Summary of Contents for KaVo ELECTROtorque 4890
- Page 1 Operating Instructions ELECTROtorque 4890/K200. 0 rp o r q e rs re v Always on the safe side.
- Page 2 KaVo Elektrotechnisches Werk GmbH Hersteller/manufacturer: Wangener Straße 78 Kaltenbach & Voigt GmbH & Co. KG D-88299 Leutkirch Bismarckring 39 Tel.: 0 75 61 / 86-150 • Fax: 0 75 61 / 86-265 D-88400 Biberach...
-
Page 3: Table Of Contents
A 1.6 Disinfecting the unit ..............................7 Scope of delivery - accessories ............................8 A 2.1 Scope of delivery ................................8 Technical data ..................................9 A 3.1 ELECTROtorque 4890 ..............................9 A 3.2 Transformer ................................11 A 3.3 INTRA- LUX K 200 motor ............................13 Location ....................................13 Installation and Connection ............................14... -
Page 4: A 1 User Information
If other language versions are required, please request these from KaVo. The following operating mode represents the maximum allowable load of the motor (full load at maximum speed):... - Page 5 ELECTROtorque 4890/K200. The following are authorized to repair and service the KaVo ELECTROtorque: • the engineers of KaVo agents through- out the world • the engineers of authorised KaVo dealers who have been specially trained by KaVo • independent engineers specially trained by KaVo.
-
Page 6: A 1.3 Safety Measures
ELECTROtorque 4890/K200. A 1.3 Safety measures Each time before using a unit, the user must ascertain that it is operating safely and is in the proper condition.Check that set values are correct for use. The unit must not be further operated if any functional parts are damaged. - Page 7 Statutory provisions The general guidelines and/or national laws applicable to medical products, national regulations and the rules of industry for commissioning and during operation must be applied to the KaVo product in accordance with the prescribed purpose and must be fulfilled.
-
Page 8: A 1.4 Purpose And Potential Applications
ELECTROtorque 4890/K200. A 1.4 Purpose and potential applications The ELECTROtorque 4890 is a dental treatment unit for operation of a dental revers e x1000 rpm ELE CT electrically operated or air-operated drive RO torq for straight and contra-angle dental handpieces. -
Page 9: A 1.6 Disinfecting The Unit
= max. 10 mg / 100 g of disinfectant Formaldehyde solution = max. 10 mg / 100 g of disinfectant Glyoxal = max. 165 mg / 100 g of disinfectant KaVo will assume no liability if the preparations used contain ingredients differing from those stated by us. -
Page 10: A 2 Scope Of Delivery - Accessories
ELECTROtorque 4890/K200. A 2 Scope of delivery - accessories Check that the system is complete. A 2.1 Scope of delivery ELECTROtorque 4890 Mat.-No. 1.001.6133 consisting of: ELECTROtorque (with 2000 mm long tube) Mat.-No.1.001.2876 INTRA LUX K 200 motor o r q Mat.-No. -
Page 11: A 3 Technical Data
ELECTROtorque 4890/K200. A 3 Technical data A 3.1 ELECTROtorque 4890 Dimensions and weights width: 5 inches depth: 6 inches height: 2 inches weight: 29 oz. or 880 grams Ambient conditions: Permitted indors Permitted ambient temperature range of o r q... - Page 12 ELECTROtorque 4890/K200. Rating plate ELECTROtorque The rating plate is located on the back of the ELECTROtorque unit. It provides information on: @ Manufacturer 2 Protection art IP 40 3 Year of manufacture 4 CE mark according to 93/42/EEC Medical Product...
-
Page 13: A 3.2 Transformer
Electrical connection • The transformer design must comply with the national regulations and requirements for medical equipment. • The ELECTROtorque 4890 is finally for the operation with the transformer type 4880 certified. Check that the local mains voltage and mains frequency conincide with the specifications on the rating plate and the fuse holder. - Page 14 ELECTROtorque 4890/K200. Rating plate transformer 1.001.8749 It provides information on: @ Manufacturer ” Fuse 1,25 A ” 3 Year of manufacture 4 CE mark according to 93/42/EEC Medical Produc 6 mode of operation Intermittent operation 1 min. pause 9 min.
-
Page 15: A 3.3 Intra- Lux K 200 Motor
A 4 Location reverse x1000r ELE CTR Otor que Mount the ELECTROtorque 4890 1 in an easily accessible position or next to the dental unit. Choose the place of installation of the ELECTROtorque 4890 so that the connection between ELECTROtorque 4890... -
Page 16: A 5 Installation And Connection
A 5.1 Installation The following are authorized to repair and service the KaVo ELECTROtorque : • the engineers of KaVo agents through- out the world • the engineers of authorised KaVo dealers who have been specially trained by KaVo • independent engineers specially trained by KaVo. -
Page 17: A 5.3 Connection Requirements
• Air flow for the handpiece, coming out from e- type connection, must be between 6 - 10 NL/min. this can easly be proofed with the KaVo flow meter 1 0.411.4441 or 1.001.9932. Please push the flow meter upright on the motor and start the motor by pressing the foot control. -
Page 18: A 6 Preparation For Commissioning
ELECTROtorque 4890/K200. A 6 Preparation for commissioning A 6.1 Calibration of the foot control At commissioning or when changing the compressed air conditions, the foot control 5 must be calibrated (with the motor stationary). Call up the “Calibration“ subroutine by pressing the keys 1 ↑... -
Page 19: A 6.2 Motor Start Pressure
ELECTROtorque 4890/K200. A 6.2 Motor start pressure The pressure value for starting the motor is prefixed 1 bar. o r q e r s r e v... -
Page 20: A 6.3 Setting The Lamp Voltage
ELECTROtorque 4890/K200. A 6.3 Setting the lamp voltage The lamp voltage can be changed in the range from 3.0 V to 3.8 V (measured at the housing plug) with the motor switched off. The voltage at the lamp itself is 500 mV below the set value. -
Page 21: A 7 Controls And Functional Parts
ELECTROtorque 4890/K200. A 7 Controls and functional parts ELECTROtorque 4890 1 Basic unit 2 Control unit 3 “UP“ for speed increase 4 “DOWN“ for speed reduction o r q e r s r e v 5 Display - Digital speed and fault indicator 6 “REVERSE“... - Page 22 ELECTROtorque 4890/K200. Transformer 1.001.8749 1 Rating plate 2 Bridge 3 Fuse holder 4 Fuse 1,25 A slow 5 Voltage selector...
-
Page 23: A 8 Operation
ELECTROtorque 4890/K200. A 8 Operation • ELECTROtorque may not used without cool air. • Dry, clean, contamination-free compressed air must be used. • Contaminated and humid compressed air will result in premature bearing wear. • The selected speed must not exceed the maximum allowed revolutions of the instrument to be used. -
Page 24: A 9 Maintenance
A 9 Maintenance The following are authorized to repair and service the KaVo ELECTROtorque: • the engineers of KaVo agents through- out the world • the engineers of authorised KaVo dealers who have been specially trained by KaVo • independent engineers specially trained by KaVo. -
Page 25: A 10 Troubleshooting
1 . The following are authorized to repair and service the KaVo ELECTROtorque: • the engineers of KaVo agents through- out the world • the engineers of authorised KaVo dealers who have been specially trained by KaVo • independent engineers specially trained by KaVo. - Page 26 (90°C/194°F). R•Stop working until the temperature at the cooling element falls below 90°C/194°F. After the value has fallen below the limit, the ELECTROtorque 4890 auto- matically switches back to the ready mode. F• Error message: F 7 When the ELECTROtorque 4890 is switched on, the program memory is tested.
-
Page 27: B 1 Important Information
ELECTROtorque 4890/K200. B 1 Important information B 1.1 Transport and storage The packaging consists of board, Ethafoam and Styropor with supercorrugated cardboard as additional packaging. Information on transport and unpacking is printed on the outside. It applies to transport and storage. -
Page 28: B 1.2 What To Do In The Event Of Damage During Transport
Contact KaVo, Shipping Department, within 4 days. Tel: (0 75 61) 86-0 In order to make any claims for the damage, KaVo requires the shipping note with confirmation of damage. On no account return damaged goods to KaVo before contacting KaVo. -
Page 29: Guarantee Information
Within the scope of the current Delivery and Payment Conditions, KaVo EWL warrants the unit to be free from malfunctions, defects in both materials and workmanship for a period of six months from the date of purchase. At the end of this warranty period, KaVo provides a further 6-month guarantee for faults arising, which can be traced back to deficiencies in materials or the manufacturing process. -
Page 30: Spare Parts
ELECTROtorque 4890/K200. 0.516.5850 1.001.7014 o r q e r s r e v 1.001.2876 (AT 1.001.7113) 1.000.6717 1.001.8749 1.001.7115 1.001.5113 0.223.4142 DE 0.692.6881 CH 0.692.6891 US 0.692.6891 JP 0.692.6901 GB 0.692.6851 AU... - Page 31 ELECTROtorque 4890/K200.
- Page 32 1.001.1050 - 07.03 - 1 Dear dentist: KaVo hopes that you will benefit greatly from working with your new quality product, the INTRA LUX motor K 200. Please observe the following notes to assure continued trouble-free, economical and safe product...
- Page 33 The spray water component can be dosed by turning the regulating sleeve 3 clockwise or anticlockwise. Maximum flow is obtained when the KaVo mark on the regulating sleeve lines up with the button 4. Connecting the instruments to the motor...
- Page 34 The O-rings on the motor must only be oiled by means of a cotton swab wetted with KaVo mainte- nance spray. Once per week the motor sleeve has to be taken off and the motor housing has to be wiped with a dry cloth.
- Page 35 Do not continue use in the event of irregular operating noise, excessive vibration or if the heating of the motor is exceeding. To avoid further damage, please contact the KaVo After Sales Service at Biberach, or a KaVo authorised office or your Dental Depot.
- Page 36 D D - - 8 8 8 8 2 2 9 9 9 9 L L E E U U T T K K I I R R C C H H . . T T e e l l e e f f o o n n 0 0 7 7 5 5 6 6 1 1 / / 8 8 6 6 - - 1 1 5 5 0 0 · · F F a a x x 0 0 7 7 5 5 6 6 1 1 / / 8 8 6 6 - - 2 2 6 6 5 5 I I n n t t e e r r n n e e t t : : w w w w w w .
