Output
The following steps take XDS oscilloscope with dual-channel AG for instance.
To save the CH1 waveform and save to the internal/USB memory:
(1) Push Save button.
(2) Select Type in the bottom menu, turn the M rotary control to select Clone in the
left menu.
(3) Select Source in the bottom menu, select Mode as Out1. in the right menu.
(4) Select AG Output Out1 as CH1. in the right menu.
(5) Select Line in the bottom menu. If a or b is selected, turn the M rotary control to
move the cursor. If ab is selected, turn the M rotary control to move the pair of
cursors. If x is selected, the entire screen will be selected automatically.
(6) Select Save in the bottom menu.
To save the waveform to internal memory, select Storage in the right menu

as Internal. Turn the M rotary control to select an object in the left menu,
select Save in the right menu.
To save the waveform onto a USB memory device, select Storage in the right

menu as External. Select Save in the right menu. An input keyboard used to
edit the file name will pop up. Turn the M rotary control to select the keys,
push the rotary control to input. Select the
confirm. The cloned waveform will be saved onto the USB memory device as
a OTA file.
To output the waveform stored in the internal memory through the generator: (The
generator is optional.)
(1) Push Save button.
(2) Select Type in the bottom menu, turn the M rotary control to select Clone in the
left menu.
(3) Select Save in the bottom menu, select Storage as Internal in the right menu.
User Manual
Save the waveform onto a USB memory
device
Insert a USB memory device into the port on
the front panel. If the icon
top right of the screen, the USB memory
device is installed successfully. If the USB
External
memory device cannot be recognized, format
the USB memory device according to the
methods in "USB disk Requirements" on P69.
The name is default as current system date
and time. The cloned waveform will be saved
onto the USB memory device as a OTA file.
(Generator is available and internal storage is selected)
Output the waveform stored in the selected object.
79
appears on the
key in the keyboard to
