Hardware layout and configuration
NUCLEO-WB07CC is designed around the STM32WB07CCV6. NUCLEO-WB07CC includes a mezzanine board
and an MCU RF board. The hardware block diagram in
STM32WB07CC and peripherals (ARDUINO
LINK).
Figure 3
and
Figure 5
dimensions of the NUCLEO-WB07CC product are shown in
NUCLEO-WB07CC (MB1801 + MB2119)
UM3344 - Rev 1
®
Uno V3 connectors, ST morpho connector, and embedded ST-
help users locate these features on the NUCLEO-WB07CC board. The mechanical
Figure 2.
Hardware block diagram
Printed antenna
MB2119
32 MHz
STM32WB07
32.768 kHz
Mini board connectors
B1, B2, and B3
User push-buttons
B4
Reset push-button
STLINK-V3EC
LD1
LD2
LD3
Status
User LEDs
LEDs
Figure 2
illustrates the connection between
Figure
6.
3.3 V
3.3 V LDO
5 V
PWR source
selection (JP1)
MB1801
®
USB-C
GPIO
Connector
UM3344
Hardware layout and configuration
VIN
5 V LDO
5 V
VIN
5V_EXT
RF
Clock
Power
SWD bus
page 8/51
