TVA 6950
Stud Adapter
Full Installation Guide
Everything you need to get your TV safely on the wall, in no time
Before you start
...we just wanted to say thanks for choosing Vogel's. Smart choice.
And you're already making another smart choice – reading the manual! Keep reading to learn all about safe,
efficient installation, and how to use your new accessory.
Stay safe
Warning
Always read these safety instructions carefully before installing and using this product.
Following these instructions is strictly required. Incorrect mounting and/or installation could put you,
your TV, and your family at substantial risk.
TVA 6950 Series - English
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for vogel's TVA 6950
Summary of Contents for vogel's TVA 6950
- Page 1 Stay safe Warning Always read these safety instructions carefully before installing and using this product. Following these instructions is strictly required. Incorrect mounting and/or installation could put you, your TV, and your family at substantial risk. TVA 6950 Series - English...
- Page 2 What’s in your box? Something missing? Make sure your packaging has everything in place: A. Horizontal bar (2x) B. Vertical bracket C. 4x Screws D. 7x M8 washer E. 4x M8*18mm bolts F. 1x DIN916 set screw TVA 6950 Series - English...
- Page 3 M4 (4mm) Allen key Pencil Take care of your safety Who cares about looking cool? Always wear personal protective equipment: Eye protection Ear protection Safety shoes Lifting your TV is a two-person job. Don’t be bold! TVA 6950 Series - English...
- Page 4 Max weight Model Max weight Model Max weight TVM 5445 35 kg TVM 5855 75 kg TVM 7655 35 kg TVM 5645 45 kg TVM 7675 35 kg TVM 5845 55 kg Important positioning information TVA 6950 Series - English...
- Page 5 Ready… set… get installing! Step 1: Attach the bottom horizontal bar to the wall TVA 6950 Series - English...
- Page 6 2. Use a tape-measure to determine the spacing between the studs. 3. Determine which lock holes to use that correspond with the spacing between the studs. 4. Determine the height of your stud adapter and mark the drilling holes using the bottom horizontal bar. TVA 6950 Series - English...
- Page 7 5. Remove the bottom horizontal bar. 6. Now for the fun part… drilling the holes. TVA 6950 Series - English...
- Page 8 7. Attach the bottom horizontal bar Ⓐ to the wall with the screws Ⓒ and washers Ⓓ from the mounting kit. Step 2: Set the vertical bracket length to match your wall mount. TVA 6950 Series - English...
- Page 9 4. Tighten the set screw using the allen key. Step 3: Attach the top horizontal bar and vertical bracket(s) 1. Attach the top horizontal bar to the vertical bracket(s) Ⓑ . Temporarily put the assembly in the bottom horizontal bar. TVA 6950 Series - English...
- Page 10 2. Use the spirit level to level the top horizontal bar. Mark the drilling holes TVA 6950 Series - English...
- Page 11 3. Remove the top horizontal bar and the vertical bracket(s). 4. Now for the fun part… drilling the holes. TVA 6950 Series - English...
- Page 12 5. Loosen the bolt that connects the top horizontal bar with the vertical bracket(s). Remove the vertical bracket(s). TVA 6950 Series - English...
- Page 13 9. Consult the illustration ‘Positioning information’ for information on attaching your specific wall mount model. NOTICE For the TVM 5855 an extra service kit is required. 10. Use the bolts to attach the wall mount and the vertical bracket(s) to the horizontal bars at the same time. TVA 6950 Series - English...
- Page 14 11. Mount the TV screen to the wall mount according to the wall mount manual. Confused? Unsure? Going crazy? There’s plenty of help waiting for you, online: info@vogels.com www.vogels.com/contact facebook.com/ VogelsForSure/ instagram.com/ vogels_official/ www.youtube.com/ c/VogelsForSure TVA 6950 Series - English...
- Page 15 FAQs ‘What if I need spare If you require a spare part, please contact your local dealer or Vogel's. Click parts?’ here to contact Vogel's Consumer Care. ‘Why do you use The Fischer©...
- Page 16 Vogel’s guarantee shall lapse in the following cases: If the product has not been installed or used in accordance with the instructions; If applicable, if the holes in the wall have not been properly drilled in accordance with the Vogel's installation instructions for the applicable wall type;...
