- Page 1 INSTALLATION MANUAL Single Handle Pull Down Kitchen Faucet KPF-4110 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2024 Kraus USA Plumbing LLC I REV. JUN 26, 2024...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: DO NOT RETURN TO STORE...
- Page 3 Make sure you have all necessary parts by checking the diagram and · parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement. Read all instructions and safety warnings and ensure you have all tools, ·...
- Page 4 Diagram and Parts List A. Spray Head B. Faucet Body C. Mounting Hardware C1. Rubber & Metal Washer C2. Mounting Nut C3. Mounting Screws D. Quick Connector Weight E1. Weight Clip E2. Weight 2.5mm Hex Wrench...
- Page 5 Faucet Dimensions 10 7/8" [277.4mm] 5" 8 5/8" [128.5mm] [220.0mm] Ø2 1/4" [Ø58.0mm] 3/8" compression Installer Tip: Shut off main water supply before installing new faucet.
- Page 6 Step 1. Remove mounting hardware Shut off the water supply. Remove the old faucet. Clean the mounting surface. Remove mounting hardware (C) from faucet body (B). Step 2. Installing the faucet assembly Insert faucet body (B) through the hole in the sink or countertop.
- Page 7 Step 3. Securing the faucet assembly Install the rubber washer and metal washer (C1) onto the threaded mounting shank. Thread the nut (C2) onto the mounting shank. Lock the nut (C2) into position by tightening the screws (C3). Do not overtighten. (2N.m Max) Step 4.
- Page 8 Step 5. Installing the counterweight Install the weight clip (E1) at the point of the hose marking "weight here". Insert the weight (E2) onto the clip (E1) by sliding it down onto the clip (E1). Step 6. Making the waterline connections Thread the nut (1) on the supply line onto the outlet of the water supply valve and tighten with a...
- Page 9 Step 7. Flushing and checking for leaks Pull the hose assembly out of the spout and remove the spray head by unscrewing it from the hose in a counterclockwise direction. Be sure to hold the end of the hose down into the sink and turn the faucet on to the warm position where it mixes hot and cold water.
- Page 10 Replacement Parts Replacement Finish/Color Part # Parts List 1. Sprayer KP27501 BB, MB, SFS, BBMB, SFACB** 2. Screen Washer KP27088 3. Sprayer Hose KP27209 BLBB, BLMB, BLSFS, GRSFS, BLSFACB* 4. Connector KP27318 WH** 5. Quick Connector KP27090 Assembly 6. Spring Assembly KP27322 BB, MB, SFS, SFACB** 7.
- Page 11 Troubleshooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: PROBLEM CAUSE ACTION Bonnet nut (10) has Remove the cover button (14). Loosen set Leakage under faucet handle. come loose. screw (13) with hex wrench (15).
- Page 12 Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
- Page 13 TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
- Page 14 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
