Schwinn 170:  Why isn't my speed reading properly?
Follow this troubleshooting guide to help resolve issues involving incorrect speed readings on the Schwinn 170 upright bike.
Some common complaints may include:
Speed is displayed incorrectly
Speed is not displayed
Console turns off during a workout
Console displays "Please Pedal" error

Follow these steps to troubleshoot the issue

Tools you may need:
Phillips head screwdriver
Flathead screwdriver
Crank puller (if removing shrouds for troubleshooting)
6mm hex/Allen wrench, or the wrench from the hardware
card included with your machine
1.
Begin a workout using the Quick Start or Manual Workout button on your console. Pedal your bike while checking for
speed, RPM, or intensity change on the display. The speed and RPM should display on the lower display and the
intensity bar should go up while pedaling [12329.A].
2.
If the issue persists, inspect the console for any damage. If damage is present,
3.
Using a Phillips head screwdriver, remove the console and disconnect the upper Mast Cable connector (reference 1).
Inspect the cable for crimps, cuts, bent pins, or other damage. If damage is present,
about:blank
Schwinn 170:  Why isn't my speed reading properly?
(Reference 1)
ID: 12329.1
order a
Console [12329.B].
order a Mast
Cable [12329.C].
1/4

Advertisement

loading
Need help?

Need help?

Do you have a question about the Schwinn 170 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bowflex Schwinn 170

  • Page 1 Schwinn 170:  Why isn't my speed reading properly? Schwinn 170:  Why isn't my speed reading properly? ID: 12329.1 Follow this troubleshooting guide to help resolve issues involving incorrect speed readings on the Schwinn 170 upright bike. Some common complaints may include: Speed is displayed incorrectly...
  • Page 2 3/12/24, 8:45 AM Schwinn 170:  Why isn't my speed reading properly? The screws attaching the console to the mast are on the back side of the console, circled in red in this image. Remove the screws to remove the console from the mast.
  • Page 3 3/12/24, 8:45 AM Schwinn 170:  Why isn't my speed reading properly? The RPM Sensor (A) is located on the frame of the bike. Inspect both the sensor (A) and cable (B). Using a 6mm Allen wrench, remove the 4 bolts attaching the mast to the frame. Lift and remove the mast. Disconnect the lower mast cable connector and inspect for crimps, cuts, bent pins, or other damage (reference 3).
  • Page 4 A Customer Care Agent will be able to assess your current warranty eligibility and provide you with your options. Please note that if you did not purchase your machine directly from BowFlex, Schwinn, or Nautilus, we will need a copy of your purchase receipt in order to register your machine for warranty.
