Pilz SB 3075-3 ETH-2 SE Programmable Safety System Limited Availability Used and in Excellent Condition Open Web Page https://www.artisantg.com/53354-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
Page 2
PSS 3075-3 Series ® Programmable control systems PSS Operating Manual – Item No. 21 071-10...
Page 4
Contents Introduction Validity of documentation Overview of documentation Definition of symbols Overview Front views PSS 3075-3, PSS 3075-3 NR PSS 3075-3 DP-S PSS SB 3075-3 PSS SB 3075-3 DP-S 2-10 PSS SB 3075-3 ETH-2, PSS SB 3075-3 ETH-2 SE 2-12...
Page 5
Configuration coding Installation General requirements Installing the safety system Installing the safety system PSS 3075-3, PSS 3075-3 NR Installing the safety system PSS 3075-3 DP-S, PSS SB 3075-3, PSS SB 3075-3 ETH-2 and PSS SB 3075-3 ETH-2 SE Installing the safety system PSS SB 3075-3 DP-S,...
Page 6
Programming device interface RS 485 User interface (“USER”) User interface RS 232 User interface RS 485 SafetyBUS p interface (“SafetyBUS p”) Interfaces for standard bus connections Operation and Maintenance Commissioning Faults PSS and SafetyBUS p functionality Standard bus functionality Operating Manual: PSS 3075-3 Series...
Page 7
Display elements PSS functionality SafetyBUS p functionality Standard bus functionality Changing the battery Technical Details 10-1 Derating diagrams 10-6 Accessories 10-7 Appendix 11-1 Address of Safety Network International e.V. 11-1 Changes in the documentation 11-1 Operating Manual: PSS 3075-3 Series...
Page 8
PSS 3075-3 series. A PSS in the PSS SB 3075-3 series is a 3rd generation programmable safety system.
Page 9
This documentation is valid for the following programmable safety systems from the PSS 3075-3 series: • PSS 3075-3 from Version 1.0 • PSS 3075-3 DP-S from Version 1.0 • PSS 3075-3 NR from Version 1.0 • PSS SB 3075-3 from Version 1.0 •...
Page 10
This chapter describes the configuration of the available interfaces. Operation and Maintenance This chapter explains how to commission the safety systems and advises on what to do if a fault occurs. 10 Technical Details 11 Appendix Operating Manual: PSS 3075-3 Series...
Page 11
This describes a situation in which the unit(s) could be damaged and also provides information on preventive measures that can be taken. INFORMATION This gives advice on applications and provides information on special features, as well as highlighting areas within the text that are of particular importance. Operating Manual: PSS 3075-3 Series...
Page 12
- 9 dual-pole outputs - Programming device interface (combined RS 232/RS 485 interface) - User interface (combined RS 232/RS 485 interface) • In addition to the features on the PSS 3075-3, the PSS SB 3075-3 contains: - SafetyBUS p-interface Additional functions • DP-S Interface for connection to PROFIBUS-DP •...
Page 13
Overview Example: PSS SB 3075-3 ETH-2 Safety systems PSS 3075-3 with SafetyBUS p- and Ethernet interface. The digital inputs can be used for local emergency stop monitoring, for example. They are suitable for connecting single or dual-channel input devices, with or without test pulses. The test pulse outputs are suitable for testing input devices.
Page 15
Overview Front views PSS 3075-3, PSS 3075-3 NR Fig. 2-1: Front view of PSS 3075-3 Operating Manual: PSS 3075-3 Series...
Page 16
9: Supply voltage connection (24 VDC) for internal supply of the safety system and the outputs at X1, X2 10: Digital outputs and test pulse outputs 11: Digital inputs 12: Functional earth connection 13: Supply voltage connection (24 VDC) for outputs at X8, X9 Operating Manual: PSS 3075-3 Series...
Page 17
Overview PSS 3075-3 DP-S Fig. 2-2: Front view of PSS 3075-3 DP-S Operating Manual: PSS 3075-3 Series...
Page 18
14: 2-position switch for selecting the station address (PROFIBUS-DP) 15: Rotary switch for setting the station address (PROFIBUS-DP) 16: LED for status of PROFIBUS-DP 17: PROFIBUS-DP interface INFORMATION Please refer also to the manual: “PROFIBUS-DP for Compact 3 Generati- on PSS”. Operating Manual: PSS 3075-3 Series...
Page 19
Overview PSS SB 3075-3 Fig. 2-3: Front view of PSS SB 3075-3 Operating Manual: PSS 3075-3 Series...
Page 20
10: Digital outputs and test pulse outputs 11: Digital inputs 12: Functional earth connection 13: Supply voltage connection (24 VDC) for outputs at X8, X9 14: LED for status of SafetyBUS p 15: SafetyBUS p interface Operating Manual: PSS 3075-3 Series...
Page 22
16: LED for status of PROFIBUS-DP 17: PROFIBUS-DP interface 18: LED for status of SafetyBUS p 19: SafetyBUS p interface INFORMATION Please refer also to the manual: “PROFIBUS-DP for Compact 3 Generati- on PSS” Operating Manual: PSS 3075-3 Series 2-11...
Page 23
Overview PSS SB 3075-3 ETH-2, PSS SB 3075-3 ETH-2 SE Fig. 2-5: Front view of PSS SB 3075-3 ETH-2 2-12 Operating Manual: PSS 3075-3 Series...
Page 24
- Status of network connection (LINK) - Status of data traffic (TRAFFIC) 16: LED for status of SafetyBUS p 17: SafetyBUS p interface INFORMATION Please refer also to the manual: “ETH-2 for Compact 3rd Generation PSS”. Operating Manual: PSS 3075-3 Series 2-13...
Page 26
17: LED for the CANopen data cable status 18: CANopen interface 19: LED for status of SafetyBUS p 20: SafetyBUS p interface INFORMATION Please refer also to the manual: “CANopen for Compact 3 Generation PSS”. Operating Manual: PSS 3075-3 Series 2-15...
Page 28
(2 free ports); LEDs on each port for - Status of network connection (LINK) - Status of data traffic (TRAFFIC) INFORMATION Please refer also to the manual: “CANopen for Compact 3 Generation PSS” and “ETH-2 for Compact 3 Generation PSS”. Operating Manual: PSS 3075-3 Series 2-17...
Page 30
Safety Intended use Programmable safety systems from the PSS 3075-3 series are intended for use as follows: • Safety-related applications in the PSS failsafe section • Non-safety-related applications in the PSS standard section INFORMATION The following system software is required in order to program the safety systems: •...
Page 31
Please note: To achieve the corresponding category or requirement class, the whole system including all safety-related components (parts, devices, user program etc.) must be included in the assessment. For this reason, Pilz cannot accept liability for the correct classification into a category or requirement class. Digital inputs (DI2)
Page 32
• All health and safety / accident prevention regulations for the particular area of application must be observed. • Before using the unit it is necessary to perform a safety assessment in accordance with the Machinery Directive 98/37/EC. Operating Manual: PSS 3075-3 Series...
Page 33
• Any type of modification has been made (e.g. exchanging components on the PCB boards, soldering work etc.). Disposal The programmable safety system must be disposed of properly when it reaches the end of its service life. Operating Manual: PSS 3075-3 Series...
Page 34
A four-digit display and several LEDs provide information on the status of the safety system and indicate any errors. Interfaces CPU interfaces The CPU of each programmable safety system in the PSS 3075-3 series provides the following interfaces: • Programming device interface Combined RS 232 interface (minimum configuration: TxD, RxD, GND)/ RS 485 •...
Page 35
Function Description Inputs Programmable safety systems from the PSS 3075-3 series have 48 digital inputs (DI2), 6 of which can be configured as alarm inputs (DIF). The digital input signals must show a “High” (“1” signal) of 24 VDC (+15 ...
Page 36
Description” from the “PSS System Manual for the compact/modular PSS” Outputs Programmable safety systems from the PSS 3075-3 series have 18 single- pole outputs (DOS) and 9 dual-pole outputs (DOZ). 4 of the single-pole outputs can be configured as test pulse outputs (DOT).
Page 37
(output’s diode not lit up). If you then generate a short circuit between the output and 0 V, the desired error reaction should occur. In the worst case, the error reaction should occur within 30 minutes. Operating Manual: PSS 3075-3 Series...
Page 38
Each time SB255, function 2 is called, data words DW200, DW201 and DW202 must be written in full to ensure that outputs are not excluded from the power-up test unintentionally, due to data words being unwittingly overwritten during the program cycle. Operating Manual: PSS 3075-3 Series...
Page 39
DB003 DW200 Slot number on the PSS 3075-3 series: 2 / 4 DW201 Masks for outputs 2.00 ... 2.15 / 4.00 ... 4.15 If this is set on a bit belonging to an output, the power-up test for this output will be deactivated.
Page 40
PSS will switch to a STOP condition, switch off the outputs and send a message to the CPU-display. All outputs are protected against short-circuit, overload and excess temperature. They can switch both resistive and inductive loads. Operating Manual: PSS 3075-3 Series...
Page 42
Drill M4 holes in the control cabinet’s mounting plate, as shown in the illustrations (tolerance: +/-0.3 mm/0.012"). Attach the safety system to the mounting plate in your control cabinet, using washers. Operating Manual: PSS 3075-3 Series...
Page 43
Installing the safety system PSS 3075-3 and PSS 3075-3 NR Option B: Option A: Fig. 5-1: Installation options for the programmable safety system PSS 3075-3 and PSS 3075-3 NR Dimensions stated in mm (") Dimensions in mm (") excluding interfaces and operating controls : H x W x D: 246.4 x 123.6 x 162 (9.70"...
Page 44
PSS SB 3075-3 ETH-2 and PSS SB 3075-3 ETH-2 SE Option B: Option A: Fig. 5-2: Installation options for the programmable safety system PSS 3075-3 DP-S, PSS SB 3075-3, PSS SB 3075-3 ETH-2 and PSS SB 3075-3 ETH-2 SE Dimensions stated in mm (") Dimensions in mm (") excluding interfaces and operating controls :...
Page 45
PSS SB 3075-3 CANopen and PSS SB 3075-3 ETH-2 CANopen Dimensions stated in mm (") Dimensions in mm (") excluding interfaces and operating controls : H x W x D: 246.4 x 196.8 x 162 (9.70" x 7.58" x 6.38") Operating Manual: PSS 3075-3 Series...
Page 46
Installing the safety system in a control cabinet Fig. 5-4: Installing safety systems from the PSS 3075-3 series in a control cabinet (example: PSS 3075-3), dimensions stated in mm (") Operating Manual: PSS 3075-3 Series...
Page 48
Safe electrical isolation must be ensured for the external 24 V supply. Failure to do so could result in electric shock. Power supplies must conform to EN 60950, 03/97, section 2.3, EN 60742, 9/95 or EN 50178, 10/97. Operating Manual: PSS 3075-3 Series...
Page 49
• The external power supply for the programmable safety system should be connected as shown in Fig. 6-1. Fig. 6-1: Supplying programmable safety systems from the PSS 3075-3 series • The external power supply for the outputs on the programmable safety system should be connected as shown in Fig.
Page 50
X1/X2, X8/X9). Please refer to Chapter 7, “Wiring the Inputs and Outputs”. Notes on wiring • Minimum range for cable cross sections on field connection terminals in - Power supply: 1.5 (AWG16) ... 2.5 (AWG12) - Functional earth: 2.5 (AWG12) Operating Manual: PSS 3075-3 Series...
Page 51
• The torque setting on the terminals should be 0.5 … 0.6 Nm. • Earthing: - Connect the housing to the central earth bar. - A cable cross section of at least 2.5 mm should be used. - Connections should be kept as short as possible. Operating Manual: PSS 3075-3 Series...
Page 52
I1.0 ... I1.7 I0.0 ... I0.7 I0.16 ... I0.23 I1.8, I1.9 I0.8 ... I0.15 I0.24 ... I0.31 I3.0 ... I3.5 (alarm outputs) Fig. 7-1: Terminal configuration on programmable systems from the PSS 3075-3 series (Example: PSS 3075-3) Operating Manual: PSS 3075-3 Series...
Page 53
• Connecting and laying the cables - Screened cables are not required for digital I/Os. However, if the connection cables have screening, it should be connected at one end. Operating Manual: PSS 3075-3 Series...
Page 54
• Signal inputs with frequent operation are signals that change status on several occasions within a period of time. • Single-channel safe input devices are positively-driven, normally-closed contacts which open on actuation (failsafe principle). Operating Manual: PSS 3075-3 Series...
Page 55
If necessary, the supply to the system can be buffered. CAUTION! The connection shown overleaf is only approved for non-safety applications. The connection of input devices for safety-related applications is described in the examples that follow. Operating Manual: PSS 3075-3 Series...
Page 56
Please ensure safety regulations and EMC guidelines are met! Operating Manual: PSS 3075-3 Series...
Page 57
Depending on the type of input device connected, this could create a risk to both personnel and machinery (e.g. E-STOP). Always ensure that the unit is suitably wired to eliminate the risk of short circuits. Operating Manual: PSS 3075-3 Series...
Page 58
Single-channel, failsafe input device Please ensure safety regulations and EMC guidelines are met! Operating Manual: PSS 3075-3 Series...
Page 59
Depending on the type of input device connected, this could create a risk to both personnel and machinery (e.g. E-STOP). Always ensure that the unit is suitably wired to eliminate the risk of short circuits. Operating Manual: PSS 3075-3 Series...
Page 60
Input for other input devices Dual-channel input device with identical (homogenous) channels (max. Cat. 3) Dual-channel input device with different (diverse) channels Please ensure safety regulations and EMC guidelines are met! Operating Manual: PSS 3075-3 Series...
Page 61
With 1 kOhm resistance parallel to input: max. 800 m CAUTION! Short circuits between the cable from the signal to the input device and the cable from the input device to the input will not be detected. 7-10 Operating Manual: PSS 3075-3 Series...
Page 62
Single- channel, failsafe input device Test pulse 0 Please ensure safety regulations and EMC guidelines are met! Operating Manual: PSS 3075-3 Series 7-11...
Page 63
(cable from the signal to the input device and cable from the input device to the input). • Cable runs: 200 m; With 1 kOhm resistance parallel to input: max. 800 m 7-12 Operating Manual: PSS 3075-3 Series...
Page 64
Dual-channel input Dual-channel input device with device with diverse identical channels channels Test pulse 2 Test pulse Please ensure safety regulations and EMC guidelines are met! Operating Manual: PSS 3075-3 Series 7-13...
Page 65
(see example, “Alarm test”). • If cable runs exceed 50 m, a resistance of 1 kOhm must be connected in parallel with the input. Maximum cable runs will then be 400 m. 7-14 Operating Manual: PSS 3075-3 Series...
Page 66
Input I3.0 Input I3.5 Please ensure safety regulations and EMC guidelines are met! Operating Manual: PSS 3075-3 Series 7-15...
Page 67
Depending on the type of input device connected, this could create a risk to both personnel and machinery (e.g. E-STOP). Always ensure that the unit is suitably wired to eliminate the risk of short circuits. 7-16 Operating Manual: PSS 3075-3 Series...
Page 68
Test pulse 0 Test pulse Please ensure safety regulations and EMC guidelines are met! Operating Manual: PSS 3075-3 Series 7-17...
Page 69
Please note that the second shutdown route is only tested when the safety system switches from STOP to RUN and that a feedback loop must be used with single-channel operation. To achieve category 4, two actuators must be connected in series to two different outputs. 7-18 Operating Manual: PSS 3075-3 Series...
Page 70
- Use an additional shutdown device such as a main contactor Test pulse outputs O/T2.0 ... O/T2.3 supply test pulses for input devices or are used as single-pole outputs Please ensure safety regulations and EMC guidelines are met! Operating Manual: PSS 3075-3 Series 7-19...
Page 71
In this case it helps to have a 1 kOhm resistor connected in parallel to the contactor coil. • Each output is protected against short-circuit, overload and excess temperature. Outputs are designed for resistive and inductive loads. 7-20 Operating Manual: PSS 3075-3 Series...
Page 73
Wiring the Inputs and Outputs Notes 7-22 Operating Manual: PSS 3075-3 Series...
Page 74
• If you are using longer cables and there is the possibility of transient currents, you can prevent these by using equipotential bonding cables. If you are unable to use equipotential bonding cables, connect the screening at one end. Operating Manual: PSS 3075-3 Series...
Page 75
9-pin RS 232 RS 485 1: RxD 2: R1 5: GND 3: B 6: TxD 4: R2 5: GND 7: A 8: R3 n.c. = not connected Fig. 8-1: Configuration of the programming device interface Operating Manual: PSS 3075-3 Series...
Page 76
This adapter is available under order number 311 080. Programming device (Female 9-pin D-Sub connector) (Female 9-pin D-Sub connector) Screening Fig. 8-2: Connection cable between programming device and PSS Operating Manual: PSS 3075-3 Series...
Page 77
Interface adapter (Female 9-pin D-Sub connector) programming device (Female 9-pin D-Sub connector) Screening Fig. 8-3: RS 485 connection cable from the PSS to the interface adapter or programming device, with links to activate the terminating resistors Operating Manual: PSS 3075-3 Series...
Page 78
Male D-Sub connector 9-pin RS 232 RS 485 2: RxD 1: A 3: TxD 5: GND 4: DTR 9: B 5: GND 6: DSR 7: RTS 8: CTS Fig. 8-4: Configuration of the user interface Operating Manual: PSS 3075-3 Series...
Page 79
INFORMATION To connect PX(T) display systems, PMI graphics systems and the Pilz MPI adapter to the RS 232 user interface on the PSS you will need a cable with a layout as shown in Fig. 8-5. This cable is available under order number 301 965.
Page 80
(USER) button on the front of the module to the OFF position. This will enable you to build up an RS 485 network. Button R Status (USER) Button operated, Terminating resistors are ON position connected Button not operated, Terminating resistors are OFF position disconnected Operating Manual: PSS 3075-3 Series...
Page 81
Interfaces for standard bus connections The standard bus interfaces are described in separate operating manuals. The necessary operating manuals are supplied with each programmable safety system in the PSS 3075-3 series, depending on the unit type. Operating Manual: PSS 3075-3 Series...
Page 82
• Bus diagnostics via a corresponding network analyzer Network analyzers from various companies are available for the different bus systems. Further information can be found in the operating manual for the relevant analyzer. Operating Manual: PSS 3075-3 Series...
Page 83
The LED lights as soon as the connection to SafetyBUS p is made. Standard bus functionality Various operating and fault statuses are displayed via the LEDs on the various standard bus interfaces (see operating manual for the relevant standard bus system). Operating Manual: PSS 3075-3 Series...
Page 84
If the battery voltage drops below 2.5 V, the CPU will issue the error message “S-04”. You should then change the battery, Only use a battery type that has been approved by Pilz (see chapter entitled “Technical De- tails”). Battery types that are approved by Pilz are “UL-Recognized”.
Page 85
Remove the cap from the “F-STACK” button. Fig. 9-1: Changing the battery, part 1 (example: PSS 3075-3) CAUTION! Adverse effect on the safety functions! Please ensure that no metal parts get into the open PSS system, as this could adversely affect the system’s safety functions.
Page 86
Change the battery and close up the housing. Fig. 9-2: Changing the battery, part 2 (example: PSS 3075-3) NOTICE Make sure all the screws are tightened up securely, to ensure the housing is properly connected to the functional earth.
Page 88
Supply voltage 24 VDC Tolerance 20 ... 30 VDC including residual ripple of max. ± 1.2 V Current consumption “PSS PWR” PSS 3075-3, PSS 3075-3 NR Max. 570 mA PSS 3075-3 DP-S Max. 680 mA PSS SB 3075-3 Max. 740 mA...
Page 89
Combined RS 232 (with minimum configuration)/RS 485 interface for programming device, Combined RS 232/RS 485 as user interface (termination is selectable) Battery (not on PSS 3075-3 NR) Lithium, Type CR2477N (see accessories) Service life ca. 2 years SafetyBUS p Status display Transmission rate Max.
Page 90
-1 VDC at 3.5 A Switch-off delay Test pulses: ca. 50 µs Single-pole outputs: < 200 µs On time during self test ca. 200 µs Off time during self test 400 µs ... 500 µs Operating Manual: PSS 3075-3 Series 10-3...
Page 91
Frequency range: 10 ... 57 Hz Amplitude: 0.075 mm Frequency range: 57 ... 150 Hz Acceleration: 1g Shock EN 60068-2-27, 03/93 15g, 11 ms EN 60068-2-29, 04/93 10g, 16 ms EN 61000-6-2, 08/02 EN 61000-6-4, 08/02 10-4 Operating Manual: PSS 3075-3 Series...
Page 92
3150 g Dimensions (H x W x D) PSS 3075-3, PSS 3075-3 NR 246.4 x 123.6 x 162 mm PSS 3075-3 DP-S, PSS SB 3075-3, PSS SB 3075-3 ETH-2 (SE) 246.4 x 160.2 x 162 mm PSS SB 3075-3 DP-S,...
Page 93
Derating diagrams Current load capacity of the outputs, depending on the ambient temperature T Max. current load capacity of 3.5 A when T >45 °C Continuous duty: 60% based on T : 40 s 10-6 Operating Manual: PSS 3075-3 Series...
Page 94
3074 to one for a PSS from the PSS 3047- 3/PSS 3075-3 series) Lithium Type CR2477N 300 930 3.0 V 950 mAh The names of products, goods and technologies used in this manual are trademarks of the respective companies. Operating Manual: PSS 3075-3 Series 10-7...
Page 96
Changes in the documentation Changes in Version 21 071-02 Change page page Additional PROFIBUS interface (PSS 3075-3 DP-S), expanded in various places Changes in Version 21 071-03 Change page page Additional PSS SB 3075-3 and PSS SB 3075-3 DP-S,...
Page 97
Changes in Version 21 071-08 Change page page 10-3 10-3 Technical details was amended Changes in Version 21 071-09 Change page page Additional PSS SB 3075-3 ETH-2 CANopen, expanded in various places 11-2 Operating Manual: PSS 3075-3 Series...
Page 98
Changes in Version 21 071-10 Change page page Additional PSS 3075-3 NR, expanded in various places Operating Manual: PSS 3075-3 Series 11-3...
