- Page 1 User Manual MIC-3861 3U CompactPCI® Serial Quad Ports 10 Gigabit Ethernet Board with Intel® X710 TM4/AT2...
- Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
- Page 3 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Please contact your local supplier for ordering information.
- Page 4 Document Feedback To assist us with improving this manual, we welcome all comments and constructive criticism. Please send all feedback in writing to support@advantech.com. Packing List Before system installation, check that the items listed below are included and in good condition.
- Page 5 SFP+-10G-LR-IT, 1310nm, SM, 10km, -40~85°C, sin- gle-mode SFP-XSM-LCI-10K SFP+-10G-ELR-IT, 1310nm, SM, 20km, -40~85°C, sin- gle-mode SFP-XSM5-LCI-40K SFP+-10G-ER40-IT, 1550nm, SM, 40km, -40~85°C, sin- gle-mode SFP-XSM-LCI-80K SFP+-10G-ZR, 1550nm, SM, 80km, -40~85°C, single- mode 968AD00409 SFP+ 10G,1310nm DFB SM, 10km, 0~70°C, XCVR W/ DDM, single-mode MIC-3861 User Manual...
- Page 6 In accordance with IEC 704-1:1982 specifications, the sound pressure level at the operator’s position should not exceed 70 dB (A). DISCLAIMER: These instructions are provided according to IEC 704-1 standards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. MIC-3861 User Manual...
- Page 7 We Appreciate Your Input Please let us know of any aspect of this product, including the manual, which could use improvement or correction. We appreciate your valuable input in helping make our products better. MIC-3861 User Manual...
- Page 8 MIC-3861 User Manual viii...
- Page 9 Contents Chapter General Information ......1 Introduction ....................2 Figure 1.1 MIC-3861-A1S1............2 Figure 1.2 MIC-3861-B1S1............3 Key Features..................... 3 HW Specifications ..................3 Mechanical Specifications................. 4 Figure 1.3 MIC-3861-A1S1............4 Figure 1.4 MIC-3861-B1S1............4 Figure 1.5 MIC-3861-C1S1............5 Environmental & Regulatory Specifications ..........5 Chapter Installation........7...
- Page 10 MIC-3861 User Manual...
- Page 11 Chapter General Information...
- Page 12 100Base-TX through 100 meters of Cat 5e or better cabling. The MIC-3861 utilizes PCI Express® 3.0 (up to 8GT/s) and supports x1, x4, and x8 link widths. Maximum PCIe data transfer rates for Gen3 (8 GT/s) depend on the CPU card and backplane slot.
- Page 13 Figure 1.2 MIC-3861-B1S1 Key Features 3U CompactPCI® Serial 4HP height 10Gbps networking card 2 x 10GbE SFP+ plus 2* 10GbE RJ-45 ports with Intel® X710-TM4 2 x 10GbE M12 X-code ports or RJ-45 with Intel® X710-AT2 Supports virtualization (SR-IOV): up to 128 virtual functions ...
- Page 14 – SFP+ fiber ports: 10GbaseT/Full, 1GbaseX/Full, 10GbaseSR/Full, 10GbaseLR/Full LED: power LED; LAN LED Mechanical Specifications Dimensions: 160 x100 mm Height: 4HP / 20.23 mm Weight: 0.2 kg Figure 1.3 MIC-3861-A1S1 Figure 1.4 MIC-3861-B1S1 MIC-3861 User Manual...
- Page 15 Figure 1.5 MIC-3861-C1S1 Environmental & Regulatory Specifications Operating Temperature: 0 ~ 70°C (-32 ~ 158°F) Storage Temperature: -40 ~ 85°C (-40 ~ 185°F) Operating Humidity: 95% @ 40°C, non-condensing Storage Humidity: 95% @ 60°C, non-condensing Vibration: 2Grms, random (5 ~ 500 Hz) ...
- Page 16 MIC-3861 User Manual...
- Page 17 Chapter H/W Installation...
- Page 18 MIC-3861 Overview Function Block Diagram MIC-3861 User Manual...
- Page 19 Name Description Green Indicates power on LAN 1/LAN2 (Link) Green, on (10 Gbps), orange (5/2.5/1 Gbps (speed link)) LAN1/LAN2 (Activity) Green Blink is working LAN 3/LAN4 (Link) Green, on (10 Gbps) LAN3/LAN4 (Activity) Green Blink is working MIC-3861 User Manual...
- Page 20 MIC-3861 User Manual...
- Page 21 Chapter Driver Installation...
- Page 22 Introduction MIC-3861 supports Windows and Linux. It has been tested on the OS below. Windows: Windows® 10, Windows® 11 Linux: Ubuntu 22.04, CentOS Stream 9 Windows Driver Setup Copy the driver (Release_28.3.zip) to the host and unzip it (suppose the X710- TM4).
- Page 23 Left-click the first Ethernet Controller and right-click Update driver. Select “Browse my computer for driver software”. MIC-3861 User Manual...
- Page 24 Select the folder where driver files are located. Select this file according to Release_28.3→PRO40GB→Winx64→NDIS68 and click OK. Click next. MIC-3861 User Manual...
- Page 25 If the driver i40e version is not 2.24.6, it is suggested you install the driver version manually. Go to the Advantech official website to download this NIC driver installation package (the package name is: i40e-2.24.6.tar.gz). Extract the driver file: #sudo tar -zxf i40e-2.24.6.tar.gz Enter the driver folder: #sudo cd i40e-2.24.6/src...
- Page 26 Install the driver: #insmod i40e.ko #sync #ethtool –i enp1s0f0 Then you can see the i40e driver version is 2.24.6. This means the driver has been installed successfully. MIC-3861 User Manual...
- Page 27 Appendix Pin Assignments and Jumper Settings...
- Page 28 SW Settings SW1 is for debugging. Defaults are as shown below. Table A.3: SMBUS Address:1110 A2 A1 AO R/W FIXED A2 Address EO/E1 E2/E3 E4/E5 DEFAULT E6/E7 1110 E8/E9 EA/EB EC/ED EE/EF MIC-3861 User Manual...
- Page 29 MIC-3861 User Manual...
- Page 30 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2024...
