- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S LCD Swivel Stand MSS6000...
-
Page 2: Installation Instructions
MSS6000 DISCLAIMER Milestone AV Technologies, Inc., and its affiliated corporations and subsidiaries (collectively, "Milestone"), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product. - Page 3 Installation Instructions LEGEND Tighten Fastener Apretar elemento de fijación Befestigungsteil festziehen Apertar fixador Serrare il fissaggio Bevestiging vastdraaien Serrez les fixations Loosen Fastener Aflojar elemento de fijación Befestigungsteil lösen Desapertar fixador Allentare il fissaggio Bevestiging losdraaien Desserrez les fixations Phillips Screwdriver Destornillador Phillips Kreuzschlitzschraubendreher Chave de fendas Phillips...
-
Page 4: Tools Required For Installation
MSS6000 TOOLS REQUIRED FOR INSTALLATION PARTS 3/16" 5/32" (Provided) (Provided) A (1) B (5) C (1) .5x.5x.203 5/32" Installation Instructions 3/8" D (1) 3/16"... -
Page 5: Installation
Installation Instructions INSTALLATION Mount Installation Free Standing (not anchored) Applications Only: NOTE: Do not perform this step if you are going to anchor the stand to a surface. Install five rubber bumpers (B) on bottom of stand. (See Figure 1) Rubber Bumpers (5 places) View from Bottom... -
Page 6: Display Installation
MSS6000 Display Installation The following procedure assumes that the proper interface bracket for the display being mounted has already been installed on the display. If no interface bracket is present on display, install bracket to display using the instructions included with the interface bracket before proceeding. - Page 7 Installation Instructions Remove bolt or padlock if used Pin in "Closed" position - move to "Open" position to remove display Pin in "Open" position - move to "Closed" position after display is removed. Figure 7 ADJUSTMENTS Display Height Adjustment CAUTION: Displays are fragile. Allowing the display to drop to bottom of stand may result in damage to the display.
- Page 8 MSS6000 2 deg. Max. Roll Adjustment Nuts (2 places) NOTE: Adjustment nuts located between slide plate and back plate of base assembly. Figure 9 Display Swivel Tension Adjustment Display swivel tension is pre-set at the factory. Swivel tension will vary depending on the weight of display being mounted.
-
Page 9: Cable Management
Installation Instructions Cable Management The MSS-6000 has been designed to provide multiple cable management/routing options. Option A Option A does not use the cable access features of the MSS-600 and simply routes the cables away from the display and mount. (See Figure 12) Figure 12 Option B Option B uses the cable access at the center of the MSS-... - Page 10 MSS6000 8800-000057 Rev. B 2008 Chief Manufacturing www.chiefmfg.com 03/08 USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615...
