Edge Computing Appliance Platform
Hardware Platforms for Edge Computing
ECA-6040
User Manual
Date of Release:2024-11-04
1
Version: 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECA-6040 and is the answer not in the manual?

Questions and answers

Related Manuals for Lanner ECA-6040

Summary of Contents for Lanner ECA-6040

  • Page 1 Edge Computing Appliance Platform Hardware Platforms for Edge Computing ECA-6040 User Manual Version: 1.0 Date of Release:2024-11-04...

  • Page 2: About This Document

    - assumed to be qualified in the servicing of computer equipment, such as professional system integrators, or service personnel and technicians. The latest version of this document can be found on Lanner’s official website, available either through the product page or through the Lanner Download Center page with a login account and password.

  • Page 3: Contact Information

    221 新北市汐止區 service@ls-china.com.cn 大同路二段 173 號 7 樓 T: +886-2-8692-6060 F: +886-2-8692-6101 contact@lannerinc.com Canada Lanner Electronics Inc. Lanner Electronics Canada Ltd 47790 Westinghouse Drive 3160A Orlando Drive Fremont, CA 94539 Mississauga, ON T: +1-855-852-6637 L4V 1R5 Canada F: +1-510-979-0689 T: +1 877-813-2132 sales_us@lannerinc.com...

  • Page 4: Copyright And Trademarks

    Copyright and Trademarks This document is copyrighted © 2024. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of the original manufacturer.

  • Page 5: Safety Guidelines

    Safety Guidelines Follow these guidelines to ensure general safety: Keep the chassis area clear and dust-free during and after installation. Avoid wearing loose clothing or jewelry that could catch in the chassis. Secure ties, scarves, and roll up sleeves. Wear safety glasses if you are working under any conditions that might be hazardous to your eyes. Do not perform any action that creates a potential hazard to people or makes the equipment unsafe.

  • Page 6: Sécurité De Fonctionnement

    The installation of this product must be performed by trained specialists; otherwise, a non-specialist might create the risk of the system’s falling to the ground or other damages. Lanner Electronics Inc. shall not be held liable for any losses resulting from insufficient strength for supporting the system or use of inappropriate installation components.

  • Page 7: Electrical Safety Instructions

    Warning Class I Equipment. This equipment must be earthed. The power plug must be connected to a properly wired earth ground socket outlet. An improperly wired socket outlet could place hazardous voltages on accessible metal parts. Product shall be used with Class 1 laser device modules. Avertissement Équipement de classe I.

  • Page 8: Table Of Contents

    Table of Contents Chapter 1: Product Overview ............10 Package Content ......................... 10 Ordering Information ......................... 10 System Specifications ......................... 11 Front Panel ..........................12 Rear Panel ..........................12 Chapter 2: Motherboard information ..........13 Internal Jumpers and Connectors ....................14 Chapter 3: Hardware Setup .............
  • Page 9 Using BMC Web UI ........................54 Chapter 4: BIOS Setup ..............59 Main Page ........................... 60 Advanced Page ........................... 61 Platform Configuration ....................... 77 Socket ............................82 Server Mgmt ..........................106 Security ............................. 111 Boot Menu ..........................114 Save & Exit Menu ........................115 Appendix A: LED Indicator Explanations ........

  • Page 10: Chapter 1: Product Overview

    CHAPTER 1: PRODUCT OVERVIEW The ECA-6040 is powered by the 4th & 5th Gen Intel Xeon Scalable Processors and is a scalable, high- performance platform for telecom operators aiming to build and deploy open, efficient and secure 5G radio access networks Main Features 4th &...

  • Page 11: System Specifications

    System Specifications Form Factor 2U 19” Rackmount Intel® Xeon® Processor Scalable Family (Codenamed Sapphire Processor Options Rapids-SP/EMR-SP/Rapids-EE) CPU Socket Platform 1x LGA 4677 Chipset Intel®C741 Security Acceleration Intel® QuickAssist Technology BIOS AMI SPI Flash BIOS Technology DDR5 4800MHz RDIMM System Memory Max.

  • Page 12: Front Panel

    Front Panel Description Power Supply AC Redundant PSU PCIe Expansion 2x FH 3/4L PCIe*16 Expansion Slot PCIe Expansion 2x LP PCIe*8 Expansion Slot OCP NIC 1x OCP 3.0 NIC Slot LED Indicator Power/Status LED Indicator Reset Button For Software Reset (control by CPLD) Power Button 1x Power Button MGT Port...

  • Page 13: Chapter 2: Motherboard Information

    Description Smart Fans 6x Swappable Smart Fans CHAPTER 2: MOTHERBOARD INFORMATION Block Diagram...

  • Page 14: Internal Jumpers And Connectors

    Internal Jumpers and Connectors 1. J2: Gen 3 PCI Express x16 Slot Pin # Description Pin # Description P12V P12V P12V P12V P12V SMB_SCL SMB_CDA P3V3 P3V3 P3V3_AUX P3V3 WAKE# PERST REFCLK+ CPUPETP0 REFCLK- CPUPETN0 CPUPERP0 CPUPERN0 CPUPETP1 CPUPETN1 CPUPERP1 CPUPERN1 CPUPETP2 CPUPETN2...
  • Page 15 CPUPETP4 CPUPETN4 CPUPERP4 CPUPERN4 CPUPETP5 CPUPETN5 CPUPERP5 CPUPERN5 CPUPETP6 CPUPETN6 CPUPERP6 CPUPERN6 CPUPETP7 CPUPETN7 CPUPERP7 CPUPERN7 CPUPETP8 CPUPETN8 CPUPERP8 CPUPERN8 CPUPETP9 CPUPETN9 CPUPERP9 CPUPERN9 CPUPETP10 CPUPETN10 CPUPERP10 CPUPERN10 CPUPETP11 CPUPETN11 CPUPERP11 CPUPERN11 CPUPETP12 CPUPETN12 CPUPERP12 CPUPERN12 CPUPETP13 CPUPETN13 CPUPERP13 CPUPERN13...
  • Page 16 CPUPETP14 CPUPETN14 CPUPERP14 CPUPERN14 CPUPETP15 CPUPETN15 CPUPERP15 CPUPERN15 PAD1 PAD2 2. MCIO1: PCI Express x16 Slot Pin # Description Pin # Description PRSNTB＿N P3V3_AUX PERST P3V3_AUX CPUPERN7 WAKE# CPUPERP7 CPUPERN6 SMB_SCL CPUPERP6 SMB_CDA CPUPERN5 CPUPETN7 CPUPERP5 CPUPETP7 CPUPERN4 CPUPETP6 CPUPERP4 CPUPETN6 CPUPERN3 CPUPETN5...
  • Page 17 REFCLK+ CPUPETN1 REFCLK- CPUPETP1 CPUPERN15 CPUPETN0 CPUPERP15 CPUPETP0 CPUPERN14 P3V3 CPUPERP14 P3V3 CPUPERN13 P3V3 CPUPERP13 P3V3 CPUPERN12 P3V3 CPUPERP12 P3V3 CPUPERN11 CPUPETN15 CPUPERP11 CPUPETP15 CPUPERN10 CPUPETP14 CPUPERP10 CPUPETN14 CPUPERN9 CPUPETN13 CPUPERP9 CPUPETP13 CPUPERN8 CPUPETP12 CPUPERP8 CPUPETN12 CPUPETN9 CPUPETN11 CPUPETP9 CPUPETP11 CPUPETP8 CPUPETP10 CPUPETN8...
  • Page 18 3. J1: Power Connector Pin # Description +P12V +P5V 1. J2: Gen 3 PCI Express x16 Slot Pin # Description Pin # Description P12V P12V P12V P12V P12V SMB_SCL SMB_CDA P3V3 P3V3 P3V3_AUX P3V3 WAKE# PERST REFCLK+ CPUPETP0 REFCLK- CPUPETN0 CPUPERP0 CPUPERN0 CPUPETP1...
  • Page 19 CPUPERN2 CPUPETP3 CPUPETN3 CPUPERP3 CPUPERN3 CPUPETP4 CPUPETN4 CPUPERP4 CPUPERN4 CPUPETP5 CPUPETN5 CPUPERP5 CPUPERN5 CPUPETP6 CPUPETN6 CPUPERP6 CPUPERN6 CPUPETP7 CPUPETN7 CPUPERP7 CPUPERN7 2. J3: Gen 3 PCI Express x16 Slot Pin # Description Pin # Description P12V P12V P12V P12V P12V SMB_SCL SMB_CDA P3V3...
  • Page 20 CPUPETN8 CPUPERP8 CPUPERN8 CPUPETP9 CPUPETN9 CPUPERP9 CPUPERN9 CPUPETP10 CPUPETN10 CPUPERP10 CPUPERN10 CPUPETP11 CPUPETN11 CPUPERP11 CPUPERN11 CPUPETP12 CPUPETN12 CPUPERP12 CPUPERN12 CPUPETP13 CPUPETN13 CPUPERP13 CPUPERN13 CPUPETP14 CPUPETN14 CPUPERP14 CPUPERN14 CPUPETP15 CPUPETN15 CPUPERP15 CPUPERN15 3. MCIO11: PCI Express x16 Slot Pin # Description Pin # Description PRSNTB＿N...
  • Page 21 CPUPERN7 WAKE# CPUPERP7 CPUPERN6 SMB_SCL CPUPERP6 SMB_CDA CPUPERN5 CPUPETN7 CPUPERP5 CPUPETP7 CPUPERN4 CPUPETP6 CPUPERP4 CPUPETN6 CPUPERN3 CPUPETN5 CPUPERP3 CPUPETP5 CPUPERN2 CPUPETP4 CPUPERP2 CPUPETN4 CPUPERN1 CPUPETN3 CPUPERP1 CPUPETP3 CPUPERN0 CPUPETP2 CPUPERP0 CPUPETN2 REFCLK+ CPUPETN1 REFCLK- CPUPETP1 CPUPERN15 CPUPETN0 CPUPERP15 CPUPETP0 CPUPERN14 P3V3 CPUPERP14 P3V3...
  • Page 22 CPUPERN11 CPUPETN15 CPUPERP11 CPUPETP15 CPUPERN10 CPUPETP14 CPUPERP10 CPUPETN14 CPUPERN9 CPUPETN13 CPUPERP9 CPUPETP13 CPUPERN8 CPUPETP12 CPUPERP8 CPUPETN12 CPUPETN9 CPUPETN11 CPUPETP9 CPUPETP11 CPUPETP8 CPUPETP10 CPUPETN8 CPUPETN10 PAD1 PAD2 PAD3 PAD4 4. ATX1: Power Connector Pin # Description +P12V +P12V +P12V +P12V +P12V +P12V...
  • Page 23 1. ATX1: HDD Power Connector Pin # Description +P12V +P5V 2. CN1/CN2/CN3/CN4: SAS Connector Pin # Description Pin # Description SATA_TXP SATA_TXN SATA_RXN PRESENT SATA_RXP +P5V +P5V +P5V LED_HDD +P12V +P12V +P12V...
  • Page 24 3. J1/J2/J3/J4: SATA Connector Pin # Description SATA_TXP SATA_TXN SATA_RXN SATA_RXP PAD1 PAD2 1. ATX1: HDD Power Connector Pin # Description +P12V +P5V 2. CN1/CN2/CN3/CN4: SAS Connector Pin # Description Pin # Description +P3V3_AUX PERST2_N PE_CLK_P PE_CLK_N...
  • Page 25 PE_TX_P0 PE_TX_N0 PE_RX_N0 PE_RX_P0 PE_TX_P1 PE_TX_P3 PE_TX_N1 PE_TX_N3 PE_RX_N1 PE_RX_N3 PE_RX_P1 PE_RX_P3 PE_TX_P2 SMB_SCL PE_TX_N2 SMB_SDA PE_RX_N2 PE_WAKE# PE_RX_P2 PRSNTB_N ACT_N HOTPLUG_N +P12V +P12V +P12V PAD1 PAD2 3. MCIO1: U.2 x8 Connector Pin # Description Pin # Description REFCLK+ CPUPERP1 REFCLK- CPUPERN1 CPUPETP1...
  • Page 26 CPUPETN3 CPUPERN0 CPUPETP0 CPUPERP0 CPUPETN0 CPUPERN0 CPUPETP0 CPUPERP1 CPUPETN0 CPUPERN1 CPUPETP1 CPUPERP2 CPUPETN1 CPUPERN2 CPUPETP2 CPUPERP3 CPUPETN2 CPUPERN3 CPUPETP3 REFCLK+ CPUPETN3 REFCLK- PWR_ON_N SMB_SCL PWR_ON_N SMB_CDA PWRFL_N WAKE# PWRFL_N PRSNTB_N PRSNTB_N +P3V3_AUX PERST_N +P3V3_AUX 4. MCIO2: U.2 x8 Connector Pin # Description Pin # Description...
  • Page 27 CPUPETP3 CPUPERP0 CPUPETN3 CPUPERN0 CPUPETP0 CPUPERP0 CPUPETN0 CPUPERN0 CPUPETP0 CPUPERP1 CPUPETN0 CPUPERN1 CPUPETP1 CPUPERP2 CPUPETN1 CPUPERN2 CPUPETP2 CPUPERP3 CPUPETN2 CPUPERN3 CPUPETP3 REFCLK+ CPUPETN3 REFCLK- WAKE# +P3V3_AUX PERST_N +P3V3_AUX...

  • Page 28: Chapter 3: Hardware Setup

    CHAPTER 3: HARDWARE SETUP To reduce the risk of personal injury, electric shock, or damage to the system, please remove all power connections to shut down the device completely, and wear ESD protection gloves when conducting the steps in this chapter. Do not open the chassis cover when the system is in operation or after it has been powered on.

  • Page 29: Installing The Cpu

    Installing the CPU Please note that the system delivered to you includes the heatsink and processor. This processor comes with a rather sophisticated design, therefore, the assembly of which must be handled with exclusive tools and extreme care by professionals. Installing the processor onto the motherboard involves three stages: 1.
  • Page 30 When handling heatsink, always grip it along the axis of the fins of the heatsink to avoid fin damage. Heatsink Fins or soldering of fins might be (1U & 2U) damaged by handling heatsink holding along the long side of the heatsink.
  • Page 31 2. Place the processor carrier on top of the processor that is in the package tray aligning Pin 1 marks on the processor carrier to Pin 1 of the processor. Note: Make sure that the keying feature tabs of the processor carrier are aligned to the slots in the processor properly.
  • Page 32 Processor Carrier Assembly to Heatsink 1. If there is TIM (Thermal Interface Material) protective film on the base of heatsink, remove it. 2. Turn the heatsink over and set the Anti-Tilt wires to the locked position (outward position). 3. Align Pin 1 indicator of Processor carrier and corner cut out of Heatsink.
  • Page 33 5. Press heatsink down firmly to engage carrier latching features to the heatsink at four corners. 6. If carrier latching features do not latch the heatsink properly, engage each latching Click features by pressing the heatsink at the unlatched corner. You may hear a clicking sound when latched.
  • Page 34 3. Lift up the PHM. Turn the PHM over to locate the PIN1 corner on processor carrier and processor. 4. Then turn the PHM right side up. Line up PIN1 corner of the PHM to the bolster plate PIN1 corner. Lower the PHM vertically down over the bolster plate studs.
  • Page 35 7. Tighten all nuts on heatsink using a torque driver with a T30 bit to 8 in-lbf ± 10%.

  • Page 36: Installing The System Memory

    Installing the System Memory The motherboard supports 16 memory slots for DDR5 registered DIMM. Supported System Memory Summary Total Slots Supported DIMM Capacity 8GB, 16GB, 32GB, 64GB Memory Size Maximum 1024GB RDIMM (64GB*16) Memory Type DDR5 ECC RDIMM 4000MHZ Minimum DIMM Installed At least 1 memory module to boot and run from.

  • Page 37: Installing M.2 Nvme Storage Modules (Optional)

    Installing M.2 NVMe Storage Modules (Optional) This system supports one M.2 2242/2260 M-Key slot for storage expansion. Please follow the procedure for installation. 1. Power down the system and open the top chassis. Then, remove the PCIe bracket. 2. Locate the M.2 module slot on the motherboard. PCIe Bracket 3.

  • Page 38: Installing M.2 Sata Storage Modules (Optional)

    Installing M.2 SATA Storage Modules (Optional) This system supports one M.2 2280 BB+M-Key slot for storage expansion. Please follow the procedure for installation. 1. Power down the system and open the top chassis. Then, remove the PCIe bracket. 2. Locate the M.2 module slot on the motherboard. PCIe Bracket 3.

  • Page 39: Installing Low-Profile Pcie Expansion Card (Optional)

    Installing Low-Profile PCIe Expansion Card (Optional) ECA-6040 comes with two Low-Profile PCIe expansion slot for graphics card, ethernet or accelerator card. Please follow the instructions for installation. 1. Power off the system and open the top chassis cover. 2. Locate the LP PCIe slots. The slot bracket should be secured to the motherboard.
  • Page 40 5. Insert the clip and secure with one (1) screw. 6. Install the bracket back onto the mother board. Secure with the original three (3) screws. Repeat steps if installing a second LP module card.

  • Page 41: Installing Pcie Expansion Card (Optional)

    Installing PCIe Expansion Card (Optional) ECA-6040 is equipped with two PCIe x16 FH3/4L slots, suitable for GPU graphics card or accelerator card expansion. Please follow the instructions for installation. 1. Power off the system and open the top chassis cover.
  • Page 42 5. Align the GPU module pin slot to the socket key on the bracket. Slide the GPU module into the PCIe bracket until it is fully seated. Secure with one (1) screw. 6. Install the bracket back onto the motherboard. Secure with the original screws.
  • Page 43 10. Pick up the PCIe bracket, and align the GPU module pin slot to the socket key on the bracket. Slide the GPU module into the PCIe bracket until it is fully seated. Secure with one (1) screw. 11. Install the bracket back onto the motherboard. Secure with the original screws.

  • Page 44: Installing Ocp Nic (Optional)

    Installing OCP NIC (Optional) The system supports one OCP NIC 3.0 module. Please follow the steps for installation. 1. Power off the system and locate the OCP NIC module slot. 2. Rotate clockwise and loosen the lock- screw and remove the door. 3.

  • Page 45: Installing The Disk Drives (Optional)

    Installing the Disk Drives (Optional) This system supports four 2.5” SATA SSD drive bays. Please follow the instructions to install the disk drives. 1. Power off the system. Locate the 2.5” disk bay on the front panel. 2. To remove the tray, push the Tab for the Tab Lever to slide open, and then hold the Tab Lever to pull out the tray.
  • Page 46 HDD/SSD Contacts (bottom side), and secure the SSD with two (2) screws on each side. 5. Place the mounted disk tray back into the system. Gently slide the tray in until it is securely seated, then press the tab lever until it clicks, indicating it is locked in place.

  • Page 47: Replacing The Cooling Fans

    Replacing the Cooling Fans Cooling fans may eventually wear out. Please refer to the steps below for replacing cooling fans. When using a new cooling fan, simply reverse the steps to install the fan back into the enclosure and system. 1.

  • Page 48: Replacing The Power Supply Units

    Replacing the Power Supply Units Power supply units may wear down eventually. Please be noted that ECA-6040 series supports 1600W AC PSUs. Please prepare the power supply units that matching this capacity. 1. Power off the system. Locate the power supply units on the front panel.

  • Page 49: Chapter 3: Remote Server Management

    CHAPTER 3: REMOTE SERVER MANAGEMENT This chapter will introduce the features of Lanner’s BMC firmware and how to perform server remote management through it. The BMC firmware implements IPMI 2.0 based on ASPEED service processor. It performs all the BMC management tasks defined by IPMI 2.0. BMC firmware runs an embedded web-server for full configuration using Web UI.

  • Page 50: Bmc Firmware Functional Description

    BMC Firmware Functional Description System Health Monitoring The BMC implements system sensor monitoring feature. It could monitor voltage, temperature, and current of critical components. System Power Management The BMC implements chassis power and resets functions for system administrators to control and manage the system power behavior.
  • Page 51 User Management The BMC supports 9 IDs for IPMI user accounts. The maximum length of the username and password are 16 and 20 respectively, and the possible privilege levels are Callback, User, Operator, and Administrator. Moreover, the account creator can enable/disable the user account at any time. If not specified, the default user accounts are listed follows: User Name Password...

  • Page 52: Ipmi Commands Support List

    IPMI Commands Support List COMMANDS NETFN IPM Device “Global” Commands Get Device ID APP (06h) Cold Reset APP (06h) Warm Reset APP (06h) Get Device GUID APP (06h) BMC Watchdog Timer Commands Reset Watchdog Timer APP (06h) Set Watchdog Timer APP (06h) Get Watchdog Timer APP (06h)
  • Page 53 Delete SEL Entry Storage (0Ah) Clear SEL Storage (0Ah) Get SEL Time Storage (0Ah) Set SEL Time Storage (0Ah) Get SEL Time UTC Offset Storage (0Ah) Set SEL Time UTC Offset Storage (0Ah) LAN Device Commands Set LAN Configuration Parameters Transport (0Ch) Get LAN Configuration Parameters Transport (0Ch)

  • Page 54: Using Bmc Web Ui

    Using BMC Web UI In the address bar of your Internet browser, input the IP address of the remote server to access the BMC interface of that server. Initial access of BMC prompts you to enter username and password. A screenshot of the login screen is given below: Login Page Username: Enter your username in this field.

  • Page 55: Default Username And Password

    Default User Name and Password Username: admin Password: admin The default username and password are in lower-case characters. When you log in using the default username and password, you will get full administrative rights, and it will ask you to change the default password once you log in.

  • Page 56: First Time Wizard

    First Time Wizard After the first-time login, you will see first time wizard welcome page as the following picture. Please press the “Next” button and configure your BMC step by step. On the “IPv4”, “IPv6” and “DNS” pages, you could specify the hostname and network settings of BMC. On the “Remote Control”...

  • Page 57: Web Ui Layout

    Web UI Layout The BMC Web UI consists of various menu items: Menu Bar A screenshot of the menu bar is shown below, please select the page you would like to navigate. Menu Bar Quick Button and Logged-in User The user information and quick buttons are located at the top right of the Web UI. User Information Logged-in user information: Click the icon to view the logged-in user information.
  • Page 58 The logged-in user information shows the logged-in user’s username, privilege, with the quick buttons allowing you to perform the following functions: Refresh: Click the icon to reload the current page. Sign out: Click the icon to log out of the Web UI. Logged-in user and its privilege level This option shows the logged-in username and privilege.

  • Page 59: Chapter 4: Bios Setup

    CHAPTER 4: BIOS SETUP BIOS is a firmware embedded on an exclusive chip on the system’s motherboard. Lanner's BIOS firmware offering including market-proven technologies such as Secure Boot and Intel Boot Guard technology deliver solid commitments for the shield protection against malware, uncertified sequences and other named cyber threats.

  • Page 60: Main Page

    Main Page Setup main page contains BIOS information and project version information. Feature Description BIOS Vendor: American Megatrends Core Version: AMI Kernel version, CRB code base, X64 BIOS Compliancy : UEFI version, PI version Information BIOS Version : BIOS release version Build Date and Time : MM/DD/YYYY Access Level: Administrator / User Memory...

  • Page 61: Advanced Page

    Advanced Page Select the Advanced menu item from the BIOS setup screen to enter the “Advanced” setup screen. Users can select any of the items in the left frame of the screen.

  • Page 62: Trusted Computing

    Trusted Computing Feature Options Description Enables or disables BIOS support for security device. By Security Device Enabled disabling this function, OS will not show Security Device. TCG Support Disabled EFI protocol and INT1A interface will not be available.
  • Page 63 Trusted Computing (TPM1.2) Feature Options Description Enables or disables BIOS support for security device. By disabling Security Device Enabled this function, OS will not show Security Device. TCG EFI protocol Support Disabled and INT1A interface will not be available. Enables or disables Security Device. Enabled TPM State NOTE: Your computer will reboot during restart in order to change...
  • Page 64 Feature Options Description Enables or disables BIOS support for security device. By Security Device Enabled disabling this function, OS will not show Security Device. TCG Support Disabled EFI protocol and INT1A interface will not be available. Enabled SHA-1 PCR Bank Enables or disables SHA-1 PCR Bank.
  • Page 65 Schedules an Operation for the Security Device. Pending None NOTE: Your computer will reboot during restart in order to operation TPM Clear change State of Security Device. Platform Enabled Enables or disables Platform Hierarchy. Hierarchy Disabled Enabled Storage Hierarchy Enables or disables Storage Hierarchy. Disabled Endorsement Enabled...
  • Page 66 AST2600 Super IO Configuration...

  • Page 67: Serial Port 1 Configuration

    Serial Port 1 Configuration Feature Options Description Enabled Serial Port Enable or Disable Serial Port (COM) Disabled Device Settings IO=3F8h; IRQ = 4...

  • Page 68: Serial Port 2 Configuration

    Serial Port 2 Configuration Feature Options Description Enabled Serial Port Enables or disables Serial Port 2 Disabled Device Settings IO=2F8h; IRQ = 3...
  • Page 69 Serial Port Console Redirection Feature Options Description COM0 Enabled Enables or disables Console Redirection Console Redirection Disabled...

  • Page 70: Console Redirection Settings

    Console Redirection Settings Feature Options Description VT100: ASCII char set VT100 VT100+:Extends VT100 to support color, function keys, etc. VT100+ VT-UTF8:Uses UTF8 encoding to map Unicode chars onto 1 Terminal Type VT-UTF8 or more bytes ANSI ANSI: Extended ASCII char set 9600 Selects serial port transmission speed.
  • Page 71 Key Support Enabled terminals Disabled With this mode enabled, only text will be sent. This is to Recorder Mode Enabled capture Terminal data. Disabled Resolution 100x31 Enables or disables extended terminal resolution Enabled VT100 LINUX XTERM86 Putty KeyPad Selects FunctionKey and KeyPad on Putty. ESCN VT400...
  • Page 72 PCI Subsystem Settings Feature Options Description Above 4G Disabled Enables or disables 64bit capable Devices to be Decoded in Above Decoding Enabled 4G Address Space (Only if System Supports 64 bit PCI Decoding) Disabled If the system has SR-IOV capable PCIe Devices, this option enables SR-IOV Support Enabled or disables Single Root IO Virtualization Support.

  • Page 73: Usb Configuration

    USB Configuration Feature Options Description Enabled Enables Legacy USB support. Legacy USB Disabled Auto option disables legacy support if no USB devices are connected; Support Auto Disabledoption will keep USB devices available only for EFI applications. Enabled This is a workaround for OSes without XHCI hand-off support. The XHCI XHCI Hand-off Disabled ownership change should be claimed by XHCI driver.

  • Page 74: Network Stack Configuration

    Network Stack Configuration...

  • Page 75: Nvme Configuration

    NVMe Configuration...
  • Page 76 Control PXE Boot Feature Options Description Control Legacy PXE Disabled Select On Board LAN# Boot Boot from Enabled...

  • Page 77: Platform Configuration

    Platform Configuration Select the Platform menu item from the BIOS setup screen to enter the Platform Setup screen. Users can select any of the items in the left frame of the screen. Feature Options Description PCH Configuration None Displays and provides option to change the PCH Settings Server ME None Configure Server ME Technology Parameters...

  • Page 78: Pch Configuration

    PCH Configuration Feature Options Description SATA And RST Configuration...
  • Page 79 Controller 2 SATA and RST Configuration Feature Options Description Disabled SATA Configuration Enables or disables SATA Controller Enabled SATA Mode Selection AHCI Determines how SATA controller(s) operate. Disabled Port4 Enable or Disable SATA Port Enabled Disabled Hot Plug Designates this port as Hot Pluggable. Enabled Disabled Configured as eSATA...
  • Page 80 Enabled If enabled for any of ports Staggerred Spin Up will be Disabled Spin Up Device performed and only the drives witch have this option enabled Enabled will spin up at boot. Otherwise all drives spin up at boot. Hard Disk Drive Identify the SATA port is connected to Solid State Drive or SATA Device Type Solid State Drive...

  • Page 81: Server Me Configuration

    Server ME Configuration...

  • Page 82: Socket

    Socket Select the Socket menu item from the BIOS setup screen to enter the Socket Setup screen. Users can select any of the items in the left frame of the screen. Feature Options Description Processor None Displays and provides option to change the Processor Settings Configuration Memory None...

  • Page 83: Processor Configuration

    Processor Configuration Feature Options Description ALL LPs Enables Logical processor (Software Method Enable LP Single LP Enable/Disable Logical Processor threads) Disabled Machine Check Enable or Disable the Machine Check Enabled Hardware Disabled = MLC Streamer Prefetcher (MSR 1A4h Bit [0])
  • Page 84 Prefetcher Enabled Adjacent Cache Disabled = MLC Spatial Prefetcher (MSR 1A4h Bit [1]) Prefetcher Enabled Disabled Extended APIC Enables or disables extended APIC support Enabled Disabled Enable Intel® TXT Enables Intel(R) TXT Enabled Disabled Enables the Vanderpool Technology, which takes effect Enabled after reboot.
  • Page 85 Per-Socket Configuration Feature Options Description CPU Socket0 Configuration None None...
  • Page 86 CPU Socket0 Configuration Feature Options Description 0: Enable all cores. FFFFFFFFFFF: Disable all cores least one Core Disable core per CPU must be enabled. Disabling all cores is an Bitmap (Hex) invalid configuration.

  • Page 87: Memory Configuration

    Memory Configuration Feature Options Description Auto 3200 3600 4000 Maximum Memory Frequency Selections in Mhz. Do not select Memory Frequency 4400 Reserved. 4800 5200 5600 Memory Topology None Displays memory topology with Dimm population information...

  • Page 88: Iio Configuration

    IIO Configuration Feature Options Description Socket0 None None Configuration Intel® VT for Press <Enter> to bring up the Intel® VT for Directed I/O None Directed I/O (VT-d) (VT-d) Configuration menu. PCI-E ASPM Disable This option enables / disables the ASPM support for all Support (Global) Per-Port downstream devices.
  • Page 89 Feature Options Description Selects PCIe Subsystem Mode for selected slot(s) Port 1 Gen5 Gen4: Gen4 controller only Subsystem Mode Protocol Auto Negotiation Gen5: Gen5 with or without mix mode Auto: Auto select Port 2 Gen5 Selects PCIe Subsystem Mode for selected slot(s) Subsystem Mode Protocol Auto Negotiation Gen4: Gen4 controller only...
  • Page 90 Gen5: Gen5 with or without mix mode Auto: Auto select Selects PCIe Subsystem Mode for selected slot(s) Port 3 Gen5 Gen4: Gen4 controller only Subsystem Mode Protocol Auto Negotiation Gen5: Gen5 with or without mix mode Auto: Auto select Selects PCIe Subsystem Mode for selected slot(s) Port 4 Gen5 Gen4: Gen4 controller only...
  • Page 91 Port 1A Feature Options Description In auto mode the BIOS will remove the EXP port if there is Auto PCI-E Port no device or errors on that device and the device is not HP capable. Enable/Disable is used Auto Gen 1 (2.5 GT/s) Gen 2 (5 GT/s) Link Speed Choose Link Speed for this PCIe port...
  • Page 92 Feature Options Description In auto mode the BIOS will remove the EXP port if there Auto PCI-E Port is no device or errors on that device and the device is not HP capable. Enable/Disable is used Auto Gen 1 (2.5 GT/s) Gen 2 (5 GT/s) Link Speed Choose Link Speed for this PCIe port...
  • Page 93 Feature Options Description In auto mode the BIOS will remove the EXP port if there is no Auto PCI-E Port device or errors on that device and the device is not HP capable. Enable/Disable is used. Auto Gen 1 (2.5 GT/s) Gen 2 (5 GT/s) Link Speed Choose Link Speed for this PCIe port...
  • Page 94 Port 2A Feature Options Description In auto mode the BIOS will remove the EXP port if there Auto PCI-E Port is no device or errors on that device and the device is not HP capable. Enable/Disable is used Auto Gen 1 (2.5 GT/s) Gen 2 (5 GT/s) Link Speed Choose Link Speed for this PCIe port...
  • Page 95 Port 2E Feature Options Description In auto mode the BIOS will remove the EXP port if there Auto PCI-E Port is no device or errors on that device and the device is not HP capable. Enable/Disable is used. Auto Gen 1 (2.5 GT/s) Gen 2 (5 GT/s) Link Speed Choose Link Speed for this PCIe port...
  • Page 96 Port 3A Feature Options Description In auto mode the BIOS will remove the EXP port if there is no Auto PCI-E Port device or errors on that device and the device is not HP capable. Enable/Disable is used. Auto Gen 1 (2.5 GT/s) Gen 2 (5 GT/s) Link Speed Choose Link Speed for this PCIe port...
  • Page 97 Port 3E Feature Options Description In auto mode the BIOS will remove the EXP port if there is no Auto PCI-E Port device or errors on that device and the device is not HP capable. Enable/Disable is used Auto Gen 1 (2.5 GT/s) Gen 2 (5 GT/s) Link Speed Choose Link Speed for this PCIe port...
  • Page 98 Feature Options Description In auto mode the BIOS will remove the EXP port if there Auto PCI-E Port is no device or errors on that device and the device is not HP capable. Enable/Disable is used Auto Gen 1 (2.5 GT/s) Gen 2 (5 GT/s) Link Speed Choose Link Speed for this PCIe port...
  • Page 99 Port 4A Feature Options Description In auto mode the BIOS will remove the EXP port if there Auto PCI-E Port is no device or errors on that device and the device is not HP capable. Enable/Disable is used Auto Gen 1 (2.5 GT/s) Gen 2 (5 GT/s) Link Speed Choose Link Speed for this PCIe port...
  • Page 100 Feature Options Description In auto mode the BIOS will remove the EXP port if there Auto PCI-E Port is no device or errors on that device and the device is not HP capable. Enable/Disable is used Auto Gen 1 (2.5 GT/s) Gen 2 (5 GT/s) Link Speed Choose Link Speed for this PCIe port...
  • Page 101 Intel VT for Directed I/O (VT-d) Feature Options Description Enable/Disable Intel Virtualization Technology for Directed I/O (VT-d) by reporting the I/O device Intel VT for Enable Directed I/O Disable assignment to VMM through DMAR ACPI Tables. To disable...

  • Page 102: Advanced Power Management Configuration

    Advanced Power Management Configuration Feature Options Description P State Control Configuration Sub Menu, include Turbo, XE CPU P State Control None and etc. CPU C State Control None CPU C State setting P State Control Configuration Sub Menu, include Turbo, XE Package C State Control None and etc.
  • Page 103 CPU P State Control Feature Options Description Disabled SpeedStep (Pstates) Enables or disables EIST (P-States) Enabled Max Performance Boot performance Select the performance state that the BIOS will set Max Efficient mode before OS hand off. Set by Intel Node Manager CPU Flex Ratio Disabled Enable/Disable CPU Flex Ratio Programming...
  • Page 104 CPU C State Control Feature Options Description CPU C1 auto Disabled Autonomous Core C-State Control demotion Enabled Disabled Enable/Disable CPU C6(ACPI C3) report to OS, Auto maps to CPU C6 report Enabled enable Auto Enhanced Halt Disabled Core C1E auto promotion Control. Takes effect after reboot. State (C1E) Enabled...
  • Page 105 Package C State Control Feature Options Description C0/C1 state C2 state C6 (non Retention) state Package C State limit, the state Auto maps is Package C State C6 (Retention) state program specific. No Limit Auto...

  • Page 106: Server Mgmt

    Server Mgmt Feature Options Description Enabled BMC Support Enable or disables interfaces to communicate with BMC. Disabled Wait For BMC response for specified time out. In PILOTII, Enabled BMC starts at the same time when BIOS starts during AC Wait For BMC Disabled power ON.
  • Page 107 Enter the value Between 1 to 30 min for OS Boot Watchdog OS Wtd Timer Timer Expiration. Not available if OS Boot Watchdog Timer is Timeout disabled. Do Nothing Configure how the system should respond if the OS Boot OS Wtd Timer Reset Watchdog Timer expires.
  • Page 108 System Event Log Feature Options Description Disabled Enables or disables all features of System Event SEL Components Enabled Logging during boot. Erase SEL Yes, On next reset Choose options for erasing SEL. Yes, On every reset Do Nothing When SEL is Full Erase Immediately Choose options for reactions to a full SEL.

  • Page 109: Bmc Network Configuration

    BMC Network Configuration Feature Options Description Select to configure LAN channel parameters statically or Unspecified dynamically (by BIOS or BMC). The unspecified option will Configuration Static not modify any BMC network parameters during BIOS Address source DynamicBmcDhcp phase. DynamicBmcNonDhcp...
  • Page 110 View System Event Log...

  • Page 111: Security

    Security Select the Security menu item from the BIOS setup screen to enter the Security Setup screen. Users can select any of the items in the left frame of the screen. Feature Description If ONLY the Administrator's password is set, it only limits access to Administrator Password Setup and is only asked for when entering Setup.
  • Page 112 Secure Boot Feature Options Description Secure Boot is activated when Platform Key (PK) is enrolled, System mode Disabled Secure Boot is User/Deployed, and CSM function is disabled. Enabled Secure Boot mode selector: Secure Boot Standard In Custom mode, Secure Boot Variables can be configured without Mode Custom authentication...

  • Page 113: Key Management

    Key Management Feature Options Description Factory Key Disabled Provision factory default keys on next re-boot only when System Provision Enabled in Setup Mode. Restore Factory Force System to User Mode. Configure NVRAM to contain OEM- None Keys defined factory default Secure Boot keys. Allows the image to run in Secure Boot mode.

  • Page 114: Boot Menu

    Boot Menu Select the Boot menu item from the BIOS setup screen to enter the Boot Setup screen. Users can select any of the items in the left frame of the screen. Feature Options Description The Number of seconds to wait for setup activation key. Setup Prompt Timeout 65535 means indefinite waiting.

  • Page 115: Save & Exit Menu

    ECA-6040 User Manual Save & Exit Menu Select the Save and Exit menu item from the BIOS setup screen to enter the Save and Exit Setup screen. Users can select any of the items in the left frame of the screen.
  • Page 116 ECA-6040 User Manual ■ Restore Defaults Restore default values for all setup options. Select “Yes” to load Optimized defaults. Note: The items under Boot Override may not have the same image as above, as it would depend on the actual devices connected on system.

  • Page 117: Appendix A: Led Indicator Explanations

    ECA-6040 User Manual APPENDIX A: LED INDICATOR EXPLANATIONS System Power / Status / HDD Activity Green: System Power Red/Green: System Status Amber: HDD Activity COLOR COLOR LED ACTION DESCRIPTION ON LCM ON BOARD Green Green Steady When system power on...

  • Page 118: Appendix B: Dual Bios Introduction

    To provide increased flexibility and usage protection, Lanner has released the 2nd Gen Dual BIOS function on Lanner appliances. With 2nd Gen Dual BIOS, both the primary BIOS and secondary BIOS can be updated and flashed using the BIOS Tool to run different versions of BIOS ROMS independently for maximum compatibility.
  • Page 119 Lanner Technical Support. Warning DO NOT power off or reset the system during BIOS updating process. Disclaimer Under no circumstances will Lanner accept responsibility or liability for damages of any kind whatsoever resulting or arising directly or indirectly from a BIOS update.

  • Page 120: Appendix C: Terms And Conditions

    ECA-6040 User Manual APPENDIX C: TERMS AND CONDITIONS Warranty Policy 1. All products are under warranty against defects in materials and workmanship for a period of one year from the date of purchase. 2. The buyer will bear the return freight charges for goods returned for repair within the warranty period;...

  • Page 121: Rma Service Request Form

    ECA-6040 User Manual RMA Service Request Form When requesting RMA service, please fill out the following form. Without this form enclosed, your RMA cannot be processed.
