Summary of Contents for Hikmicro B20
- Page 1 Handheld Thermography Camera User Manual...
- Page 2 The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find the latest version of this Manual at the HIKMICRO website (www.hikmicrotech.com/). Please use this Manual with the guidance and assistance of professionals trained in supporting the Product.
- Page 3 Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 4 Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could result in equipment Caution damage, data loss, performance degradation, or unexpected results.
- Page 5 Technical support ● The https://www.hikmicrotech.com portal will help you as a HIKMICRO customer to get the most out of your HIKMICRO products. The portal gives you access to our support team, software and documentation, service contacts, etc.
-
Page 6: Table Of Contents
4.5 Set Temperature Alarm ......5 5 Capture Snapshots ......... 5 5.1 View Snapshots ..错误!未定义书签。 5.2 Export Snapshots ........6 6 HIKMICRO Viewer Connection ......7 6.1 Connect via Wi-Fi ........7 6.2 Connect via Hotspot ......... 7 7 Image Settings ..........8 8 Set LED Light ........... -
Page 7: Introduction
Client Software Connection Mobile Phone: Use HIKMICRO Viewer to see live image, capture, and recording, etc. on your phone. PC: Use HIKMICRO Analyzer to see live image, capture, recording, and receive alarm message, etc., on your PC. Alarm Device outputs audible and visual alarm when the target’s temperature is higher than the... -
Page 8: Preparation
Function Button Hold: Power On/Off Press: Display menu or confirm operation Exit the menu or return to previous menu. Navigation Button Press ▽, △ to sele parameters. Press to confirm. Function Component Charging When the device is Indicator charging, the LED indicator is solid red. -
Page 9: Interface Description
Type-C Power On/Off Power On Remove the lens cover, and hold for over three seconds to turn on the device. You can observe the target when the interface of the device is stable. Power Off When the device is turned on, hold for three seconds to power off the device. -
Page 10: Set Temperature Range
Steps: In the live view interface, press show the menu. Press to select desired setting bar. Press button to go to the setting interface. Emissivity: Set the emissivity of your target as the effectiveness in emitting energy as thermal radiation. -
Page 11: Enhance High-Temperature Target
Go to Custom Spot. Select the certain custom spot, and press Press adjust the position of the spot. Press the trigger to finish setting. The device shows the real-time temperature on the upper left side of live view interface. Enhance High-Temperature Target In target enhancement function, when the target’s temperature is higher than the set value, the target’s color will change to red... -
Page 12: View Snapshots
Picture Type. ● Offline Picture: Select this type when analyzing the picture with the HIKMICRO Analyzer. ● Thermal Graphic: Select this type for custom software development. In the live view interface, pull the trigger to capture snapshot. The live view freezes and device displays the snapshot with temperature information. -
Page 13: Hikmicro Viewer Connection
HIKMICRO Viewer Connection The device supports both Wi-Fi connection and WLAN hotspot. Connect the device to HIKMICRO Viewer App, and you can control the device via mobile App. Connect via Wi-Fi Before You Start Download and install app on your phone. -
Page 14: Image Settings
Cast Screen Before You Start ● Connect the device and PC with supplied Type-C cable ● Install HIKMICRO Analyzer that supports UVC protocol on your PC. Steps: In the live view interface, press show the menu. -
Page 15: Maintenance
Open HIKMICRO Analyzer and you can view the live view and operation of the device on HIKMICRO Analyzer. Maintenance 10.1 View Device Information In the live view interface, press select About to view the device information. 10.2 Set Date and Time In the live view interface, press select Time &... -
Page 16: Appendix
Appendix 11.1 Common Material Emissivity Reference Material Emissivity Human Skin 0.98 0.91 Cement Concrete 0.95 Ceramics 0.92 Rubber 0.95 Paint 0.93 Wood 0.85 Asphalt 0.96 Brick 0.95 Sand 0.90 Soil 0.92 Cotton 0.98 Cardboard 0.90 White Paper 0.90 Water 0.96 11.2 Frequently Asked Questions (FAQ) Q: The charge indicator flashes red. - Page 17 Facebook: HIKMICRO Thermography LinkedIn: HIKMICRO Instagram: hikmicro_thermography YouTube: HIKMICRO E-mail: info@hikmicrotech.com Website: https://www.hikmicrotech.com/ UD21752B-B...
