- Page 1 INSTALLATION MANUAL Allyn™ Industrial Pull Down Single Handle Kitchen Faucet KPF-4102 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2023 Kraus USA Plumbing LLC I Rev. April 11, 2023...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: DO NOT RETURN TO STORE...
-
Page 3: Prior To Installation
Make sure you have all necessary parts by checking the diagram and · parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement. Read all instructions and safety warnings and ensure you have all tools, ·... -
Page 4: Quick Connector
Diagram and Parts List A. Spray Head G. Weight H. Weight Clip B. Faucet Body I. Quick Connector C. Rubber Washer J. Hex Wrench D. Metal Washer E. Mounting Nut F. Screws... -
Page 5: Faucet Dimensions
Faucet Dimensions 11 1/8'' [283.7mm] 8 7/8'' [128.1mm] [226.4mm] Ø2 1/4'' [58.0mm] 3/8”-compression Installer Tip: Shut off main water supply before installing new faucet. -
Page 6: Step 1: Installing The Faucet
Step 1: Installing the faucet Shut off the water supply. Place the faucet (B) through the hole in the countertop. Secure the faucet (B) to the countertop using the rubber washer (C), metal washer (D) and mounting nut (E) provided. Hand tighten the nut (E) onto the faucet assembly. -
Page 7: Step 3: Installing The Counterweight
Step 3: Installing the counterweight Install the weight clip (H) at the point of the hose marking "weight here". Insert the weight (G) onto the weight clip (H) by sliding it down onto the weight clip (H). Step 4: Connect waterlines to main valve Attach waterlines to angle stops and tighten until snug. -
Page 8: Replacement Parts
Replacement Parts Replacement Parts List Finish / Color Part # 1. Spray Head SFACB, CH, MB KP27298 SFSB, SFS** 2. Sprayer Washer KP27208 3. Sprayer Hose KP27209 GRCH, GRSFS, BLMB, BLSFSB, BLSFACB* KP27090 4. Quick Connector Assembly KP27210 5. O-Ring KP27211 6. -
Page 9: Troubleshooting
Troubleshooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: PROBLEM CAUSE ACTION Bonnet nut (9) has Remove the cover button (13). Loosen Leakage under the handle. come loose. set screw (12) with hex wrench (14). - Page 10 Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
- Page 11 TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
- Page 12 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
