  • Page 1 Thermal Network Camera User Manual...

  • Page 2: About This Manual

    Thermal Network Camera User Manual Legal Information About this Manual The Manual includes instructions for using and managing the Product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 Thermal Network Camera User Manual IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER PREVAILS.

  • Page 4: Symbol Conventions

    Thermal Network Camera User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could Caution result in equipment damage, data loss, performance degradation, or...

  • Page 5: Safety Instruction

    Thermal Network Camera User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. Laws and Regulations In the use of the product, you must be in strict compliance with the electrical safety regulations ●...

  • Page 6: Installation

    Thermal Network Camera User Manual Please purchase the charger by yourself. Input voltage should meet the Limited Power Source ● (12 VDC, 24 VAC, or PoE(802.3af)) according to the IEC62368 standard. Please refer to technical specifications for detailed information. Make sure the plug is properly connected to the power socket. ●...

  • Page 7: System Security

    Thermal Network Camera User Manual The interface varies with the models. Please refer to the product datasheet for details. ● If the device needs to be wired by yourself, select the corresponding wire to supply power ● according to the electric parameters labeled on the device. Strip off wire with a standard wire stripper at corresponding position.
  • Page 8 Thermal Network Camera User Manual The openings shall never be blocked by placing the device on a bed, sofa, rug, or other similar surface. Keep a proper distance around the device for sufficient ventilation. ● This device is suitable for mounting on concrete or other non-combustible surface only to avoid ●...

  • Page 9: Table Of Contents

    Thermal Network Camera User Manual Contents Chapter 1 Overview ........................1 1.1 Brief Description ........................1 1.2 Function ..........................1 Chapter 2 Device Activation and Accessing ................. 2 2.1 Activate Device ........................2 2.1.1 Activate the Device via Browser ..................2 2.1.2 Activate the Device via SADP ..................
  • Page 10 Thermal Network Camera User Manual 3.13 Set SRTP ..........................13 3.14 Modbus Communication ....................13 3.14.1 Set Modbus Main Mode ................... 13 3.14.2 Set Modbus Subordinate Mode ................16 3.14.3 Modbus Error Code Description ................16 3.15 Operate via Mobile Client ....................18 3.15.1 Enable Guarding Vision Service on Camera ..............
  • Page 11 Thermal Network Camera User Manual 5.1.3 Resolution ........................25 5.1.4 Bitrate Type and Max. Bitrate ..................26 5.1.5 Video Quality ......................26 5.1.6 Frame Rate ........................26 5.1.7 Video Encoding ......................26 5.1.8 Smoothing ........................28 5.1.9 Display VCA Info ......................28 5.1.10 Audio Settings ......................
  • Page 12 Thermal Network Camera User Manual 5.5 Set Privacy Mask ........................34 5.6 Overlay Picture ........................35 5.7 Set Manual DPC (Defective Pixel Correction) ............... 35 Chapter 6 Video Recording and Picture Capture ................ 36 6.1 Storage Settings ........................36 6.1.1 Set Memory Card ......................36 6.1.2 Set NAS ........................
  • Page 13 Thermal Network Camera User Manual 7.3 Perimeter Protection ......................55 7.3.1 Set Perimeter Protection Rules ................... 56 7.3.2 Set Perimeter Protection Shield Region ..............58 7.3.3 Set Overlay & Capture Parameters ................58 7.3.4 Calibration ........................59 7.3.5 Set Advanced Configuration Parameters ..............61 Chapter 8 Event and Alarm .......................
  • Page 14 Thermal Network Camera User Manual 10.3 Import and Export Configuration File ................72 10.4 Export Diagnose Information ..................... 73 10.5 Reboot ..........................73 10.6 Device Auto Maintenance ....................73 10.7 Restore and Default ......................73 10.8 Upgrade ..........................74 10.9 View Open Source Software License .................. 74 10.10 Time and Date ........................
  • Page 15 Thermal Network Camera User Manual Chapter 11 Appendix ........................ 85 11.1 Common Material Emissivity Reference ................85...

  • Page 16: Chapter 1 Overview

    Thermal Network Camera User Manual Chapter 1 Overview 1.1 Brief Description Thermal network camera equipped with built-in GPU which supports intelligent perimeter protection algorithm, can realize high-precision VCA detection and real-time alarm. It is applied to perimeter protection and fire-prevention purposes in critical infrastructures such as community, villa, construction site, factory, 4S stores, and so on.

  • Page 17: Chapter 2 Device Activation And Accessing

    Thermal Network Camera User Manual Chapter 2 Device Activation and Accessing To protect the security and privacy of the user account and data, you should set a login password to activate the device when access the device via network. Note Refer to the user manual of the software client for the detailed information about the client software activation.

  • Page 18: Activate The Device Via Sadp

    Thermal Network Camera User Manual 2.1.2 Activate the Device via SADP Search and activate the online devices via SADP software. Before You Start Get SADP software from the official website to install. Steps 1. Connect your computer to the same Wi-Fi network that the device is in. 2.

  • Page 19: Illegal Login Lock

    Thermal Network Camera User Manual Operating System Web Browser Operation → Network Service to enable WebSocket or WebSockets for normal view if plug-in installation is not required. Display and operation of certain functions are restricted. For example, Playback and Picture are not available. For detailed restricted function, refer to the actual device.

  • Page 20: Chapter 3 Network Settings

    Thermal Network Camera User Manual Chapter 3 Network Settings 3.1 TCP/IP TCP/IP settings must be properly configured before you operate the device over network. IPv4 and IPv6 are both supported. Both versions can be configured simultaneously without conflicting to each other. Go to Configuration →...

  • Page 21: Multicast Discovery

    Thermal Network Camera User Manual Input IPv6 Address, IPv6 Subnet, IPv6 Default Gateway. Consult the network administrator for required information. It stands for maximum transmission unit. It is the size of the largest protocol data unit that can be communicated in a single network layer transaction. The valid value range of MTU is 1280 to 1500.

  • Page 22: Port Mapping

    Thermal Network Camera User Manual It refers to the port of real-time streaming protocol. SRTP Port It refers to the port of secure real-time transport protocol. Server Port It refers to the port through which the client adds the device. WebSocket Port TCP-based full-duplex communication protocol port for plug-in free preview.

  • Page 23: Set Manual Port Mapping

    Thermal Network Camera User Manual 2. Select the port mapping mode to Auto. 3. Click Save. Note UPnP™ function on the router should be enabled at the same time. 3.3.2 Set Manual Port Mapping Steps 1. Check Enable UPnP™, and choose a friendly name for the device, or you can use the default name.

  • Page 24: Snmp

    Thermal Network Camera User Manual 3.5 SNMP You can set the SNMP network management protocol to get the alarm event and exception messages in network transmission. Before You Start Before setting the SNMP, you should download the SNMP software and manage to receive the device information via SNMP port.

  • Page 25: Access To Device Via Pppoe Dial Up Connection

    Thermal Network Camera User Manual By Client Software Add domain name to the client software. Refer to the client manual for specific adding methods. 3.7 Access to Device via PPPoE Dial Up Connection This device supports the PPPoE auto dial-up function. The device gets a public IP address by ADSL dial-up after the device is connected to a modem.

  • Page 26: Set Open Network Video Interface

    Thermal Network Camera User Manual Steps 1. Go to Configuration → Network → Advanced Settings → Platform Access . 2. Select ISUP as the platform access mode. 3. Select Enable. 4. Select a protocol version and input related parameters. 5. Click Save. Register status turns to Online when the function is correctly set.

  • Page 27: Set Alarm Server

    Thermal Network Camera User Manual 3.11 Set Alarm Server The device can send alarms to destination IP address or host name through HTTP, HTTPS, or ISUP protocol. The destination IP address or host name should support HTTP, HTTP, or ISUP data transmission.

  • Page 28: Set Srtp

    Thermal Network Camera User Manual 3.13 Set SRTP The Secure Real-time Transport Protocol (SRTP) is a Real-time Transport Protocol (RTP) internet protocol, intended to provide encryption, message authentication and integrity, and replay attack protection to the RTP data in both unicast and multicast applications. Steps 1.
  • Page 29 Thermal Network Camera User Manual Figure 3-1 Main Mode Configuration 2. Check to enable the function of transmitting data via Modbus. 3. Click Add to configure the transmission parameters between the device and the subordinate. Subordinate Name Customized subordinate for distinguishing between different subordinates. Connection type Note Only when System →...
  • Page 30 Thermal Network Camera User Manual Note If the connection status displays online, the device is connected to the subordinate normally; ● if it displays offline, the device is disconnected from the subordinate, which may be caused by the subordinate not being online. If the status shows Error, refer to the contents of the error code description below to diagnose the connection problem.

  • Page 31: Set Modbus Subordinate Mode

    Thermal Network Camera User Manual 3.14.2 Set Modbus Subordinate Mode Configure the device as the subordinate server, the main can read the temperature measurement data of the device or write the temperature measurement parameters of the device. The form of authorized access can improve data communication security.
  • Page 32 Thermal Network Camera User Manual Error Code Name Description unconfigured and is being asked to return register values. Illegal Data Address The data address received in the query is not an allowable address for the server. More specifically, the combination of reference number and transfer length is invalid.

  • Page 33: Operate Via Mobile Client

    Thermal Network Camera User Manual Error Code Name Description Memory Parity Error Specialized use in conjunction with function codes 20 and 21 and reference type 6, to indicate that the extended file area failed to pass a consistency check. The server attempted to read record file, but detected a parity error in the memory.

  • Page 34: Set Up Guarding Vision

    Thermal Network Camera User Manual 2. Enter platform access configuration interface. Configuration → Network → Advanced Settings → Platform Access 3. Select Guarding Vision as the Platform Access Mode. 4. Check Enable. 5. Click and read "Terms of Service" and "Privacy Policy" in pop-up window. 6.
  • Page 35 Thermal Network Camera User Manual 4. Scan the QR code on camera body or on the Quick Start Guide cover. Note If the QR code is missing or too blur to be recognized, you can also add the camera by inputting the camera's serial number.

  • Page 36: Chapter 4 Live View

    Thermal Network Camera User Manual Chapter 4 Live View It introduces the live view parameters, function icons and transmission parameters settings. 4.1 Live View Parameters The supported functions vary depending on the model. 4.1.1 Window Proportion refers to the window size is 16 : 9. ●...

  • Page 37: View Previous/Next Page

    Thermal Network Camera User Manual 4.1.5 View Previous/Next Page When the number of channels surpasses that of live view window division, this function can switch live view among multiple channels. Click to switch live view among multiple channels. 4.1.6 Full Screen This function is used to view the image in full screen mode.

  • Page 38: Lens Parameters Adjustment

    Thermal Network Camera User Manual - For PTZ settings, see Lens Parameters Adjustment . - For display settings, see Display Settings . - For OSD settings, see OSD . - For audio and video settings, see Video and Image Settings . - For VCA settings, see Fire Detection , Temperature Measurement , and Perimeter Protection .
  • Page 39 Thermal Network Camera User Manual UDP is suitable for the unstable network environment that does not demand high video fluency. MULTICAST MULTICAST is suitable for the situation that there are multiple clients. You should set the multicast address for them before selection. Note For detailed information about multicast, refer to Multicast .

  • Page 40: Chapter 5 Video And Image Settings

    Thermal Network Camera User Manual Chapter 5 Video and Image Settings This part introduces the configuration of video/audio and image related parameters. 5.1 Video Settings This part introduces the settings of video parameters, such as, stream type, video encoding, and resolution.

  • Page 41: Bitrate Type And Max. Bitrate

    Thermal Network Camera User Manual 5.1.4 Bitrate Type and Max. Bitrate Constant Bitrate It means that the stream is compressed and transmitted at a comparatively fixed bitrate. The compression speed is fast, but mosaic may occur on the image. Variable Bitrate It means that the device automatically adjust the bitrate under the set Max.

  • Page 42: I-Frame Interval

    Thermal Network Camera User Manual H.265 H.265, also known as High Efficiency Video Coding (HEVC) and MPEG-H Part 2, is a compression standard. In comparison to H.264, it offers better video compression at the same resolution, frame rate and image quality. MJPEG Motion JPEG (M-JPEG or MJPEG) is a video compression format in which intraframe coding technology is used.

  • Page 43: Smoothing

    Thermal Network Camera User Manual 5.1.8 Smoothing It refers to the smoothness of the stream. The higher value of the smoothing is, the better fluency of the stream will be, though, the video quality may not be so satisfactory. The lower value of the smoothing is, the higher quality of the stream will be, though it may appear not fluent.

  • Page 44: Two-Way Audio

    Thermal Network Camera User Manual LineIn Set Audio Input to LineIn when the device connects to the audio input device with the high output power, such as MP3, synthesizer or active pickup. MicIn Set Audio Input to MicIn when the device connects to the audio input device with the low output power, such as microphone or passive pickup.

  • Page 45: Metadata

    Thermal Network Camera User Manual Steps 1. Go to Configuration → Video/Audio → ROI . 2. Check Enable. 3. Select Stream Type. 4. Select Region No. in Fixed Region to draw ROI region. 1) Click Draw Area. 2) Click and drag the mouse on the view screen to draw the fixed region. 3) Click Stop Drawing.

  • Page 46: Dnr

    Thermal Network Camera User Manual Manual Correction Click DPC (Defective Pixel Correction) to optimize the image once. Note It is a normal phenomenon that short video freezing might occur during the process of Manual Correction. Thermal AGC Mode Choose the AGC mode according to different scenes to balance and improve the image quality. Histogram: Choose for scene with obvious WDR and high temperature difference, can ●...

  • Page 47: Set Target Enhancement

    Thermal Network Camera User Manual 5.2.5 Set Target Enhancement You can set the color of the targets in different temperature ranges to identify the target quickly. Steps 1. Go to Configuration → Image → Display Settings . 2. Click Image Enhancement, select Palette as White Hot or Black Hot. 3.

  • Page 48: Enhance Regional Image

    Thermal Network Camera User Manual 5.2.9 Enhance Regional Image You can select the desired area of image to improve the coding quality. The regional image will be more detailed and clear. Steps 1. Go to Configuration → Image → Display Settings → Image Enhancement . 2.

  • Page 49: Osd

    Thermal Network Camera User Manual Some camera models support CVBS, SDI, or HDMI output. Set the local output ON or OFF according to the actual device.This is the start of your concept. 5.3 OSD You can customize OSD (On-screen Display) information such as device name, time/date, font, color, and text overlay displayed on video stream.

  • Page 50: Overlay Picture

    Thermal Network Camera User Manual 5. Click Save. 5.6 Overlay Picture Overlay a customized picture on live view. Before You Start The picture to overlay has to be in BMP format with 24-bit, and the maximum picture size is 128 × 128 pixel.

  • Page 51: Chapter 6 Video Recording And Picture Capture

    Thermal Network Camera User Manual Chapter 6 Video Recording and Picture Capture This part introduces the operations of capturing video clips and snapshots, playback, and downloading captured files. 6.1 Storage Settings This part introduces the configuration of several common storage paths. 6.1.1 Set Memory Card If you choose to store the files to memory card, make sure you insert and format the memory card in advance.

  • Page 52: Set Ftp

    Thermal Network Camera User Manual Steps 1. Go to NAS setting page: Configuration → Storage → Storage Management → Net HDD . 2. Click HDD No.. Enter the server address and file path for the disk. Server Address The IP address of the network disk. File Path The saving path of network disk files.

  • Page 53: Set Cloud Storage

    Thermal Network Camera User Manual 4. Click Test to verify the FTP server. 5. Click Save. 6.1.4 Set Cloud Storage It helps to upload the captured pictures and data to the cloud. The platform requests picture directly from the cloud for picture and analysis. The function is only supported by certain models. Steps Caution If the cloud storage is enabled, the pictures are stored in the cloud video manager firstly.
  • Page 54 Thermal Network Camera User Manual Before You Start Select Trigger Recording in event settings for each record type except Continuous. See Event and Alarm for details. Steps Note The function varies according to different models. 1. Go to Configuration → Storage → Schedule Settings → Record Schedule . 2.

  • Page 55: Record Manually

    Thermal Network Camera User Manual Post-record The time period you set to stop recording after the scheduled time. Stream Type Select the stream type for recording. Note When you select the stream type with higher bitrate, the actual time of the pre-record and post-record may be less than the set value.

  • Page 56: Capture Configuration

    Thermal Network Camera User Manual Note Go to Configuration → Local , click Save downloaded files to to change the saving path of downloaded video files. 6.3 Capture Configuration The device can capture the pictures manually or automatically and save them in configured saving path.

  • Page 57: View And Download Picture

    Thermal Network Camera User Manual 6.3.3 View and Download Picture You can search, view and download the pictures stored in the local storage or network storage. Steps 1. Click Picture. 2. Set search condition and click Search. The matched pictures showed in the file list. 3.

  • Page 58: Chapter 7 Vca Resource

    Thermal Network Camera User Manual Chapter 7 VCA Resource VCA resource is a collection of smart functions supported by the device. 7.1 Temperature Measurement When you enable this function, the device measures the actual temperature of the scene. It alarms when temperature exceeds the temperature threshold value.
  • Page 59 Thermal Network Camera User Manual Figure 7-1 Thermography Configuration Flow Chart...

  • Page 60: Automatic Thermography

    Thermal Network Camera User Manual Note Please refer to the Quick Start Guide for detailed information of Installation part in the flow chart. 7.1.3 Automatic Thermography Configure the temperature measurement parameters and temperature measurement rules. The device can measure the actual temperature and output alarms when temperature exceeds the alarm threshold value.
  • Page 61 Thermal Network Camera User Manual Top Left Display the information on the top left of screen. Picture Quality Set picture quality as high, medium, or low. Unit Display temperature with Degree Celsius (°C)/Degree Fahrenheit (°F)/Degree Kelvin (K). Temperature Range Select the temperature measurement range. The device can adjust the temperature range automatically if you select Auto.
  • Page 62 Thermal Network Camera User Manual Enable this function when there are forklifts or high temperature moving objects, or it may cause false alarm. You can select the filter level to filter out different kinds of objects and set the filtering temperature. Smoking Filter Enable this function to filter out high temperature alarms triggered by smoking.
  • Page 63 Thermal Network Camera User Manual Temperature Sudden Change Alarm When the temperature change exceeds the set sudden change alarm value within the set cycle, the camera triggers an alarm. Note Temperature sudden change alarm is only supported by certain device models. 5.
  • Page 64 Thermal Network Camera User Manual Set Expert Mode Select the temperature measurement rules from Point, Line, or Area and configure parameters, the device alarms if the alarm rules are met. Steps 1. Go to Configuration → Temperature Measurement & Fire Prevention → Basic Settings , check Enable Temperature Measurement.
  • Page 65 Thermal Network Camera User Manual If there is any object with high emissivity in the scene, check and set the reflective temperature to correct the temperature. The reflective temperature should be set the same as the temperature of the high emissivity object. 4.
  • Page 66 Thermal Network Camera User Manual Note The same parameters and linkage method apply to the two kinds of pre-alarm/alarm, only the threshold temperature and arming schedule vary. Offsite Pre-Alarm Temperature When the temperature of target exceeds the Offsite Pre-Alarm Temperature during the Offsite Arming Schedule, and this status lasts not shorter than the Filtering Time, the pre- alarm is triggered.

  • Page 67: Manual Thermography

    Thermal Network Camera User Manual Area Thermography Configure the temperature measurement rule and monitor the maximum temperature of the area. Steps 1. Click and drag the mouse in the live view to draw the area and right click to finish drawing. 2.

  • Page 68: Fire Detection

    Thermal Network Camera User Manual Steps 1. Access Configuration → System → System Maintenance → Diagnosis Information Collection . 2. Check Add Original Data on Capture to overlay the raw device data on the temperature alarm capture. 3. Check Add Original Data on Stream to overlay the raw data in the corresponding video streams which can subsequently be downloaded along with the video files through the playback download function.

  • Page 69: Recommended Scene

    Thermal Network Camera User Manual Note Not all models support the function. Please take the actual product for reference. 7.2.1 Recommended Scene This part introduces the recommended scenes of fire source detection and helps you select the appropriate scene. Fire source detection can be applied to indoor and outdoor monitoring with a large detection radius.

  • Page 70: Set Detection Shield Region

    Thermal Network Camera User Manual Alarm Interval Set the alarm interval between two alarms. Picture Quality Set picture quality as high, medium, or low. Note When VCA Resource Type is selected as Temperature Measurement + Perimeter Protection, only Smoking Mode is supported in Fire Source Detection. When VCA Resource Type is selected as Temperature Measurement + Fire Detection, Dynamic Fire is also supported in Fire Source Detection.

  • Page 71: Set Perimeter Protection Rules

    Thermal Network Camera User Manual 7.3.1 Set Perimeter Protection Rules The device can detect whether there is any target breaking the perimeter protection rules. The device will alarm when the rule is triggered. Before You Start Go to Configuration → System → Maintenance → VCA Resource Type , select Temperature Measurement + Perimeter Protection.
  • Page 72 Thermal Network Camera User Manual a. Click to draw an area in the live view. Right click the mouse to finish drawing. It is recommended to draw three different areas covering the whole detection scene from near to far. Note The recommended drawing is optional for some camera models, refer to the pop-up operation guide after you checked Intelligent Analysis.

  • Page 73: Set Perimeter Protection Shield Region

    Thermal Network Camera User Manual 7. Optional: Calibrate the camera to improve the accuracy. Refer to Calibration for detailed settings. 7.3.2 Set Perimeter Protection Shield Region You can configure areas from being detected. Steps 1. Go to Configuration → Local , and enable Display Shield Area. 2.

  • Page 74: Calibration

    Thermal Network Camera User Manual 7.3.4 Calibration You can calibrate the camera first to improve the detection accuracy of perimeter protection. The calibration is optional, take the actual condition for reference. Note The function varies according to different camera models. Calibrate Automatically Before You Start Make sure that we have known the actual height of the target person in the scene.
  • Page 75 Thermal Network Camera User Manual Calibrate Manually Steps 1. Go to Configuration → Perimeter Protection → Camera Calibration . 2. Check Manual Calibration. 3. Click Fig 1. Click and drag the vertical line until it fits the target. 4. Enter the actual length of the calibration line. 5.

  • Page 76: Set Advanced Configuration Parameters

    Thermal Network Camera User Manual 7.3.5 Set Advanced Configuration Parameters Go to Configuration → Perimeter Protection → Advanced Configuration and configure the parameters. Detection Parameters Single Alarm The system only sends alarm once for one target triggering. Otherwise, the alarm will be triggered continuously until the target disappears.

  • Page 77: Chapter 8 Event And Alarm

    Thermal Network Camera User Manual Chapter 8 Event and Alarm This part introduces the configuration of events. The device takes certain response to triggered alarm. Certain events may not be supported by certain device models. 8.1 Set Motion Detection It helps to detect the moving objects in the detection region and trigger the linkage actions. Steps 1.

  • Page 78: Expert Mode

    Thermal Network Camera User Manual 8.1.2 Expert Mode You can configure the motion detection parameters of day/night switch according to the actual needs. Steps 1. Select expert mode in Configuration. 2. Set parameters of expert mode. Day/Night Switch OFF: Day/Night switch is disabled. Day/Night Auto-Switch: The system switches day/night mode automatically according to environment.

  • Page 79: Set Alarm Input

    Thermal Network Camera User Manual Figure 8-1 Set Video Tampering Area 5. Refer to Set Arming Schedule for setting scheduled time. Refer to Linkage Method Settings for setting linkage method. 6. Click Save. 8.3 Set Alarm Input Alarm signal from the external device triggers the corresponding actions of the current device. Before You Start Make sure the external alarm device is connected.

  • Page 80: Set Exception Alarm

    Thermal Network Camera User Manual 8.4 Set Exception Alarm Exception such as network disconnection can trigger the device to take corresponding action. Steps 1. Go to Configuration → Event → Basic Event → Exception . 2. Select Exception Type. HDD Full The HDD storage is full.

  • Page 81: Detect Scene Change

    Thermal Network Camera User Manual 3. Refer to Set Arming Schedule for setting scheduled time. Refer to Linkage Method Settings for setting linkage methods. 4. Click Save. Note The function varies according to different models. 8.6 Detect Scene Change Scene change detection function detects the change of the scene. Some certain actions can be taken when the alarm is triggered.

  • Page 82: Chapter 9 Arming Schedule And Alarm Linkage

    Thermal Network Camera User Manual Chapter 9 Arming Schedule and Alarm Linkage Arming schedule is a customized time period in which the device performs certain tasks. Alarm linkage is the response to the detected certain incident or target during the scheduled time. 9.1 Set Arming Schedule Set the valid time of the device tasks.

  • Page 83: Manual Alarm

    Thermal Network Camera User Manual Manual Alarm You can trigger an alarm output manually. Steps 1. Set the manual alarm parameters. Alarm Output No. Select the alarm output No. according to the alarm interface connected to the external alarm device. Alarm Name Custom a name for the alarm output.

  • Page 84: Ftp/Nas/Memory Card Uploading

    Thermal Network Camera User Manual Steps 1. Check Enable Auto Trigger. 2. Set Trigger Time, and the device will trigger an alarm output to the alarm server automatically in the set time. 3. Set Auto Trigger Delay. It refers to the time duration that the alarm output remains in effect after the auto trigger.

  • Page 85: Notify Surveillance Center

    Thermal Network Camera User Manual When you select TLS, and disable STARTTLS, emails are sent after encrypted by TLS. The ● SMTP port should be set as 465. When you select TLS and Enable STARTTLS, emails are sent after encrypted by STARTTLS, ●...

  • Page 86: Set Audible Alarm Output

    Thermal Network Camera User Manual 9.2.6 Set Audible Alarm Output When the device detects targets in the detection area, audible alarm can be triggered as a warning. Steps 1. Go to Configuration → Event → Basic Event → Audible Alarm Output . 2.

  • Page 87: Chapter 10 System And Security

    Thermal Network Camera User Manual Chapter 10 System and Security It introduces system maintenance, system settings and security management, and explains how to configure relevant parameters. 10.1 View Device Information You can view device information, such as Device No., Model, Serial No. and Firmware Version. Enter Configuration →...

  • Page 88: Export Diagnose Information

    Thermal Network Camera User Manual Note You can import the exported Device Common Parameters to devices of the same series. 4) Click Browse to select the saved configuration file. 5) Input the encryption password you have set when exporting the configuration file. 6) Click Import.

  • Page 89: Upgrade

    Thermal Network Camera User Manual 2. Click Restore or Default according to your needs. Restore Reset device parameters, except user information, IP parameters and video format to the default settings. Default Reset all the parameters to the factory default. Note Be careful when using this function.

  • Page 90: Set Ntp Server

    Thermal Network Camera User Manual 3. Click Manual Time Sync.. 4. Choose one time synchronization method. - Select Set Time, and manually input or select date and time from the pop-up calendar. - Check Sync. with computer time to synchronize the time of the device with that of the local 5.

  • Page 91: Set Rs-485

    Thermal Network Camera User Manual Steps 1. Go to Configuration → System → System Settings → RS-232 . 2. Set RS-232 parameters to match the device with computer or terminal. 3. Click Save. 10.12 Set RS-485 RS-485 is used to connect the device to external device. You can use RS-485 to transmit the data between the device and the computer or terminal when the communication distance is too long.

  • Page 92: Security

    Thermal Network Camera User Manual 10.14 Security You can improve system security by setting security parameters. 10.14.1 Authentication You can improve network access security by setting RTSP and WEB authentication. Go to Configuration → System → Security → Authentication to choose authentication protocol and method according to your needs.

  • Page 93: Set Ip Address Filter

    Thermal Network Camera User Manual Search Security Audit Logs You can search and analyze the security log files of the device so as to find out the illegal intrusion and troubleshoot the security events. Steps Note This function is only supported by certain camera models. 1.

  • Page 94: Set Mac Address Filter

    Thermal Network Camera User Manual Steps Note IP Address Filter is mutually exclusive with MAC Address Filter. 1. Go to Configuration → System → Security → IP Address Filter . 2. Check Enable IP Address Filter. 3. Select the type of IP address filter. Forbidden IP addresses in the list cannot access the device.

  • Page 95: Certificate Management

    Thermal Network Camera User Manual 10.14.5 Certificate Management It helps to manage the server/client certificates and CA certificate, and to send an alarm if the certificates are close to expiry date, or are expired/abnormal. Note The function is only supported by certain device models. Create Self-signed Certificate Steps 1.
  • Page 96 Thermal Network Camera User Manual 7. Optional: Click Export to export the certificate, or click Delete to delete the certificate to recreate a certificate, or click Certificate Properties to view the certificate details. Note Up to 16 certificates are allowed. ●...

  • Page 97: Control Timeout Settings

    Thermal Network Camera User Manual 10.14.6 Control Timeout Settings If this function is enabled, you will be logged out when you make no operation (not including viewing live image) to the device via web browser within the set timeout period. Go to Configuration →...

  • Page 98: Set Ieee 802.1X

    Thermal Network Camera User Manual Steps 1. Go to Configuration → Network → Advanced Configuration → QoS . 2. Set Video/Audio DSCP, Alarm DSCP and Management DSCP. Note Network can identify the priority of data transmission. The bigger the DSCP value is, the higher the priority is.

  • Page 99: Online Users

    Thermal Network Camera User Manual Operator Operators can be assigned all permission except for operations on the administrator and creating accounts. Modify Select a user and click Modify to change the password and permission. Delete Select a user and click Delete. Note The administrator can add up to 31 user accounts.

  • Page 100: Chapter 11 Appendix

    Thermal Network Camera User Manual Chapter 11 Appendix 11.1 Common Material Emissivity Reference Material Emissivity Human Skin 0.98 Printed Curcuit Board 0.91 Concrete 0.95 Ceramic 0.92 Rubber 0.95 Paint 0.93 Wood 0.85 Pitch 0.96 Brick 0.95 Sand 0.90 Soil 0.92 Cloth 0.98 Hard Paperboard...
  • Page 101 UD36432B...
