User Manual
PT-SP-HD12-48G
5. System Diagram
Usage Precaution
⚫
Make sure all components and accessories included before installation.
⚫
System should be installed in a clean environment with proper
temperature and humidity.
⚫
All of the power switches, plugs, sockets, and power cords should be
insulated and safe.
⚫
All devices should be connected before power on.
The following diagrams illustrate typical input and output connections that
can be utilized with this device:
DVD or Blu-ray Player
IN
8K TV 2
OUT 1 OUT 2
AVR or Amplifier
8K TV 1
10
Power Supply
L/R
Line Level
Audio Device
