- Page 1 PoE Driven Multi-Output Power Supply with Lithium Battery Backup Installation Guide Tango8P - 12VDC and/or 24VDC selectable by output @ 75W max. - Eight (8) fuse protected outputs - Built-in Lithium Iron Phosphate Battery Charger Tango8PCB - 12VDC and/or 24VDC selectable by output @ 75W max. - Eight (8) Class 2 power-limited PTC protected outputs - Built-in Lithium Iron Phosphate Battery Charger More than just power.
-
Page 2: Table Of Contents
Table of Contents: Overview pg. 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Specifications . -
Page 3: Overview
Overview: Altronix Tango8P(CB) PoE Driven Multi-Output Power Supply converts an IEEE802 .3bt PoE input into eight (8) regulated 24VDC and/or 12VDC outputs up to 75W . It eliminates the need for a high voltage inside the enclosure . Tango8P(CB) is designed to support a single 12V LiFePO 4 (Lithium Iron Phosphate) battery for 12VDC and 24VDC backup . -
Page 4: Installation Instructions
Installation Instructions: Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, the Canadian Electrical Code and with all local codes and authorities having jurisdiction . Product is intended for indoor use only . 1 . Mount unit in desired location . Mark and predrill holes in the wall to line up with the top two keyholes in the enclosure . -
Page 5: Led Diagnostics
LED Diagnostics: Tango1B BLINKING Input Input voltage is present . Input voltage not present . Battery Normal operating condition . Battery is low or missing . Indicates Class . Refer to table below Classes 3-8 Supervision PoE Fail or BAT Fail . NC dry contact 30V 1A (not an LED) Class Green... - Page 6 Fig. 3 - Tango8P(CB) PDS8 PWR1 + IN1 Fuse Dual Voltage PWR1 + Power Distribution PDS8CB Module Data Pass-Through LiFeP0 4 Battery connection (non power-limited) OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8 COM (--- ) PoE Input COM (--- ) Supervision PWR2 + PWR2 +...
- Page 7 Notes: Tango8P(CB) - PoE Driven Multi-Output Power Supply - 7 -...
-
Page 8: Enclosure Dimensions
Altronix is not responsible for any typographical errors . 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www .altronix .com | e-mail: info@altronix .com | Lifetime Warranty | Made in U .S .A . IITango8P(CB)
