MIC-3820
3U CompactPCI
Startup Manual
Packing List
Before installation, please ensure that the following items
have been included in your shipment:
1. 1 x MIC-3820-A1S1
2. 4 x Screws M3x4L S/S D
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.
Note :
Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: www.
adobe.com/Products/acrobat/readstep2. html
(Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support services, please visit our support
website at:
http://support.advantech.com
This manual is for the MIC-3820-A1S1.
Part No. 2041382000
Printed in China
Serial SATA Carrier Board
®
Edition 1
August 2022
Specifications
Standard Functions
• Backplane Interface: SATA3.0
• Accommodate model: 2.5" SATA SSD/HDD
• Power: +12: VPower consumption depending on plugged
module, supports up to 75W
Mechnical and Environment
• Dimensions (W x H x D): 160.00 x 100.00 mm (6.30" x
3.95")
• Non-Operate temperature: -40 ~ 85 °C (-40 ~ 185 °F)
• Operating temperature (depending on module): -40 ~
85 °C (-40 ~ 185 °F)
• Operating Humidity: 95% @ 40 °C, non-condensing
• Non-Operate Humidity: 95% @ 60 °C, non- condens-
ing
• Vibration (5~500 Hz): 2.0 Grms (without HDD/SSD
module)
MIC-3820 Startup Manual 1
Advertisement
Related Manuals for Advantech MIC-3820
Summary of Contents for Advantech MIC-3820
- Page 1 • Operating Humidity: 95% @ 40 °C, non-condensing • Non-Operate Humidity: 95% @ 60 °C, non- condens- • Vibration (5~500 Hz): 2.0 Grms (without HDD/SSD module) For more information on this and other Advantech products, please visit our website at: http://www.advantech.com http://www.advantech.com/epc...
- Page 2 RESET# SDI_L P_SATA_RX+ Pin Number Net Name Pin Type Pin Number Net Name Pin Type +12V_HOT WAKE_OUT# SCLK0 P_SATA_RX- Pin Number Net Name Pin Type Pin Number Net Name Pin Type +12V_HOT PCIE_EN# SLOAD0 P_SATA_TX+ P_SATA_TX- 2 MIC-3820 Startup Manual...
- Page 3 P1 Pin Definition (Cont.) Block Diagram Dimension Diagram 177.43±0.3 165.13±0.3 MIC-3820 Startup Manual 3...
- Page 4 3. Put the SSD/HDD model in holder bracket. (Figure 3) 4. Push the bracket through the front panel into carrier board.(Figure 4) 5. Lock the hand screw .(Figure 5) Figure 1 Figure 2 Figure 3 Figure 4 Figure 5 4 MIC-3820 Startup Manual...
