SKYDANCE TL4-1D Manual

TL4-1D,TL4-2D
Wall Mounted Touch Panel DALI Master
● Touch panel 1 zone or 4 zone DIM/CCT DALI master.
● 1/4 DALI address, support DT6 dimming, DT8-TC color temperature.
● Touch panel DALI master assigns DALI addresses to all slaves on the bus , support unicast and group mode.
● In accordance with DALI standard protocol IEC 62386 and in compliance with DALI products from other international incorporation.
●
Powered by DALI bus
or 24VDC.
● Enable to set DALI address by encoding switch, support unicast, group and broadcast mode,
● Match with RF 2.4G single zone or multiple zone remote control optional.
● Smooth and accurate brightness and
● Touch keys with LED indicator.
● White & Black glass panel available.
Technical Parameters
Input and Output
DALI bus/24VDC
Power supply
Static currnt
17mA@16VDC, 2mA@24VDC
Output signal
DALI
Environment
Operation temperature O
Ta: -30 C ~ +55
O
Case temperature (Max.) Tc: +65 C
IP rating
IP20
Mechanical
Structures
and
Installations
10 level rotary switch
DALI signal input
DALI bus no need
distinguish
plus-minus polarity
Installation
diagram:

Uninstall Touch panel
User Manual Ver 1.0.0
2024.3
TL4-1D
1/4 Zone DIM
color temperature adjustment by touching the color slide.
Dimming data
Input signal
RF Control distance
Dimming level
Dimming range
O
C Package
Size
Gross weight
16 level rotary switch
X Y
Power Input -
Da1 Da2 +24V GND
Power Input +
Baseplate Base
TL4-2D
1/4 Zone CCT
also support slave DALI address assignment
Safety and EMC
Touch key + RF 2.4GHz
EMC standard (EMC)
10m(Barrier-free space)
256 levels
Safety standard
Radio Equipment (RED)
0
-100%
Certification
Warranty
L112 x W112 x H50mm
Warranty
0.230kg
86.00 mm
60.00 mm
52.00 mm
Typical base as below:
European style
RF DIM DALI
.
ETSI EN 301 489-1 V2.2.3
ETSI EN 301 489-17 V3.2.4
EN 62368-1:2020+A11:2020
ETSI EN 300 328 V2.2.2
CE, EMC, RED
5 years
34.50 mm
59.00 mm
11.50 mm
86 size
RED
