User Manual
PT-SP-HD12-48G
No. Name
CEC DIP
switch
EDID DIP
5
switch
6 SERVICE
7 IN port
OUT port
8
(1~2)
9 OPTICAL
10 L/R
11 DC 5V
Use this DIP switch to enable or disable CEC.
1 - CEC disable: Prevent CEC communication between
source and sink devices.
0 - CEC enable: Allow CEC communication between source
and sink devices.
Use the DIP switch to set EDID.
[DIP]=1111: Copy OUT1 port sink EDID
[DIP]=1110: FRL12G_8K_HDR,2.0CH
[DIP]=1101: FRL12G_8K_HDR,5.1CH
[DIP]=1100: FRL12G_8K_HDR,7.1CH
[DIP]=1011: FRL10G_8K_HDR,2.0CH
[DIP]=1010: FRL10G_8K_HDR,5.1CH
[DIP]=1001: FRL10G_8K_HDR,7.1CH
[DIP]=1000: 4K120(420)_HDR,2.0CH
[DIP]=0111: 4K120(420)_HDR,5.1CH
[DIP]=0110: 4K120(420)_HDR,7.1CH
[DIP]=0101: 4K60(444)_HDR,2.0CH
[DIP]=0100: 4K60(444)_HDR,5.1CH
[DIP]=0011: 4K60(444)_HDR,7.1CH
[DIP]=0010: 1080P120(444)_HDR,2.0CH
[DIP]=0001: 1080P60(444), 2.0CH
[DIP]=0000: Custom EDID Upload
Firmware update and debug port.
HDMI signal input port, connecting to HDMI source device
such as DVD or PS5 with an HDMI cable.
HDMI signal output port, connecting to HDMI display
device such as TV or Monitor with an HDMI cable.
Optical fiber audio output port.
Analog audio output port.
DC 5V/2A Power input port.
Function Description
