Advantech MIC-300 Startup Manual

MIC-300
3U Height CompactPCI
Startup Manual
Packing List
Before installation, please ensure that the following items
have been included in your shipment:
1. 1 x MIC-300 serial
2. 1 x Startup manual
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.
Safety Instructions
1. Put this equipment on a reliable surface during installa-
tion. Dropping it or letting it fall may cause damage
2. Make sure the voltage of the power source is correct
before connecting the equipment to the power outlet
3. If the equipment is not used for a long time, disconnect
it from the power source to avoid damage by transient
overvoltage
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support services, please visit our support
website at:
http://support.advantech.com
This manual is for the MIC-300 Series.
Part No. 2041030000
Printed in China
Serial Enclosure for 3U Cards
®
Specifications
Standard Functions
• Interface supported: PCIe (Gen3), SATA (Gen3),
USB2.0/USB3.0, Ethernet (10GBase-T)
• Backplane Type: 7-slot or 9-slot CompactPCI Serial
backplane with Ethernet Star, single star, without RIO
• Connector Type: AirMax VS
• Power: Power backplane for AC/DC CPCI-Serial Power
module.
• 12V Main: 6.65 A per slot
• 5V standby: 0.95A per slot
Mechnical and Environment
• Operating temperature:: 0 ~ 70° C (32 ~ 158° F)
• Storage Temperature: -40 ~ 85° C (-40 ~ 185° F)
• Humidity: 95% @ 40° C (non-condensing)
• Humidity (Non-operating): 95% @ 60° C (non-con-
densing)
• Cooling: 12 removable low noise mini-fans can be as-
sembled on the top and bottom side of chassis
• Random Vibration (operation): 5~500Hz, 2Grms, 3
axes
• Shock (Operation): 10G, 11ms
• EMC & Safety: design to meet EN50155/EN50121-4
Ordering Information
PN
MIC-300S1-S1
MIC-300S1-S2
Edition 1
August 2022
Chassis
Description
Slot TY
MIC-300
3U CPCI-S
21
Chassis with 9
Slot BP
MIC-300
3U CPCI-S
11
Chassis with 7
Slot BP
MIC-300 Startup Manual 1
Backplane
slot
9
7
