Fig. 48: Main control panel
2011-08-30
Item Name
16
17
1 [ON]
High-voltage
2
regulator
High-voltage
3
input field
18
[▲] / [▼]
4
5 [▲] / [▼]
19
20
21
"Beam" LED
6
22
23
24
Indicator "Power"
7
[Iso]
8
25
26
9 [Controls]
27
28
10 [Timer]
11 "System Messages"
[▲] / [▼]
12
Indicator "Focus"
13
14 "Modus" [0]
15 "Modus" [1]
X-ray inspection system phoenix x|aminer
Operating the X-ray controls
Description
Switches on X-ray emission or restarts an
aborted process (such as warm-up, if it had
been aborted by opening the interlock).
The button turns bright green when the system
is ready to generate the X-ray beams.
Regulates high voltage between mini-
mum and maximum values.
For entering the high-voltage setpoint
value directly.
Changes high voltage by +/- 1 kV.
Changes high voltage by +/- 10 kV.
Beam status:
Red
"Off": X-ray is off.
Yellow
"RunUp": Beam is being generated or
centred.
Green
"Stable": Beam is stable and focused.
Displays the beam power in watts.
Keeps power supply constant in the
event of high-voltage fluctuations. The
corresponding tube current is set au-
tomatically.
Activates or deactivates the window
featuring status indicators and possible
additional functions.
Activates or deactivates the window
featuring a timer.
Displays system messages.
NA
NA
NA
NA
