Exercise Computer

    EXERCISE COMPUTER BLUETOOTH 1. The Bluetooth icon will flash when the meter is on or wakes from sleep mode. If no Bluetooth connection is established within 3 minutes, the Bluetooth icon will turn off. 2. The Bluetooth icon will stay on when it is connected. WIRELESS HEART RATE 1.

  • Page 13: Function Buttons

    FUNCTION BUTTONS MODE: 1. Press the button to select TIME, DISTANCE, CALORIES and PULSE to preset. 2. Press the button for selection function display on main LCD, or enter after setting. 3. Hold the MODE button for 2 seconds to reset all values except ODO when the Bluetooth is not connected.

  • Page 14: Operation Order

    OPERATION ORDER: 1. Power on – Installs 2 pieces of 1.5V UM-3 or AA batteries. The computer start to segment test with a long beep sound. (Whenever batteries are removed, all the functions values will be reset to zero or default value.) 2.

  • Page 15: App Connection

    APP CONNECTION: Connect Smart Equipment to SunnyFit App: 1. Scan to download SunnyFit from the app store: 2. Ensure that the Bluetooth function is turned on from your mobile device. 3. If this is your first time using the SunnyFit app, follow the in-app instructions to register for your free SunnyFit account and log in.

  • Page 16: Exploded Diagram

    EXPLODED DIAGRAM 1...
  • Page 17 EXPLODED DIAGRAM 2...

  • Page 18: Parts List

    PARTS LIST Description Spec. Description Spec. Main Frame Big Washer Ф13*Ф24*2.0 Front Post Handle Tube Front Stabilizer Pedal Left Swing Tube Bolt M8*25 Right Swing Tube Bolt M8*20 Left Foot Bar Plastic Bushing Right Foot Bar Big Washer Ф20*Ф8*2.0 Left Foot Tube Connect Roller Connecting Patch Shaft...
  • Page 19 Description Spec. Description Spec. Magnetic Plate Axle Foam Grip Ф24*Ф30*180 Magnetic Bracket Hand Pulse Sensor Magnet Seat Hand Pulse Sensor Magnet 40*25*10MM Wire Plug Φ12.1 Screw ST2.9*9 Computer TZ-2190 Spring Computer Wire Bolt M6*45 Bolt M5*10 C-clip Φ20*1 Flywheel Ф240 Bearing 6004ZZ Bearing Seat...
