SKYDANCE T15 User Manual

Wall Mounted Touch Panel
Model No.: T15
4 Zone/1-5 color in one/Glass touch panel/Color wheel/AC input/DMX 512 and RF 2.4G signal output
Features
● Touch panel 4 zone 1-5 color DMX512 master, can also be used as 4 zone 1-5 color RF remote.
● Each zone can be set as single color, dual color(WW/CW), RGB, RGBW or RGB+CCT light type.
● DMX signal output, comply to standard DMX512 protocol, compatible with DMX decoder from any supplier.
● When used as RF remote, each zone can remote control multiple Skydance's 2.4G LED controllers.
● Ultra sensitive high strength glass touch panel with touch color wheel in the middle and backlighting.
● Smooth and accurate color adjustment by touching the color wheel.
● Touch keys with chord tones and LED indicator.
Technical Parameters
Input and Output
Input voltage
Input current
Output signal
Safety and EMC
EMC standard (EMC)
Safety standard(LVD)
Radio Equipment(RED)
Certification
Warranty
Warranty
User Manual Ver 1.0.2
85-265VAC
Max 0.1A
DMX512, RF 2.4GHz
EN301 489,EN 62479
EN60950
EN300 328
CE,EMC,LVD,RED
5 years
www.iskydance.com
Dimming data
Input signal
RF Control distance
Dimming level
Dimming range
Environment
Operation temperature
Case temperature Max.
( )
IP rating
LVD RED
Touch key + RF 2.4GHz
30m
256 levels
0 - 100%
O O
Ta: -30 C ~ +55 C
O
T c: +85
C
IP20
