Instructions for use MULTIflex LED coupling 465 LED - 1.007.3197
3 Product description | 3.2 Technical Specifications
3.2 Technical Specifications
Connector
Spray control
Anti-retraction valve
Rated voltage of the KaVo MULTI LED
lamp
Voltage range of the KaVo MULTI LED
lamp
Maximum current
Can be attached to
NOTE
Please comply with the Instructions for Use of the product to be connected to
the MULTIflex coupling. Check the suitability of the product for operation with
the MULTIflex coupling.
NOTE
Operation on KaVo units:
4 1042: on the unit, set the cold light intensity to the lowest intensity level
and increase the brightness level maximally to intensity level 4.
4 1065 / 1060: If the KaVo MULTIflex coupling is used on these units, have a
technician adjust the voltage.
4 E80 / E70 / E50 / 1058 / 1080 / 1066 / 1062: The KaVo MULTIflex coupling
can be used on these units with any further measures being required.
NOTE
Mixed operation KaVo MULTI LED lamp / high-pressure lamp:
Due to design features, mixed operation is not permitted on the following
KaVo units:
1065 / 1063 / 1060 / 1061 / 1059 / 1057
These devices must be fully converted to the new LED. Adaptation of the cold-
light voltage by a service technician is required.
NOTE
Operation on third-party units:
For operation on KaVo-approved third-party devices, see www.kavo.com,
item "LED compatibility".
NOTE
Do not exceed the specified upper voltage limit of 3.6 V DC on the KaVo
MULTI LED lamp.
in accordance with DIN EN ISO 9168
type 3
with regulating ring for Spray control
with Anti-retraction valve
3.4 V DC
3.0 - 3.6 V DC
120 mA
all KaVo (LUX) instruments with ori-
ginal MULTIflex connector
10 / 28
