I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
FOUR/FIVE SCREEN ARRAY ACCESSORY
MSP-YM4 / MSP-YMACC1
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CHIEF MSP-YM4
Summary of Contents for CHIEF MSP-YM4
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation FOUR/FIVE SCREEN ARRAY ACCESSORY Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description MSP-YM4 / MSP-YMACC1...
-
Page 2: Installation Instructions
MSP-YM4 up to (and including) the displays does not exceed 300 lbs (136.1 kg) [not to exceed 75 lbs (34.0 kg) for the MSP-YMACC1]. - Page 3 Installation Instructions MSP-YM4 / MSP-YMACC1 DIMENSIONS...cont’d MSP-YMACC1 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon...
-
Page 4: Tools Required For Installation
Installation Instructions MSP-YM4 / MSP-YMACC1 TOOLS REQUIRED FOR INSTALLATION PARTS B (4) A (2) (MSP-YMACC1 only) C (5) (+1: MSP-YMACC1 only) D (4) (+1: MSP-YMACC1 only) E (4) (+1: MSP-YMACC1 only) F (4) L (2) G (1) 7/8"-14 x 1-1/2"... - Page 5 MSP-YM4 up to (and including) the displays [not to exceed 300 lbs (136.1 kg) for the MSP-YM4, and not to exceed 75 lbs (34.0 kg) for the MSP-YMACC1]. Preparing Rails...
- Page 6 MSP-YM4 / MSP-YMACC1 Installation Instructions Installing to Wall Determine where the center of the array should be located on the wall. Place torpedo level Line up the diamond on bracket with center of array marking on rail to determine vertical center. (See Figure 5) Measure up 6"...
- Page 7 Installation Instructions MSP-YM4 / MSP-YMACC1 WARNING: IMPROPER INSTALLATION CAN LEAD TO DISPLAY FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! Using screws of improper size may damage your display. Use screws provided with this product. Attach brackets to back of screen using four M6 x 12mm Phillips head screws (J) and four M6 flat washers (K) for each screen.
- Page 8 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 Chief Manufacturing, a division of F +31 (0)40 2668615 Milestone AV Technologies Asia Pacific A Room 24F, Block D, Lily YinDu International Building LuoGang, BuJi Town, Shenzhen, CHINA.
