SKYDANCE T11 Quick Start Manual

Wall Mounted Touch Panel
Model No.: T11, T12, T13, T14

4 Zone / 1-4 color / Glass touch panel / Color wheel / AC input/ DMX 512 and RF 2.4G signal output
T11
Features
● Touch panel 4 zone 1-4 color DMX512 master, can also be used as 4 zone 1-4 color RF remote.
● DMX signal output, comply to standard DMX512 protocol, compatible with DMX decoder from any supplier.
● When used as RF remote, each zone can remote control multiple RF 2.4G LED controllers.
● Ultra sensitive high strength glass touch panel with touch color wheel in the middle.
● Smooth and accurate color adjustment by touching the color wheel.
● Touch keys with LED indicator.
● White & Black glass panel available.
Technical Parameters
Model No.
T11
Light type Single color
Output dmx channel number 4
Safety and EMC
ETSI EN 301 489-1 V2.2.3
EMC standard (EMC)
ETSI EN 301 489-17 V3.2.4
Safety standard
EN 62368-1:2020+A11:2020
ETSI EN 300 328 V2.2.2
Radio Equipment(RED)
Certi cation
CE,EMC,RED
Mechanical Structures and Installations
AC input N
DMX output -
DMX output +
Typical base as below:
86 size
European style
User Manual Ver 3.0.1
T12
T12 T13
RGB
Dual color
8
Environment
Operation temperature
Case temperature (Max.)
IP rating
Package
Size
Gross weight
AC input L
N L
INPUT 100-240VAC
T11/T12/T13/T14
DMX OUTPUT
DMX output +
D- D+ GND D- D+
DMX output -
DMX signal GND
Installation diagram:
T13
T14
RGBW
12 16
Ta: -30 O C ~ +55 O C
O
Tc: +65 C
IP20
L112 x W112 x H50mm
0.234kg
Uninstall Touch panel Baseplate
1
T14
Input and Output
Input voltage
100-240VAC
Input current
Max 0.1A
Output signal
DMX512, RF 2.4GHz
Dimming data
Input signal Touch key + RF 2.4GHz
10m(Barrier-free space)
RF Control distance
Dimming level
256 levels
Dimming range
0 -100%
Warranty
Warranty 5 years
33.00 mm
86.00 mm
60.00 mm
52.00 mm
59.00 mm 11.50 mm
Base
www.iskydance.pl
