INSTRUCTION MANUAL
For N120 FTZ Adaptor ER 25 with
Knob (for Z6III)
PN# 22225
FOREWORD
Thank you for your purchase of a NAUTICAM
product.
At NAUTICAM, we pride ourselves in the ability
to recognize the requirements of professional as
well as amateur underwater photographers and
fulfill them through the innovative designs of our
products. We strive to achieve a high level of
user-friendliness
by
installation and easy operation of all important
functions of the camera.
Each product is individually inspected and water
pressure tested to ensure optimum quality.
Please read this manual carefully before using
the product, this will maximize its performance as
well as its lifetime.
allowing
stress-free
Advertisement
Related Manuals for Nauticam 22225
Summary of Contents for Nauticam 22225
- Page 1 For N120 FTZ Adaptor ER 25 with Knob (for Z6III) PN# 22225 FOREWORD Thank you for your purchase of a NAUTICAM product. At NAUTICAM, we pride ourselves in the ability to recognize the requirements of professional as well as amateur underwater photographers and fulfill them through the innovative designs of our products.
- Page 2 Protect the interior from moisture with and/or placed within our products. and debris in order to prevent malfunction or NAUTICAM accepts no liability for any loss of leakage. captured images or the inability to capture images even if it is due to the malfunctioning of Defective products should be shipped to our our products.
- Page 3 IDENTIFICATION OF PARTS Port alignment “O” mark Unlock button Zoom/Focus Knob Port Cap Lock safety button Preparation of the product 1. After verifying that the sealing O-ring is in good condition, lightly coat it with the lubricant provided and wipe away the excess. 2.
- Page 4 REMOVE HOUSING CAP To remove housing cap 1. Gently push the safety button of housing port locking lever downwards. 2. Gently turn the port locking lever counterclockwise to the most outward position as shown until it cannot go any further. Reminder: please refrain...
- Page 5 MOUNT ER25 TO HOUSING To install port adaptor 4. Prepare sealing O-ring first instructed on page 3, align the extension ring “o” mark with housing’s, and push the product onto the housing gently. 5. Lock the housing port locking lever into place by turning the lever to the inward lock position.
- Page 6 INSTALL PORT 1. After install lens and gear, engage the gear on the lens by pushing the knob inwards, then turn the knob both direction to check if the lens is functioning. 2. Press the extension ring unlock button. 3. Then press the extension ring lock safety button and turn the locking lever to release position as shown.
- Page 7 INSTALL PORT Align the alignment “O” mark of the extension ring and the port, gently push the port into the extension ring until it cannot go in any further. 5. Lock it into place by turning the locking lever to the inward lock position and when a “click”...
- Page 8 SPECIFICATIONS #22225 N120 FTZ Adaptor ER 25 with Knob (for Z6III) Dimensions(mm): DIA162.4x132.2x38.1 Extension length: 25 mm Port Mount: N120 Material: Aluminum Alloy Depth rating: 150m Compatible NA-Z6III Housing Remark: Nauticam supports only e-manuals. Please download corresponding product manuals on google drive https://bit.ly/Nauticammanual, or contact us for e-...
- Page 9 Please refer to "Nauticam Product Care and O-ring with the provided lubricant before Maintenance Guide" for more details.
