INVERTER
FR-D800(-E)
Instruction Manual (Functional Safety)
(Standard model / Ethernet model)
CONTENTS
1. GENERAL DESCRIPTION............................................. 3
2. INSTALLATION AND WIRING ...................................... 4
4. TEST AND CHECKING FAILURE ............................... 11
5. SAFETY PARAMETERS OF FR-D800 ......................... 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-D800 and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Electric FR-D800

Summary of Contents for Mitsubishi Electric FR-D800

  • Page 1: Table Of Contents

    Instruction Manual (Functional Safety) (Standard model / Ethernet model) CONTENTS 1. GENERAL DESCRIPTION..........3 2. INSTALLATION AND WIRING ........4 3. EXAMPLE OF SAFETY SYSTEM CONFIGURATION..8 4. TEST AND CHECKING FAILURE ....... 11 5. SAFETY PARAMETERS OF FR-D800 ......12...
  • Page 2 CAUTION  The information of this manual is merely a guide for proper installation.  Mitsubishi Electric cannot assume responsibility for the compliance or the noncompliance to any code, national, local, or otherwise for the proper installation of this equipment.

  • Page 3: General Description

    Features The safety stop function of the Mitsubishi Electric FR-D800(-E) inverter can be used to prevent the inverter from supplying rotational energy to motors. Dual input terminals S1 and S2 can be used to cut off the gate-drive power to the IGBT.

  • Page 4: Installation And Wiring

    Refer ISO/IEC 13849-2. Installation The safety stop function of the Mitsubishi Electric FR-D800(-E) inverter should be used under the following conditions and environment. Table 2 Conditions and environment for using the safety stop function...
  • Page 5 Wiring The safety related terminals are described in Table 3 and Table 4. Table 3 Safety related terminals Terminal Terminal name Terminal function description Rating   symbol For input of safety stop channel 1 Safety stop input Between S1 and PC (Channel 1) OFF: In safety stop mode Input resistance: 4.7 kΩ...
  • Page 6 Table 4 Truth table of safety related signals Internal Input terminal Output Output signal Inverter Operation panel indication Input safety terminal      running power circuit status SAFE SAFE2 E.SAF   status Output shutoff   ...
  • Page 7 Shorting wire The shorting wire are installed between terminals S1/S2 and PC in the initial status as shown in Figure 2. Remove the shorting wires and connect the safety relay module when using the safety stop function. FR-D800 FR-D800-E S2 PC...

  • Page 8: Example Of Safety System Configuration

    CC-Link IE Field Network remote I/O module (with safety functions) NZ2GFSS2 - 32D/NZ2EXSS2 - 8TE Figure 3 Safety system example of the FR-D800(-E) inverter  When the control logic is the sink logic, the common terminal is terminal SD. NOTE •...
  • Page 9 Gate Driver +24V Fuse Figure 4 When using multiple safety stop function inverters (FR-D800(-E)) NOTE • Some models cannot be used together because their control logics are different. Refer to the Safety Stop Function Manual of each model. EXAMPLE OF SAFETY SYSTEM CONFIGURATION...
  • Page 10 WS0-CPU0 Safety I/O combined module WS0-XTIO Figure 5 Safety system example of the FR-D800(-E) inverter NOTE • When starting up the system operation, press the RESET switch to reset the safety stop function first. • In the above configuration, after resetting the emergency stop button, the inverter will be in the safe-state until the RESET switch is pressed.

  • Page 11: Test And Checking Failure

    TEST AND CHECKING FAILURE CAUTION  To avoid system faults, check the safety stop function at least once per year. Also, check the safety stop function at system installation, any software changes, and parameter setting changes. I/O status and inverter operation The inverter’s safety related I/O status obeys the following truth table.

  • Page 12: Self-Diagnostic Test

    2) Disconnect the wires from terminals S1, S2, and PC, then reset or turn OFF and ON the power. If the ‘SA’ is indicated on the operation panel, there is a failure in the system except for the FR-D800 inverter. When ‘E.SAF’ is indicated and a fault signal is output, a fault may be occurring in the FR-D800 inverter.
  • Page 13 MEMO...
  • Page 14 REVISIONS Revision date Manual number Revision Dec. 2024 BCN-A23498-003-A(E) First edition...
