User Manual
PT-SP-HD12-48G
1.3 Package List
1 × 8K HDMI 1x2 Splitter
1 × 5V/2A Multinational Power Supply
2 × Mounting Ear
4 × Machine Screw (KM3*4)
1 × User Manual
2. Panel Description
1
IN
7
No.
Name
1
Power LED The power LED lights in red when the device is working.
2
IN LED
OUT LED
3
(1~2)
HDCP DIP
4
switch
IN
OUT 1
OUT 2
2
3
OUT 1
When the HDMI IN port connects an active source device,
the green LED will be on.
When the HDMI OUT 1/2 port connects a display device and
outputs signal, the corresponding green LED will be on.
Use this DIP switch to set HDCP.
1 - Pass-through mode: The output HDCP follows the source.
0 - Managed mode: If the source has HDCP, the output will
be set to HDCP 1.4; if the source has no HDCP, the output
will be set to no HDCP.
1
1
0
0
HDCP CEC
4
OUT 2
8
Function Description
3
EDID
SERVICE
5
6
L/R
11
9
10
