Altronix Trove2PD2 Installation Manual

Download this manual

Access & Power Integration

Trove2PD2

- Trove2 enclosure with Altronix/PDK backplane (TPD2)

TPD2

- Altronix/PDK backplane only

Installation Guide

All registered trademarks are property of their respective owners.

Rev. T2PD2011023

Installing Company: _________________________ Service Rep. Name: __________________________________________

Address: _________________________________________________________ Phone #: _________________________

SIGNALING

More than just power.™

Need help?

Do you have a question about the Trove2PD2 and is the answer not in the manual?

Page 1 SIGNALING Access & Power Integration Trove2PD2 - Trove2 enclosure with Altronix/PDK backplane (TPD2) TPD2 - Altronix/PDK backplane only Installation Guide More than just power.™ All registered trademarks are property of their respective owners. Rev. T2PD2011023 Installing Company: _________________________ Service Rep. Name: __________________________________________...
Page 2 Install the three lower screws and make sure to tighten all screws. Mount included UL Listed tamper switch (Altronix Model TS112 or equivalent) in desired location, opposite hinge. Slide the tamper switch bracket onto the edge of the enclosure approximately 2” from the right side (Fig. 1, pg. 2). Connect tamper switch wiring to the Access Control Panel input or the appropriate UL Listed reporting device.
Page 3 TPD2: Configuration of Altronix Power Supplies, Sub-Assemblies and PDK Modules Fasten spacers (provided) to pems that match the hole pattern for Altronix Power Supply/Chargers (Fig. 2, pg. 3). Fasten metal spacers in the correct locations to provide proper grounding, see below (Fig. 2, pg. 3).
Page 4 Trove2PD2 Enclosure Dimensions (H x W x D): 27.25” x 21.75” x 6.5” (692.2mm x 552.5mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 5.25” (133.35mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77” 1.125” (28.3mm) (45mm) 2.415”...
