Page 1
2967-002B SINGLE ARM RESIDUE MANAGER FOR TWIN ROW PLANTER GREAT PLAINS OPERATOR’S MANUAL PART IDENTIFICATION 2565-763_REV_I – 08/2024 YETTER MANUFACTURING CO. FOUNDED 1930 Colchester, IL 62326-0358 Toll free: 800/447-5777 309/776-3222 (Fax) Website: www.yetterco.com E-mail: info@yetterco.com...
Page 2
It is the user’s responsibility to deliver his machine to the Yetter dealer who sold him the product for service or replacement of defective parts, which are covered by the warranty policy.
Page 3
SAFETY PRECAUTIONS A brief description of signal words that may be used in this manual: DANGER: Indicates an imminently hazardous situation which, if not avoided “will” result in death or serious injury. This signal word is to be limited to the most extreme situations. WARNING: Indicates a potentially hazardous situation which, if not avoided, “could”...
Page 4
BOLT TORQUE Mounting bolts and hardware Before operating the Residue Manager for the first time, check to be sure that all hardware is tight. Check all hardware again after approximately 50 hours of operation and at the beginning of each planting season. All hardware used on the Residue Manager is Grade 5 unless otherwise noted.
Page 5
OPERATION ROW CLEANER DO’S AND DON’TS 1. DO NOT move soil; Residue Managers are designed to move crop residue only. 2. DO NOT operate planter at slow speeds, ground speed affects how aggressive the spoke wheels are; operate at sufficient speed (4-6 mph) to maintain good residue flow. 3.
Page 6
NOTICE: failure to properly set the planter frame height and levelness can result in less than successful operation of the planter and the Yetter product and may result in damaged equipment. All operators should read and thoroughly understand the instructions given prior to using the Yetter product.
Page 8
INSTALLATION INSTRUCTIONS STEP 1. Attach the Residue Manager to the planter unit using 4) ½” bolts, nuts, and lock washers.
Page 9
INSTALLATION INSTRUCTIONS Attach the R.M. wheel/hub assembly to the arm using 5/8” lock washer and hex nut. STEP 2. Adjust the bearing shield to top dead center, rotated slightly forward. Torque to 180 ft. lbs.
Page 10
Conditions in certain geographical areas may require special lubricants and lubrication practices which do not appear in the operator's manual. If there are any questions, consult Yetter Manufacturing Co. to obtain latest information and recommendation. Storing Lubricants Your machine can operate at top efficiency only if clean lubricants are used.
Page 11
PARTS IDENTIFICATION 2967-002B-L-FW 2966-140-ST-FW 2966-140-ST-PFW...
Page 12
PARTS IDENTIFICATION 2966-140-BW-FW 2966-140-STF-PFW RIGHT HAND SHARKTOOTH FINGER WHEEL ASSEMBLY...
Page 13
ITEM PART NO DESCRIPTION 2502-221 5/16-18 X 1 HHFS GRADE 5 2502-222 5/16-18 X 1-1/4 HHFS GRADE 5 2502-225 5/16-18 X 1-1/2 HHFS GRADE 5 2940-560 SET SCREW 2965-500 HUB ASSEMBLY 1.406 SPINDLE 2965-501 HUB ASSEMBLY 2.406 SPINDLE 2965-502 HUB ASSEMBLY 1.157 SPINDLE ITEM PART NO DESCRIPTION...
Page 14
PARTS IDENTIFICATION 2966-104 ARM ASSEMBLY RIGHT HAND...
Page 15
PARTS IDENTIFICATION 2966-106 ARM ASSEMBLY LEFT HAND...
