Bosch G Series Quick Start Manual

G Series Quick Start Guide
It is highly recommended to use the latest version of Remote Programming Software (RPS) with
the G Series Panel available from au.boschsecurity.com. You will also need a D5370–USB Key.
DEFAULT Master PIN (User 1) = 123456
DEFAULT INSTALLER PIN (User 0) = 123
PANEL BASICS
EOL:
This panel supports Single EOL = 1.0K ohm
in SERIES. NO SPLIT EOL
This panel supports Dual EOL = 1.0 K ohm
in SERIES/1.0K ohm in PARALLEL.
Available Point Types
UNASSIGNED/Octo Input/KEYPAD/Wireless/Onboard/Output/IP Camera/DOOR
(Zonex/D8125 and POPEX components are NOT used in Australia)
A POINT also has a POINT INDEX or PROFILE of how it will work.
Up to 32 types of Point Index Profiles.
Each Point Index number sets HOW the panel will respond when specific conditions occur on this point.
Numerous settings can be configured for each Point Index.
RF Components:
Panel supports:
1 x B810 RADION RF Receiver
504 Points/1000 Keyfobs/supports 8 x RADION
RFRP Repeaters
OR:
1 x B820 INOVONICS RF Module
350 RF Points or Keyfobs/supports 8 x EN5040
Repeaters
The receiver can only be activated in programming
via RPS
RF Fob: Add/Remove
Users/Edit User — Select User # then [ENTER]
Change User? Continue
Passcode/Name/Level/Keyfob/Card/Language
Configure Keyfob?
Select Keyfob
Options are: Enter ID/ADD/Replace/Remove
Enter ID — Edit Enter ID # SAVE
ADD — Not Assigned — ADD
(Learns and Saves)
To ENTER programming = CODE (123) then select [ENTER]
To EXIT programming = Hold down ESC key
Zones:
Zones on this panel are called POINTS.
Panel supports up to 599 Points.
Main panel supports 8 x ONBOARD Points. (1 to 8)
Point expansion is by module or also with some other components.
Each with 34 different programmable settings.
Options are:
[ENTER]
Trigger Keyfob
Panel supports up to 59 x 8 input zone expanders
RF Components and Setup:
RF Receiver and Repeaters
A
RADION B810 Receiver
Supports = 504 Points/1000 RF Fobs/8
Repeaters
B810 Receiver can only be enabled in RPS
SDI2 Modules/Wireless Receiver/Module Type
= B810 Radion Wireless
B
INOVONICS B820 Interface Module
Supports = 350 Points or Fobs Total/8
Repeaters
B820 Interface can only be enabled in RPS
SDI2 Modules/Wireless Receiver/Module Type
= B820 Inovonics Wireless
Can only support using A or B/not both
Learn in/Delete RF Device
Point must already have Point Index and Source set
in programming
Installer/Wireless/RF Point Menu
• Enrol Point RFID ‒ Add device
• Replace Point RFID
• Delete Point RFID
