- Page 1 WOODEN WORKBENCH MODEL NO: CH1500B PART NO: 6500129 ASSEMBLY INSTRUCTIONS ORIGINAL INSTRUCTIONS GC 03-24...
- Page 2 When unpacking, check for any damage that may have occurred in transit and notify your CLARKE dealer immediately should any be apparent. Confirm against the inventory on pages 4-6 that all items are present. Product Dimensions (D x W x H)
- Page 3 GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt which will be required as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended.
- Page 4 PACK CONTENTS A) Side piece (pair) B) Left leg frame C) Right leg frame D) Shelf base E) Drawer holder (left and right handed pair) F) Worktop Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
- Page 5 G) Drawer front H) Drawer side I) Drawer base J) Drawer rear K) Outer Drawer Runner(pair) L) Inner Drawer Runner (pair) M) Steel locating dog (x4) N) Woodworkers vice assembly(pair) Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
- Page 6 P) Workbench pegs (x 4) Q) Shelf machine screw & barrel nut s(x4) R) Wood screw S) Machine screws (Long (x4)/Short (x4)) (Long (x8)/Short) (x6) ASSEMBLY 1. Insert the barrel nuts (Q) into the side pieces (A). 2. Use the machine screws (Q) to secure both leg frames (B and C) to one of the...
- Page 7 At this stage the frame should look like this. 3. Slide the shelf base (D) into the grooves in the side pieces as shown. 4. Secure the second side piece to the two leg frames using machine screws (Q) and barrel nuts. Parts &...
- Page 8 At this stage the frame should look like this. The outer drawer runners (K) need to be fitted to both the drawer holders (E). • The inner runners (L) will be fitted to the side panels of the drawer. Identify which runner is for the drawer (inner) and which is for the holders (outer).
- Page 9 7. Fit the legs into position and secure the assembly using long machine screws (S). 8. Turn the assembly the right way up. 9. Take the drawer side panels (H) and determine which is left and right and therefore which is the outside surface of each panel.
- Page 10 DRAWER ASSEMBLY 11.1 11.2 Fit the rear of the drawer (J) to one of Fit the other side (H) as shown. the drawer sides (H) and fix into position using the long screws (R) provided. 11.3 11.4 Rotate the drawer and slide the Fix the drawer front (G) as shown drawer base (I) into position.
- Page 11 13. Fit both vice assemblies as shown, inserting the guides and screw thread into the sockets in the bench and screwing home as required. 14. Fit the locating pegs and dogs into their locating holes as required. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
