Nucleo-64 board (mb1801 and mb2119)

Advertisement

Printed antenna area
MB2119 board
MB1801D board
LDO 5 V
ST-LINK MCU
STM32F7 (U5)
UM3344 - Rev 1
Figure 5.
NUCLEO-WB07CC PCB bottom view
(U3)
UM3344
Hardware layout and configuration
MIPI10/STDC14
connector footprint
(CN17)
LVDO 3V3
(U4)
Voltage level shifter (U9)
Voltage level shifter (U15)
Voltage level shifter (U6)
Switch external/internal
power source (SW1)
®
ST-LINK USB Type-C
connector (CN15)
page 10/51
