multicomp pro MP720665 User Manual page 71

Show
Save
Storage
When the type is Configure, the menu shows as following:
Configure
Save
Load
When the type is Image, the menu shows as following:
Save
User Manual
Recall or close the waveform stored in the
current object address. When the show is
ON, if the current object address has been
ON used, the stored waveform will be shown,
OFF the
information will be displayed at the top
left of the screen; if the address is empty,
it will prompt "None is saved".
Close all the waveforms stored in the
Close All
object address.
Save the waveform of the source to the
selected address. Whatever the Type of
save menu is set, you can save the
waveform by just pressing the Copy panel
button in any user interface.
Select Type in the bottom menu, in the
right Format menu, you can select the
storage format.
Save to internal storage or USB storage.
When External is selected, save the
waveform according to the current record
Internal length (see "
External the file name is editable. The BIN
waveform file could be open by the
waveform analysis software (on the
supplied CD).
Setting0
.....
The setting address
Setting19
Save the current oscilloscope configure to
the internal storage
Recall the configure from the selected
address
Save the current display screen. The file
can be only stored in a USB storage, so a
USB storage must be connected first. The
file name is editable. The file is stored in
BMP format.
67
address number
Record Length menu
and relevant
" on P61);
